TOS SUI 50 2000 mm Lathe Machine

Name: TOS SUI 50 2000 mm Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS SUI 50 2000 mm Lathe Machine Specification

Product Type
Universal Lathe Machine

Material
Cast Iron Body

Cutting Thickness
Up to 8 mm (depending on tool and material)

Cutting Speed
Variable, up to 2000 RPM

CNC Or Not
No (Conventional Lathe)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
500 mm

Voltage
415 V, 3 Phase

Weight (kg)
3030 kg

Dimension (L*W*H)
3170 mm x 1130 mm x 1530 mm

Capacity
Maximum turning length 2000 mm

Feature
Hardened bed ways, Precision ground gears, Gearbox with wide speed range

Color
Standard Grey with Blue Accents

Tailstock Quill Travel
180 mm

Longitudinal Feed Range
0.05 1.4 mm/rev

Distance Between Centers
2000 mm

Cross Slide Travel
320 mm

Tailstock Quill Diameter
70 mm

Lead Screw Diameter
40 mm

Spindle Nose
Camlock DIN 55029

Chuck Size
315 mm

Main Motor Power
7.5 HP (5.5 kW)

Bed Width
350 mm

Floor Space Required
Approx. 3500 mm x 1300 mm

Thread Cutting Range (Inch)
72 0.5 TPI

Thread Cutting Range (Metric)
0.5 72 mm

Coolant System
Yes

Spindle Bore
56 mm

TOS SUI 50 2000 mm Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS SUI 50 2000 mm Lathe Machine

Make - TOS (Czech Republic)

Model - SUI 50

Center Height - 255 mm

Max. Length of Job - 2000 mm

Max. Diameter of Job over Bed - 500 mm

Max. Diameter over Cross-Slide - 320 mm

Max. Swing Diameter near Chuck - 560 mm

Spindle Speeds - 14 rpm to 2240 rpm

Bed Width - 360 mm

Chuck Diameter - 250 mm

Spindle Bore - 56 mm

- With Motorised Rapid Travels on the Carriage & Cross-Slide.

- Operating Manual of the machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/9AIxeaG5-DY

Precision Engineering and Durable Construction

The TOS SUI 50 Lathe Machine is engineered for high precision and long-lasting use. Constructed with a cast iron body and featuring hardened ways, this machine ensures both stability and accuracy during operations. The variable speed control, spacious bed width, and precision-ground gears make it suitable for a variety of heavy-duty metalworking tasks.

Flexible Operations and Wide Application

Thanks to its 7.5 HP main motor and semi-automatic grade, the SUI 50 lathe supports a wide range of turning and threading processes, accommodating both metric and inch threads. With a maximum swing diameter of 500 mm and a cutting thickness up to 8 mm, this lathe suits diverse industrial needs such as manufacturing, exporting, and trading.

FAQs of TOS SUI 50 2000 mm Lathe Machine:

Q: How do I set up the TOS SUI 50 Lathe Machine in my workshop?

A: Ensure you allocate a dedicated floor space of approximately 3500 mm x 1300 mm for the machine. The lathe operates on a 415 V, 3 Phase power supply. Make sure the surface is level and all connections, especially for coolant and power, are secure before commencing operation.

Q: What materials can be machined using the SUI 50 Lathe?

A: The machine is designed for machining various metals, including mild steel, alloy steel, and cast iron. The maximum cutting thickness depends on the tool and material, but it can handle up to 8 mm efficiently.

Q: Where is the TOS SUI 50 Lathe Machine manufactured and supplied from?

A: The TOS SUI 50 Lathe Machine is manufactured in the Czech Republic and is available for export, import, and supply through recognized traders and distributors globally.

Q: What are the main benefits of using the SUI 50 Lathe for industrial tasks?

A: Users benefit from high accuracy due to precision-ground gears and hardened bed ways, flexible feed and threading options, and a durable cast iron body. The semi-automatic operation and variable speed capability enhance productivity across different applications.

Q: How is thread cutting achieved on this lathe?

A: The lathe features a wide threading range, allowing users to cut both metric threads (0.5 72 mm) and inch threads (72 0.5 TPI) by manually adjusting the gearbox and lead screw, ensuring versatile and precise thread production.

Q: When should the coolant system be used during operations?

A: The integrated coolant system should be activated during heavy or prolonged cutting to maintain tool life, improve surface finish, and prevent material overheating.

Q: What is the recommended process for routine maintenance of the SUI 50 Lathe?

A: Regularly check lubrication levels, inspect gears and bed ways for wear, and clean the machine after each use. Routine maintenance ensures consistent performance and extends machine longevity.
