TOS 300 mm x 1000 mm Surface Grinding Machine

Send Inquiry

Request To Call Back

TOS 300 mm x 1000 mm Surface Grinding Machine

Name: TOS 300 mm x 1000 mm Surface Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 300 mm x 1000 mm Surface Grinding Machine Specification

Rotation
Clockwise

Model
TOS 300 x 1000

Product Type
Surface Grinding Machine

General Use
Surface Grinding of metal parts

Material
Cast Iron, Alloy Steel

Type
Horizontal

Capacity
Heavy Duty

Weight (kg)
3800 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
300 mm x 1000 mm

Table Slide Way
V & Flat ways

Magnetic Chuck Size
300 mm x 1000 mm

Grinding Wheel Size
350 mm x 50 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
1000 mm

Floor Space
2700 mm x 1600 mm

Fuel Tank Capacity
60 L (Hydraulic oil) approx.

Spindle Speed
2800 RPM

Power
7.5 HP

Voltage
415 V

Dimension (L*W*H)
2700 mm x 1600 mm x 1800 mm

Feature
Precision Grinding, Robust Construction

Color
Standard Green & White

Table Load Capacity
800 kg

Machine Accuracy
0.002 mm over full length

Longitudinal Table Travel
1100 mm

Coolant System
Integrated with pump

Cross Table Travel
350 mm

Max Work Piece Height
400 mm

Main Motor
7.5 HP high efficiency

Grinding Head Type
Heavy duty, rigid

Hydraulic System Type
Heavy duty with filtration

Machine Construction
High-grade rigid cast iron for vibration absorption

Vertical Feed Graduation
0.01 mm

Lubrication
Centralized automatic lubrication

Table Speed
Variable, up to 25 m/min

TOS 300 mm x 1000 mm Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS 300 mm x 1000 mm Surface Grinding Machine

Make - TOS (Czech Republic)

Model - BPH 300

Magnet Size - 300 mm x 1000 mm

Cross & Longitudinal Travels - 335 mm x 1060 mm

Grinding Wheel Size - Diameter 250 mm x 25 mm Width

Max. Distance between Magnet Top & Wheel-Axis - 375 mm

- Complete with Coolant Tank and Pump.

- Operating Manual & Electrical Drawings are available.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/5SCSY01neDc

Precision Engineering for Demanding Tasks

The TOS 300 x 1000 Surface Grinding Machine offers outstanding accuracy with a 0.002 mm tolerance over its full length. Its high-grade cast iron construction and robust grinding head ensure stability and precision, making it well-suited for machining tasks where high tolerances and superior surface finishes are mandatory.

Engineered for Efficiency and Performance

With features such as a heavy-duty hydraulic system, automatic centralized lubrication, and a high-efficiency 7.5 HP motor, this machine is optimized for maximum reliability and reduced downtime. An integrated coolant system and filtered hydraulic circuit keep processes smooth, even during extended periods of operation.

FAQs of TOS 300 mm x 1000 mm Surface Grinding Machine:

Q: How does the TOS 300 x 1000 Surface Grinding Machine ensure precision during grinding?

A: The machine features a rigid cast iron body that minimizes vibration, centralized automatic lubrication for consistent movement, and a high-precision grinding head. It achieves an impressive accuracy of 0.002 mm over the full table length.

Q: What is the maximum workpiece size and weight the machine can handle?

A: This surface grinder accommodates workpieces up to 1000 mm in length, 300 mm in width, and 400 mm in height, with a maximum table load capacity of 800 kg.

Q: Where is the TOS 300 x 1000 typically used?

A: This model is widely used by metalworking shops, manufacturing plants, and machinery companies, especially for finishing large, heavy components requiring superior surface smoothness and dimensional accuracy.

Q: What benefits does the integrated coolant system provide?

A: The built-in coolant system with a pump efficiently cools the workpiece and grinding wheel, preventing heat build-up, maintaining accuracy, and prolonging both tool and workpiece life.

Q: How user-friendly is the control system of the TOS 300 x 1000?

A: It features a manual, non-CNC control system designed for reliability and ease of operation, making it straightforward to manage even complex surface grinding tasks.

Q: What is the process for lubricating the moving parts of the machine?

A: A centralized automatic lubrication system ensures all critical components receive precise lubrication on schedule, reducing wear and extending machine lifespan.
