TOS 200 mm Diameter Gear Shaper Machine

Name: TOS 200 mm Diameter Gear Shaper Machine
Brand: Liberty Metal & Machines Private Limited
Price: 42500 INR
Availability: InStock

Price 42500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 200 mm Diameter Gear Shaper Machine Specification

Condition
Used

Machine Type
Gear Shaper Machine

Capacity
200 mm (Maximum gear diameter)

Power
6 kW

Dimension (L*W*H)
Approx. 2000 x 1400 x 2100 mm

Voltage
380-415 V

Output
Accurate gear shapes, batch or individual gears

Weight
Approximately 3000 kg

Used For
Gear cutting, shaping external and internal gears

Feature
High precision, robust structure, versatile gear cutting

Color
Green

Max Module
6 mm

Spindle Speed
Variable

Automation Grade
Semi-Automatic

Feed Rate
Adjustable

Table Diameter
200 mm

Gear Type Supported
Spur, helical, internal and external

Control Panel
Manual

Max Gear Width
50 mm

Main Motor
3.76 kW

Number of Strokes per Minute
70-720

Work Table Bore Diameter
72 mm

Max Cutting Stroke
90 mm

TOS 200 mm Diameter Gear Shaper Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS 200 mm Diameter Gear Shaper Machine

Make - TOS (Czech Republic)

Model - OH 4

Max. Module - 4 module

Max. Diameter of the Gear - 200 mm

Max. Width of the Gear - 40 mm

Stroke Rate - 224 strokes/min to 630 strokes/min

Max. Cutter Diameter - 4"

- Complete with spare Cams, Change Gears, Mandrels etc.

- Operating Manual, Electrical Drawings, etc. are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/ed55mfZXYn0

Versatile Gear Cutting for Multiple Applications

This gear shaper machine excels in manufacturing various gear types including spur, helical, internal, and external gears. Its adjustable stroke, feed rate, and spindle speed allow users to tailor the machining process for precise, high-quality output, whether for batch production or one-off components.

Robust Build With High Precision

Featuring a strong construction and weighing approximately 3000 kg, the machine maintains stability during operation. Its manual control panel and semi-automatic design provide both reliability and accuracy, ideal for demanding gear shaping tasks in industrial settings.

Adaptable for Diverse Production Needs

With a maximum cutting stroke of 90 mm and a gear width capacity of 50 mm, the TOS gear shaper accommodates a wide range of gear sizes. The machines variable speed and adjustable feed rate support different materials and complex gear profiles required by manufacturers and exporters.

FAQs of TOS 200 mm Diameter Gear Shaper Machine:

Q: How is the TOS 200 mm Diameter Gear Shaper Machine operated?

A: The machine operates via a manual control panel and semi-automatic mechanisms, allowing users to adjust the feed rate, spindle speed, and cutting parameters for optimal gear shaping results.

Q: What types of gears can be shaped using this machine?

A: It supports the shaping and cutting of spur, helical, internal, and external gears, providing flexibility for a variety of gear manufacturing projects.

Q: Where is this gear shaper machine typically used?

A: It is commonly used in gear manufacturing facilities, export and import workshops, and by suppliers or traders in industrial settings, especially those requiring high precision and robust gear machining.

Q: What process does this machine utilize for gear cutting?

A: The machine employs a reciprocating shaping mechanism, with adjustable strokes (up to 90 mm), feeding the cutter into the workpiece to accurately create the desired gear profile.

Q: When should I choose this machine over other gear shaping options?

A: Choose the TOS 200 mm model when you require versatile gear cutting capabilities, durable operation for high-precision work, and the ability to process up to 200 mm diameter gears with modules up to 6 mm.

Q: What benefits does the TOS gear shaper offer for manufacturers?

A: Manufacturers benefit from its high precision, adjustable settings for variable batch sizes, robust design for consistent output, and versatility to handle different gear types and dimensions.
