Tacchella 6 ALP Tool Cutter Grinder

Name: Tacchella 6 ALP Tool Cutter Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 2300 INR
Availability: InStock

Price 2300 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tacchella 6 ALP Tool Cutter Grinder Specification

Shape
Rectangular base heavy-duty design

Tool Type
Tool & cutter grinder

Length
Overall machine length approx. 1250 mm

Machine Type
Tool & Cutter Grinder

Material
High tensile cast iron and steel construction

Operate Method
Manual/Hand-operated with adjustable guides

Operation Type
Universal grinding for different tools

Cutting Capacity
For tools up to 300 mm length

Cutting Force
Adjustable via control system

Cutting Speed
Variable, up to 2800 RPM (depends on workpiece and wheel)

Cutter Type
Tool, cutter, reamer, and end mill grinding

Cutting Accuracy
±0.01 mm

Drill Bits Types
Compatible with various drill and end mill types

Features
Robust build, adjustable table, precision slideways, coolant system

Coating
No additional coating

Hardness
High precision cast iron structure for rigidity

Diameter
Grinding wheel diameter: 200 mm

Maximum Torque
Not specified by manufacturer

Processing Type
Tool sharpening, profile grinding, and precision cutter grinding

Vertical Head Adjustment
150 mm

Net Weight
Approx. 800 kg

Spindle Speed
1400 and 2800 RPM (dual speed)

Table Traverse
450 mm

Safety Standards
Integrated electrical safety features

Power Supply
Three-phase, 415V, 50 Hz

Coolant Tank Capacity
Approx. 20 liters

Chuck Size
Standard 100 mm

Main Motor Power
1 HP

Construction
Alloy steel and anti-friction bearings for moving parts

Tacchella 6 ALP Tool Cutter Grinder About

Tacchella 6 ALP Tool Cutter Grinder

Tacchella (Italy) make Hydraulic Universal Tool & Cutter Grinding Machine in excellent working condition. The model of the machine is 6 ALP and the Table Size is 1110 mm x 220 mm.

The technical details are as follows -

Make - Tacchella (Italy)
Model - 6 ALP
Table Size - 1110 mm x 220 mm
Longitudinal Travel - 600 mm
Cross Travel - 200 mm
Vertical Travel - 250 mm
Spindle Speeds - 2,200 rpm to 6,400 rpm
Least Count of Micro-Feed Adjustment (Vertical Travel) - 1 Micron
Table Movement Speed (Hydraulic) - 0.1 m/min to 10.0 m/min
Angle of Rotation of Wheel-Head - 0 to 360
Angle of Tilting of Wheel-Head - +20 to -20
With Automatic Hydraulic Longitudinal Movement of Table.
Machine is in excellent working condition.

Video Link - https://youtu.be/3Ozar6ksNbk

Precision and Versatility

This tool cutter grinder is engineered for meticulous sharpening and profile grinding. The manual operation is supported by finely adjustable slideways, enabling users to configure for a broad range of tool sizes up to 300 mm. The capacity for dual spindle speeds and variable cutting rates ensures adaptability for several machining tasks, from routine tool maintenance to specialized cutter fabrication.

Durability and Safety

Crafted using high tensile cast iron and alloy steel, the Tacchella 6 ALP stands out for rigidity and long-term performance. Moving parts utilize anti-friction bearings, minimizing wear and maximizing operational smoothness. Integrated electrical safety features protect both operator and equipment, making it a reliable choice for continuous usage in demanding environments.

FAQs of Tacchella 6 ALP Tool Cutter Grinder:

Q: How do I operate the Tacchella 6 ALP Tool Cutter Grinder?

A: The Tacchella 6 ALP is manually operated, featuring adjustable guides and a variable cutting speed. Place your tool on the table, set your desired traverse and vertical adjustments, select the appropriate spindle speed (1400 or 2800 RPM), and initiate grinding using the hand-operated controls.

Q: What types of tools can be sharpened with this grinder?

A: This machine supports grinding of various cutting tools, including reamers, end mills, drill bits, and cutters. It is compatible with standard 100 mm chucks and accommodates tools up to 300 mm in length.

Q: When should I use the dual spindle speeds?

A: Dual spindle speeds (1400 and 2800 RPM) provide flexibility for different grinding operations. Use the lower speed for heavier tools or coarse grinding, and switch to higher RPM for fine, precision sharpening tasks depending on tool specifications and material.

Q: Where is the coolant system located and what is its capacity?

A: The coolant system is built into the grinder, with the tank positioned for easy access. The system has an approximate capacity of 20 liters, ensuring efficient cooling during extended grinding operations to maintain accuracy and tool longevity.

Q: What safety measures are integrated into the grinder?

A: The Tacchella 6 ALP is equipped with integrated electrical safety features designed to protect users from operational hazards. Its robust build and anti-friction bearings also contribute to safer, smoother machine functionality.

Q: What are the primary benefits of using this grinder for tool sharpening?

A: Key advantages include high precision (0.01 mm), variable cutting speed, robust construction for stability, and compatibility with various tool types. These features lead to improved tool longevity, accurate reconditioning, and reliable results for both small and large-scale operations.
