Tacchi 8 meter Heavy Duty Lathe Machine

Price 30000 USD ($)/ Piece

Get a Price/Quote

MOQ : 1 Piece

Tacchi 8 meter Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron, Steel Fabricated

Cutting Thickness
Up to 50 mm (depending on material and tooling)

Cutting Speed
Variable up to 1200 RPM

CNC Or Not
Conventional (Non-CNC)

Automatic Grade
Manual

Control System
Manual with Electrical Panel

Max. Swing Diameter
1600 mm

Voltage
415 V, 3 Phase, 50 Hz

Weight (kg)
Approx. 16000 18500 kg

Dimension (L*W*H)
Approx. 9000mm x 1800mm x 2100mm

Capacity
High capacity; able to turn jobs up to 8 meters in length

Feature
Robust Bed, Precise Gearbox, Hardened Guideways, Heavy Duty Tailstock

Color
Industrial Grey

About Tacchi 8 meter Heavy Duty Lathe Machine

Tacchi 8 meter Heavy Duty Lathe Machine

Make - Tacchi (Italy)
Model - FTC 71
Center Height - 710 mm
Max. Length of Job - 8000 mm
Max. Diameter of Job over Bed - 1420 mm
Max. Diameter of Job over Cross-Slide - 950 mm
Bed Width - 850 mm
Chuck Diameter - 1200 mm
Spindle Speeds - 5 rpm to 475 rpm
Spindle Bore - 160 mm
Weight of Machine - 27 tons (approximately)
- With Motorized Rapid Travels of Carriage & Tool-Slide.
- Tool-Slide (Top Slide) also has powered Feed Travels.
- Complete with 2 x Steady and 1 x Follow Rest.
- Machine is in excellent working condition

Precision Engineering for Heavy Duty Turning

The Tacchi lathe machine features a hardened bed and guideways, ensuring accurate machining even on large components. Its solid construction minimizes vibrations, allowing operators to achieve fine tolerances within IS standards. This machine excels in turning long pipes, shafts, and other heavy workpieces for industries requiring reliability and robust operation.

Advanced Gearbox for Flexible Machining

Equipped with a precise, all-geared headstock, the Tacchi lathe offers a range of longitudinal feed rates from 0.05 to 2.5 mm/rev and supports both metric and inch thread cutting. This versatility enables efficient handling of complex jobs that demand multiple pitches or unique specifications, making it ideal for exporters, manufacturers, and suppliers.

Safety and Convenience Features

Designed with operator convenience in mind, the machine includes a built-in coolant system and centralized automatic lubrication for smooth operation and minimal maintenance. The electrical panel controls provide intuitive manual adjustments, ensuring safe and effective usage in industrial settings where reliability is paramount.

FAQs of Tacchi 8 meter Heavy Duty Lathe Machine:

Q: How is the Tacchi 8 Meter Heavy Duty Lathe Machine operated?

A: This lathe is manually controlled via an electrical panel, enabling precise adjustments during operation. The machine does not feature CNC capabilities, allowing users to directly manage feed rates, spindle speeds, and thread cutting.

Q: What types of jobs can be processed on this lathe?

A: The Tacchi lathe is ideal for turning large and heavy workpieces such as long pipes, shafts, rollers, and cylindrical components up to 8 meters in length with a maximum swing diameter of 1600 mm. It accommodates various materials including cast iron and steel.

Q: When should the built-in coolant and lubrication systems be used?

A: The coolant system is activated during cutting operations to dissipate heat and extend tooling life, while the centralized automatic lubrication operates continuously as long as the machine runs, ensuring consistent lubrication of critical components.

Q: Where is the Tacchi lathe machine commonly employed?

A: Industries such as manufacturing, fabrication, heavy engineering, and export/import sectors utilize this lathe for precision turning of lengthy and bulky components. It is widely used by exporters, importers, manufacturers, suppliers, and traders seeking reliable, large-capacity machinery.

Q: What is the benefit of the all-geared headstock and robust bed design?

A: The all-geared headstock offers a wide range of speeds and feeds, allowing flexible machining for different materials and threading requirements. The robust bed and hardened guideways provide enhanced stability and long-term accuracy during intensive operations.

Q: How does the lathe achieve high working accuracy?

A: The machines design follows IS standards for working accuracy. Its heavy-duty construction, precise gearbox, and hardened guideways ensure minimal deflection, enabling consistent dimensional accuracy for critical machining tasks.

Q: What is the process for thread cutting on this lathe?

A: Thread cutting can be performed in both metric and inch pitches by selecting the appropriate gearbox settings. The lead screw (60 mm diameter, 6 mm pitch) ensures accurate synchronization between carriage movement and spindle rotation for precise threads.
