TOS 1000 mm x 300 mm Vertical Surface Grinder Machine

Send Inquiry

Request To Call Back

TOS 1000 mm x 300 mm Vertical Surface Grinder Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 1000 mm x 300 mm Vertical Surface Grinder Machine Specification

Model
TOS 1000 x 300

Rotation
Clockwise

Product Type
Vertical Surface Grinder

General Use
Precision surface grinding of metals and components

Material
Cast Iron, Mild Steel

Type
Vertical

Capacity
Approx. 500 kg

Weight (kg)
3500 kg

Computerized
No

Automatic
Semi Automatic

CNC Or Not
No

Control System
Conventional

Table Size
1000 mm x 300 mm

Table Slide Way
V and Flat guideways

Magnetic Chuck Size
1000 mm x 300 mm

Grinding Wheel Size
400 mm diameter x 50 mm width

Grinding Wheel Speed
1440 RPM

Grinding Length
1000 mm

Floor Space
3100 mm x 2000 mm

Fuel Tank Capacity
80 Liters (Hydraulic)

Spindle Speed
1440 RPM

Power
7.5 HP

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
3100 mm x 2000 mm x 2200 mm

Feature
Heavy Duty, High Precision, Rigid Construction

Color
Standard Industrial Grey

Max Grinding Height
400 mm

Grinding Accuracy
0.01 mm

Machine Construction
Monolithic base

Table Traverse Speed
325 m/min

Surface Finish
Excellent (Ra0.5)

Safety Features
Overload protection, Emergency stop

Lubrication System
Automatic

Noise Level
Low

Cross Feed Travel
350 mm

Spindle Motor Power
7.5 kW

Chuck Magnet Type
Electromagnetic

Hydraulic Pump Motor
1 HP

Main Motor Type
3-phase induction

Minimum Feed
0.001 mm

WorkingSpeed
Adjustable

Coolant Tank Capacity
60 Liters

TOS 1000 mm x 300 mm Vertical Surface Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS 1000 mm x 300 mm Vertical Surface Grinder Machine

Make - TOS (Czech Republic)

Model - BPV 300/1000

Magnet Size - 300 mm x 1000 mm

Segmented Wheel Cup Diameter - 315 mm

No. of Segments in Wheel - 8 pcs.

Max. Height of Job - 400 mm

Spindle Motor - 15 kW

- With Automatic Depth Adjustment "Auto-Cut".

- Complete with Coolant tank and pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/JBosID9AR_E

Exceptional Precision and Surface Finish

Designed to deliver an excellent surface finish and high precision, the TOS grinder boasts a minimum feed of 0.001 mm and grinding accuracy within 0.01 mm. Its electromagnetic chuck and robust grinding wheel ensure consistent performance on cast iron and mild steel, achieving a top-quality Ra0.5 finish for critical components.

Versatile Functionality and High Capacity

The machine accommodates workpieces up to 1000 mm in length and 300 mm in width, with a grinding height of 400 mm. Its heavy-duty build, adjustable table traverse speed (325 m/min), and 3500 kg weight make it ideal for various industrial grinding tasks, from manufacturing to repair operations.

Built for Reliability and Operator Safety

With automatic lubrication, overload protection, and emergency stop, the vertical surface grinder prioritizes operator safety and machine longevity. The low-noise construction and rigid frame further enhance user comfort, while the semi-automatic system allows ease of use for skilled operators.

FAQs of TOS 1000 mm x 300 mm Vertical Surface Grinder Machine:

Q: How does the TOS 1000 mm x 300 mm vertical surface grinder improve machining precision?

A: The grinder achieves high machining precision through its monolithic base, minimum feed of 0.001 mm, and electromagnetic chuck, ensuring stable workpiece holding and accurate grinding. Its advanced construction and controlled spindle speed (1440 RPM) deliver a grinding accuracy of 0.01 mm, making it ideal for precision surface applications.

Q: What are the main applications of this vertical surface grinder machine?

A: This machine is primarily intended for precision grinding of metal surfaces and components, such as cast iron, mild steel, and other compatible materials. Industries like manufacturing, repair shops, and component production benefit from its capacity, accuracy, and consistent surface finish.

Q: Where can the TOS 1000 x 300 surface grinder be installed, considering its floor space requirements?

A: The machine requires a dedicated installation area measuring at least 3100 mm x 2000 mm. It is suitable for industrial workshops, manufacturing plants, and metal fabrication facilities where heavy-duty precision grinding is performed regularly.

Q: What safety features are included with the surface grinder?

A: The grinder features built-in overload protection and an emergency stop system to safeguard operators during operation. These mechanisms prevent damage to the machine and reduce the risk of injury during unexpected events, ensuring a safe workplace.

Q: How is the lubrication process managed on this machine?

A: Lubrication on the TOS vertical surface grinder is fully automatic, ensuring consistent application to critical moving parts and guideways. This reduces maintenance requirements and prolongs machine life, helping maintain optimal performance and reliability.

Q: When should I adjust the table traverse speed or working speed?

A: Table traverse speed (325 m/min) and working speed are adjustable based on material, workpiece dimensions, and desired surface finish. Operators should select appropriate speeds for specific tasks to balance performance, precision, and efficiency.
