TOS FGSV 50 Heavy Duty Vertical Milling Machine

Send Inquiry

Request To Call Back

TOS FGSV 50 Heavy Duty Vertical Milling Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS FGSV 50 Heavy Duty Vertical Milling Machine Specification

Rotation
Vertical

Model
FGSV 50

Product Type
Vertical Milling Machine

General Use
Heavy Duty Vertical Milling

Material
Cast Iron

Type
Vertical

Capacity
Heavy Duty

Weight (kg)
Approx. 3000 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1400 x 320 mm

Table Slide Way
Box Type

Magnetic Chuck Size
400 x 160 mm

Grinding Wheel Size
200 mm

Grinding Wheel Speed
2800 rpm

Grinding Length
500 mm

Floor Space
2400 x 1650 mm

Spindle Speed
561800 rpm (16 steps)

Power
5 HP main motor

Voltage
380V / 415V

Dimension (L*W*H)
2400 x 1650 x 2000 mm

Feature
Precision Milling, Rigid Structure

Color
Green

TOS FGSV 50 Heavy Duty Vertical Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS FGSV 50 Heavy Duty Vertical Milling Machine

Make - TOS Kurim (Czech Republic)

Model - FGSV 50

Table Size - 1800 mm x 630 mm

XYZ Travel - 1400 mm x 690 mm x 490 mm

Spindle Speeds - 45 rpm to 1400 rpm

Spindle Taper - ISO 50

Feed Travel Rates - 10 mm/min to 1800 mm/min

Weight of Machine - 6.5 tons (Approx)

- Equipped with 3-Axis DRO.

- With Automatic Hydraulic Clamping of the Tool-Holder.

- It is a Heavy-Duty Pure Vertical Milling Machine.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/5pTxL7bgB54

Precision and Performance for Heavy Duty Milling

The TOS FGSV 50 stands out for its robust construction and outstanding accuracy. Its ISO 40 spindle taper and 16-step speed range ensure flexibility for a variety of heavy-duty operations. The rigid box-type slideway enhances stability, while the powerful main motor delivers consistent milling and grinding performance, maximizing both productivity and reliability.

Versatile Travel and Table Capacity

Featuring substantial travel dimensionslongitudinal (1000 mm), cross (350 mm), and vertical (420 mm)the FGSV 50 accommodates large workpieces with ease. The spacious 1400 x 320 mm table and integrated magnetic chuck allow for flexible fixturing and efficient workflow, whether youre milling or grinding.

Built for Longevity and Operator Efficiency

Constructed from durable cast iron and equipped with centralized automatic lubrication, the FGSV 50 minimizes maintenance needs. The ergonomic manual controls facilitate precise adjustments, while advanced safety and reliability features provide peace of mind for operators in demanding industrial settings.

FAQs of TOS FGSV 50 Heavy Duty Vertical Milling Machine:

Q: How does the TOS FGSV 50 ensure precision during milling and grinding operations?

A: The TOS FGSV 50 utilizes a rigid cast iron frame, box-type slideways, and an ISO 40 spindle to minimize vibration and maintain precise alignment. The 16-step variable spindle speed and heavy-duty construction further contribute to high-accuracy results.

Q: What materials and workpiece sizes are suitable for this milling machine?

A: Designed to handle heavy-duty tasks, the FGSV 50 is suitable for various metals, including steel, iron, and alloys. The large table (1400 x 320 mm) and travel ranges accommodate sizable workpieces, making it ideal for industrial fabrication and machining workshops.

Q: When should the centralized automatic lubrication system be checked or serviced?

A: The centralized automatic lubrication system is designed for minimal maintenance; however, it is recommended to inspect the lubrication reservoir and distribution lines during scheduled maintenance intervals or whenever you notice irregularities in machine performance.

Q: Where can the TOS FGSV 50 be installed for optimal performance?

A: The ideal environment is a well-leveled industrial workshop or factory floor with adequate space (minimum 2400 x 1650 mm) to accommodate the machines footprint and allow for operator movement and safe loading/unloading of workpieces.

Q: What is the process for changing spindle speeds on this manual milling machine?

A: Spindle speed changes are performed manually via the control levers, enabling operators to choose from 16 available speed steps (561800 rpm) based on the specific requirements of each milling or grinding task.

Q: How does the operator benefit from the machines control system and safety features?

A: The FGSV 50s simple manual control system allows for intuitive operation and quick adjustments, while its robust build, reliable Siemens/Bharat Bijlee motor, and centralized lubrication system help minimize risk and downtime.

Q: What are the primary benefits of using this vertical milling machine over CNC or computerized options?

A: While not CNC, the manual TOS FGSV 50 delivers precise and reliable results for heavy-duty applications, offering lower upfront cost, easier maintenance, and straightforward operation for skilled machinists who require flexibility and direct control.
