Stanko 750 mm Stroke Heavy Duty Shaper Machine

Name: Stanko 750 mm Stroke Heavy Duty Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 50000 INR
Availability: InStock

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko 750 mm Stroke Heavy Duty Shaper Machine Specification

Production Capacity
750 mm stroke length (work travel per stroke)

Drive
V-Belt / Direct Motor Coupled

Machine Type
Heavy Duty Mechanical Shaper

Frame Type
Heavy cast iron box frame

Lubricating System
Automatic or manual lubrication pump

Noise Level
<80 dB

Cooling System
Conventional coolant circulation (Manual/Optional)

Frequency
50 Hz

Motor Power
7.5 HP

Power Rating
5.5 kW - 7.5 kW

Features
Robust construction, Hardened guideways, Swivel tool head, Adjustable stroke length

Operating Temperature
Ambient (5°C to 45°C Recommended)

Voltage
415 V, 3 Phase

Connectivity Options
N/A (Conventional machine)

Plastic Processed
Not applicable (Metalworking machine)

Accuracy
±0.02 mm (High, for industrial use)

Model No
750

Control System
Hand Lever & Mechanical Feed

Product Type
Heavy Duty Shaper Machine

Technology
Mechanical Reciprocating (Ram shaper)

Power Source
Electric

Operating Type
Manual / Semi-Automatic

Power
7.5 HP (Approximate)

Pressure
Hydraulic (Shaper machines typically operate with hydraulic pressure for smooth feed operations)

Surface Treatment
Paint Coated

Dimension (L*W*H)
Approx. 2500 x 1300 x 1600 mm

Weight (kg)
2800 kg (Approximate)

Color
Industrial Blue / Grey

Usage & Applications
Metal shaping, Slotting, Keyway cutting, Surface finishing

Main Drive Motor Speed
1440 rpm

Import Status
Original Stanko Russian make

Max. Stroke Length
750 mm

Suitable Material
Mild steel, Cast iron, Non-ferrous metals

Finish
Heavy duty industrial enamel paint

Clamping Slots
Provided for workpiece fixing

Maximum Work Height
450 mm

Coolant Pump Capacity
0.1 HP (if equipped)

Table Size (L x W)
800 x 350 mm

Tool Post
Universal type

Table Rotation
±90° (depending on variant)

Ram Adjustment
300 mm (Approximate)

Max Table Travel (Longitudinal / Cross)
950 mm / 400 mm

Net / Gross Weight
2800 kg / 3200 kg (Approximate)

Tool Head Swivel Angle
±60°

Stanko 750 mm Stroke Heavy Duty Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Stanko 750 mm Stroke Heavy Duty Shaper Machine About

Make - Stanko (Russia)

Model - 7A36

Max. Stroke Length - 750 mm

Table Size - 710 mm x 450 mm

Feed Travel Rate - 0 mm/stroke to 5 mm/stroke

Cross Travel of Table - 750 mm

Max. Height between Table to Tool - 425 mm

- Motorized Rapid Travels on the Cross & Vertical Travel of Table.

- Automatic Feed Travel of the Tool Post Slide.

- Continuously Variable Feed Rates of Table Travel.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/E4NSO9a1rJQ

Precision and Versatility for Your Workshop

With a maximum stroke length of 750 mm and table travel up to 950 mm longitudinally, the Stanko shaper delivers versatility for a range of metalworking projects. This heavy-duty machines universal tool post and 60 swivel tool head empower users to execute complex shaping, keyway cutting, slotting, and surface finishing tasks with high accuracy. Suitable for both manual and semi-automatic operations, it seamlessly fits into any industrial setting demanding reliable performance.

Rugged Construction and Reliable Operation

Manufactured originally in Russia, the Stanko 750 mm shaper boasts a heavy cast iron box frame and hardened guideways, providing unparalleled rigidity and longevity. Its mechanical reciprocating technology, coupled with a powerful 7.5 HP motor, enables consistent operation across diverse materials like mild steel, cast iron, and non-ferrous metals. The machine incorporates safety features such as clamping slots for secure workpiece fixing and optional coolant and lubrication systems to optimize tool life and surface finish.

FAQs of Stanko 750 mm Stroke Heavy Duty Shaper Machine:

Q: How does the Stanko 750 mm stroke heavy duty shaper operate?

A: The Stanko shaper utilizes a mechanical reciprocating ram technology powered by a 7.5 HP electric motor, allowing manual or semi-automatic operation via a hand lever and mechanical feed system. This design ensures precise, repeatable shaping and surface finishing of metal workpieces.

Q: What materials can be processed with the Stanko 750 mm shaper machine?

A: This machine is suitable for working with mild steel, cast iron, and various non-ferrous metals, thanks to its robust construction and adjustable features. It is ideal for shaping, slotting, keyway cutting, and finishing operations on these materials.

Q: Where is the Stanko 750 mm shaper machine typically used?

A: The shaper is commonly found in industrial workshops, manufacturing plants, and metalworking facilities where heavy-duty shaping, slotting, and keyway cutting are required on medium to large components.

Q: When is it recommended to use the coolant system on this shaper?

A: The coolant system, with a capacity of 0.1 HP (if equipped), should be used during extended operations or when machining tough materials to reduce heat buildup, improve tool life, and enhance surface finish quality.

Q: What process adjustments are available for customizing operations on this machine?

A: Users can adjust the ram stroke, table position (longitudinal and cross travel), ram height, and utilize the universal tool post and swiveling tool head (60 angle) to achieve desired cutting profiles and angles for various metalworking tasks.

Q: How does the machine benefit metalworking production and accuracy?

A: Its high level of accuracy (0.02 mm), stable box frame, and hardened guideways ensure precise shaping and consistent dimensions for repeat production runs. These benefits reduce error, increase productivity, and improve finish quality.

Q: What maintenance steps are recommended for prolonged service life?

A: Regularly check and top up the lubrication system, inspect and clean clamping slots, ensure coolant circulation (if equipped), and maintain proper electrical connections for reliable, noise-free (below 80 dB) operation and extended machine life.
