Stanko 6T13 Pure Vertical Milling Machine

Name: Stanko 6T13 Pure Vertical Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 23500 INR
Availability: InStock

Price 23500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko 6T13 Pure Vertical Milling Machine Specification

Rotation
Vertical

Model
Stanko 6T13

Product Type
Vertical Milling Machine

General Use
Vertical Milling Operations, Precision Machining

Material
Cast Iron, Steel

Type
Pure Vertical

Capacity
Heavy Duty

Weight (kg)
Approx. 2800 kg

Computerized
No

Automatic
No, Manual

CNC Or Not
Not CNC

Control System
Manual

Table Size
1320 mm x 320 mm

Table Slide Way
Box Type

Floor Space
1800 mm x 1600 mm

Spindle Speed
402000 RPM (12 steps)

Power
3.7 kW (5 HP)

Voltage
380415 V

Dimension (L*W*H)
Approximately 1800 x 1600 x 2000 mm

Feature
Robust Construction, High Precision

Color
Green

Distance from Spindle Nose to Table
30400 mm

Distance from Spindle Axis to Column
320 mm

Table Load Capacity
350 kg

Cross Table Travel
320 mm

Vertical Table Travel
420 mm

Feed Range (Longitudinal/Cross/Vertical)
31.51600 mm/min

Coolant System
Yes, Integrated

Main Motor Power
5 HP (3.7 kW)

Number of Spindle Speeds
12

Overarm Travel
650 mm

Longitudinal Table Travel
1000 mm

WorkingSpeed
Variable, 402000 RPM

Spindle Taper
ISO 40

Stanko 6T13 Pure Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stanko 6T13 Pure Vertical Milling Machine

Make - Stanko (Russia)

Model - 6T13

Table Size - 1700 mm x 400 mm

XYZ Travel - 950 mm x 400 mm x 450 mm

Spindle Taper - ISO 50

Spindle Speeds - 31.5 rpm to 1600 rpm

Table Feed Travel Rates - 6.25 mm/min to 1600 mm/min

- It is a Heavy Duty type Pure Vertical Milling Machine.

- Automatic Tool Clamping.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/pnsvA7Hcgfc

Exceptional Precision and Versatility

The Stanko 6T13 Vertical Milling Machine is designed to handle an extensive range of vertical milling tasks with unmatched accuracy. With a robust cast iron and steel construction, the machine delivers consistent results when working on large and heavy components. Its variable speed gearbox and 12 programmable spindle speeds cater to diverse material and process requirements.

Optimized for Heavy-Duty Performance

With a table load capacity of 350 kg and a rigid 1320 x 320 mm table, the Stanko 6T13 is purpose-built for demanding industrial applications. The reliable manual control and box-type slide ways contribute to extended operational life and minimal deflection, ensuring your machining tasks are completed with confidence under continuous runs.

User-Friendly Manual Control

This non-computerized, manual machine prioritizes user control for precise adjustments during operations. Operators benefit from intuitive feed range control (31.51600 mm/min) and an integrated coolant system, which enhance process efficiency and workpiece quality during prolonged usage.

FAQs of Stanko 6T13 Pure Vertical Milling Machine:

Q: How is the Stanko 6T13 Pure Vertical Milling Machine operated?

A: The Stanko 6T13 is operated manually, allowing operators full control over all settings. The controls are conveniently located for straightforward spindle speed selection and feed adjustments, catering to experienced machinists who value tactile feedback during precision milling.

Q: What are the principal benefits of using the Stanko 6T13 for vertical milling?

A: This machine offers excellent rigidity, consistent precision, and the flexibility to work with large, heavy-duty parts. Its robust construction, variable spindle speeds, and high table load capacity make it ideal for precision vertical milling operations in demanding industrial environments.

Q: When should I use the Stanko 6T13 over a CNC milling machine?

A: The Stanko 6T13 is particularly suitable when manual control, high load capacity, and reliability are required, especially for custom, one-off, or varied small-batch tasks where programming a CNC is less efficient. Its favored in environments where hands-on adjustments and immediate feedback are crucial.

Q: Where is the Stanko 6T13 typically employed in industrial settings?

A: This model is commonly found in heavy manufacturing plants, machine shops, and maintenance facilities that require robust, precision vertical milling for steel, cast iron, or similar materials. Its high capacity and durability make it a staple in workshops worldwide.

Q: What processes can be performed using the Stanko 6T13?

A: You can carry out various vertical milling operations, such as face milling, slotting, drilling, and precision shaping. The wide feed range and adjustable spindle speeds support a variety of cutting tasks on tough materials.

Q: How do the machines construction and features improve operational efficiency?

A: The machines box-type slide ways, heavy-duty cast iron frame, precise spindle assembly, and integrated coolant system minimize vibration and thermal expansion, thus maintaining accuracy over long periods. These features collectively support extended runs and reduce downtime due to maintenance.
