TOS 3000 mm x 400 mm Vertical Surface Grinder

Send Inquiry

Request To Call Back

TOS 3000 mm x 400 mm Vertical Surface Grinder

Name: TOS 3000 mm x 400 mm Vertical Surface Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 160000 INR
Availability: InStock

Price 160000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 3000 mm x 400 mm Vertical Surface Grinder Specification

Rotation
Manual and Hydraulic

Model
TOS 3000 x 400

Product Type
Vertical Surface Grinder

General Use
Precision Surface Grinding of Large Workpieces

Material
Cast Iron + Alloy Steel

Type
Heavy Duty

Capacity
Up to 3000 mm length

Weight (kg)
9350

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Conventional

Table Size
3000 mm x 400 mm

Table Slide Way
Hydraulic

Magnetic Chuck Size
3000 mm x 400 mm

Grinding Wheel Size
350 mm x 50 mm x 127 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
3000 mm

Floor Space
5500 mm x 2200 mm x 2400 mm

Fuel Tank Capacity
55 L

Spindle Speed
1450 RPM

Power
15 HP

Voltage
415 V / 50 Hz

Dimension (L*W*H)
5500 mm x 2200 mm x 2400 mm

Feature
High Precision, Robust Construction, Hydraulic Table Movement

Color
Industrial Grey-Green

Max Height of Workpiece
600 mm

Table Longitudinal Travel
3100 mm

Noise Level
Below 75 dB

Max Distance Center of Spindle to Table
625 mm

Spindle Motor Power
15 HP

Table Cross Travel
420 mm

Working Speed
Variable

Minimum Feed
0.003 mm

Wheel Head Motor
15 HP

Table Speed
3~25 m/min (adjustable)

Coolant System
Provided

Grinding Accuracy
±0.01 mm

Lubrication System
Centralized

Work Head
Adjustable

TOS 3000 mm x 400 mm Vertical Surface Grinder About

Make - TOS (Czech Republic)

Model - BPV 40

Magnet Size - 3000 mm x 400 mm

Wheel Cup Diameter - 500 mm

No. of Segments in Wheel - 8 pcs.

Max. Height of Job - 400 mm

- Automatic Depth Adjustment "Auto-Cut".

- Automatic Taper Angle Adjustment of Wheel Head.

- Motorised Rapid Vertical Travel of Head (2 Speeds).

- With coolant tank, pump and all covers etc. etc.

- Machine is in excellent working condition.

Video link - https://youtu.be/KmJc7gJKbEo

Exceptional Grinding Precision and Capacity

The TOS 3000 x 400 Vertical Surface Grinder offers an impressive grinding accuracy of 0.01 mm, ensuring precision for demanding industrial requirements. Its large table size and magnetic chuck accommodate workpieces up to 3000 mm in length, making it ideal for heavy-duty applications. The semi-automatic control and robust construction provide dependable operation even in rigorous manufacturing environments.

Robust Hydraulic Table Movement

The hydraulic table slide way delivers smooth and consistent longitudinal and cross travel, enhancing productivity and surface finish quality. Variable table speed settings enable operators to adjust grinding parameters for different materials and components, supporting flexible and efficient production workflows. Centralized lubrication further ensures the longevity of key moving parts.

User-Friendly Operation and Maintenance

The TOS surface grinder features a conventional control system with both manual and hydraulic rotation capabilities for easy and precise adjustments. Maintenance is simplified by the centralized lubrication system and accessible coolant reservoir, helping reduce downtime and operating costs. Its low noise emissions foster a comfortable working environment for operators.

FAQs of TOS 3000 mm x 400 mm Vertical Surface Grinder:

Q: How does the TOS 3000 x 400 Vertical Surface Grinder ensure high precision during use?

A: The grinder achieves high precision through its robust cast iron construction, adjustable work head, hydraulic table movement, and fine feeding capability as low as 0.003 mm. Its grinding accuracy is maintained at 0.01 mm, making it suitable for industrial applications requiring tight tolerances.

Q: What is the typical process for surface grinding large workpieces on this machine?

A: Operators place the workpiece on the magnetic chuck and select the appropriate table speed and feed settings. The hydraulic table facilitates smooth longitudinal and cross travel while the coolant system keeps temperatures stable. Manual and hydraulic controls allow for precise adjustment of table and spindle positions during grinding.

Q: Where is the TOS 3000 x 400 Vertical Surface Grinder best utilized?

A: This machine is ideal for manufacturing plants, industrial workshops, and facilities specializing in heavy-duty and precision metalworking. Its large capacity and rugged design support the grinding of sizeable components, making it suitable for exporters, importers, manufacturers, suppliers, and traders.

Q: What materials can be processed with this surface grinder?

A: Thanks to its powerful motor, robust construction, and adjustable feed rates, the grinder can handle a wide range of materials, including cast iron, alloy steel, and other metals commonly used in industrial applications.

Q: How does the grinder benefit operational efficiency and safety?

A: The centralized lubrication and coolant system reduce wear and heat build-up, extending component life and minimizing downtime. Low noise emission below 75 dB helps maintain a safer and comfortable workplace, while the semi-automatic controls simplify operation and help prevent errors.

Q: Is any special training required to operate the TOS 3000 x 400 grinder?

A: Basic knowledge of conventional surface grinding and hydraulic systems is recommended. While the control system is user-friendly, operators should be trained in safe machine handling, workpiece setup, and regular maintenance procedures to maximize precision and safety.
