Stanko 6M82 Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko 6M82 Milling Machine Specification

Rotation
Bi-directional spindle

Model
6M82

Product Type
Horizontal Milling Machine

General Use
Precision milling, drilling, and boring operations in metalworking industries

Material
Cast iron base and steel components

Type
Universal

Capacity
Max milling width 315 mm

Weight (kg)
2300 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC (Manual)

Control System
Conventional

Table Size
1250 x 320 mm

Table Slide Way
Box type

Floor Space
2200 x 2250 mm

WorkingSpeed
Manual, feeds of 18-900 mm/min

Spindle Speed
56 - 1800 rpm (12 steps)

Power
5.5 kW

Voltage
380 V, 3 Phase

Dimension (L*W*H)
2200 x 2250 x 1680 mm

Feature
Swivel table, robust build, rapid feed, overarm support

Color
Industrial Green/Grey

Stanko 6M82 Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stanko 6M82 Milling Machine

Make - Stanko (Russia)

Model - 6M82

Table Size - 1325 mm x 320 mm

XYZ Travel - 700 mm x 255 mm x 400 mm

Spindle Speeds - 31.5 rpm to 1600 rpm

Table Feed Rate - 25 mm/min to 1250 mm/min

- Double Swivel type Vertical Milling Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/r03Iy_zoFnQ

Precision Engineering for Diverse Applications

Engineered for reliability and accuracy, the Stanko 6M82 is ideal for tasks that demand precise milling, drilling, and boring. Its robust cast iron base ensures long-lasting stability, while the bi-directional ISO 50 spindle and semi-automatic functions allow for efficient and flexible machining of a wide range of metal components.

User-Centric Design and Operation

The manual control system of the 6M82 offers full command over operations. The centralized lubrication system enhances maintenance, and the coolant system protects both the machine and workpiece. A roomy work table and swift rapid feed increase throughput, while the swivel table enables the machining of complex parts.

Ideal for Industrial Workshops

With a maximum workpiece weight of 500 kg and a maximum milling width of 315 mm, this machine is well-suited for heavy-duty operations in manufacturing plants. Its compatible dimensions make it fit well into standard industrial spaces, and its industrial green/grey finish offers both durability and a clean appearance.

FAQs of Stanko 6M82 Milling Machine:

Q: How does the Stanko 6M82 Milling Machine enhance precision in metalworking?

A: The 6M82 provides precise control with manual feeds ranging from 16800 mm/min and a bi-directional ISO 50 spindle, allowing for accurate milling, drilling, and boring. Its robust build, box-type table slide ways, and centralized lubrication further improve machining accuracy.

Q: What types of operations can be performed on the Stanko 6M82 Milling Machine?

A: This machine is designed for precision milling, drilling, and boring tasks. Its swivel table and overarm support facilitate complex and angled machining, while the large table size and spindle travel range accommodate a variety of workpiece sizes.

Q: When should the lubrication and coolant systems be operated on the 6M82?

A: Both the centralized lubrication and coolant systems should be active during milling to ensure smooth movement of components and to dissipate heat, which increases tool life and maintains accuracy.

Q: Where is the Stanko 6M82 best utilized?

A: The 6M82 excels in industrial workshops, manufacturing facilities, and metalworking plants where high precision and durability are required, especially for handling sizable or heavy metal parts.

Q: What is the process for setting up workpieces on the 6M82 table?

A: Workpieces are mounted using the three 18 mm T-slots on the 1250 x 320 mm table, securing them with appropriate clamps or fixtures. The tables robust design ensures stability during machining processes.

Q: How does the rapid feed function benefit users?

A: The rapid feed feature, with speeds up to 2500 mm/min, allows for swift table positioning between cutting operations, saving valuable setup time and ensuring greater overall efficiency in production runs.

Q: What are the main advantages of the 6M82s manual, non-CNC operation?

A: Manual operation gives skilled machinists direct control over every aspect of the machining process, making it ideal for custom, small-batch, or prototyping work, where flexibility and adaptability are essential.
