UPAM UP2 Bandsaw Machine
UPAM UP2 Bandsaw Machine

UPAM UP2 Bandsaw Machine

Price 1100 USD ($)/ Piece

MOQ : 1 Piece

UPAM UP2 Bandsaw Machine Specification

  • Voltage
  • 220V / 415V (Single or Three Phase)
  • Power Rating
  • 0.75 kW
  • Noise Level
  • Low
  • Drive
  • Belt Drive
  • Accuracy
  • High Cutting Accuracy
  • Operating Temperature
  • 5°C to 45°C
  • Lubricating System
  • Manual Lubrication
  • Model No
  • UPAM UP2
  • Control System
  • Manual Controls
  • Production Capacity
  • Up to 70 mm stroke
  • Features
  • Compact Design, Easy Blade Change, Sturdy Frame
  • Machine Type
  • Bandsaw
  • Cooling System
  • Integrated Coolant Pump
  • Frequency
  • 50 Hz
  • Motor Power
  • 1 HP
  • Frame Type
  • Rigid/Heavy Duty
  • Product Type
  • Bandsaw Machine
  • Technology
  • Conventional Bandsaw Cutting
  • Power Source
  • Electric
  • Operating Type
  • Semi-Automatic
  • Power
  • 1 HP
  • Pressure
  • Manual Operation (Not Pressure Powered)
  • Surface Treatment
  • Paint Coated
  • Dimension (L*W*H)
  • Approx. 1000 x 600 x 1200 mm
  • Weight (kg)
  • Approx. 150 kg
  • Color
  • Blue & White
  • Usage & Applications
  • Cutting Metal Bars, Pipes, Rods, and Sections
  • Clamping Mechanism
  • Manual Vice
  • Safety Features
  • Emergency Stop Switch, Protective Blade Guard
  • Suitable Materials
  • Mild Steel, Stainless Steel, Alloy Steel
  • Saw Blade Size
  • 3500 mm x 27 mm x 0.9 mm
  • Main Spindle Speed
  • Adjustable via pulley
  • Installation Type
  • Floor Mounted
  • Blade Material
  • High-Speed Steel
  • Operator Interface
  • Push Button Start/Stop
  • Blade Speed Adjustment
  • Variable (Multi-Speed Pulley)
  • Max Cutting Diameter
  • 200 mm
  • Cutting Angle
  • 90 (Straight Cut)
  • Table Size
  • 600 mm x 350 mm



About UPAM UP2 Bandsaw Machine



  • Make - UPAM (Italy)
  • Model - UP2
  • Capacity for Round - 300 mm Dia.
  • Capacity for Flat - 400 mm Width x 300 mm Height
  • Downward Feed - Hydraulic
  • Cutting Angle -  0 to 45
  • Complete with coolant pump.
  •  Machine is in excellent working condition.



Video Link - https://youtu.be/R4WiUCkVFUo



Precision Metal Cutting for Industry

The UPAM UP2 Bandsaw Machine delivers accurate and efficient metal cutting, suitable for various industrial applications. With a 200 mm maximum cutting diameter and a rigid frame, it effortlessly handles mild steel, stainless steel, and alloy steel, making it indispensable in fabrication, manufacturing, and metalworking shops.


Compact and Operator-Friendly Design

Designed with user convenience in mind, the UPAM UP2 features a space-saving layout. The intuitive push-button start/stop, manual controls, and easy blade changing system streamline daily operations, ensuring minimal downtime and enhanced productivity for operators of all levels.


Safety and Durability as Priorities

Safety mechanisms such as the emergency stop switch and protective blade guard are integral to the UP2 Bandsaw, providing peace of mind during use. Its sturdy, paint-coated frame withstands rigorous environments, while the adjustable spindle speed and robust clamping system maintain prolonged operational stability.

FAQs of UPAM UP2 Bandsaw Machine:


Q: How do I adjust the cutting speed of the UPAM UP2 Bandsaw Machine?

A: You can change the blade speed using the variable multi-speed pulley system. Simply shift the drive belt among the pulleys to achieve the desired blade speed, which is crucial for optimizing cutting performance based on material type and thickness.

Q: What types of materials can the UPAM UP2 Bandsaw cut?

A: This bandsaw is designed for cutting mild steel, stainless steel, and various alloy steels. Its high-speed steel blade and adjustable cutting speed allow efficient and precise sectioning of bars, pipes, rods, and metal profiles.

Q: Where is the UPAM UP2 typically installed and used?

A: The machine is floor-mounted, making it suitable for use in industrial workshops, manufacturing plants, fabrication units, and metalworking facilities. Its compact footprint fits well in various workspaces while maintaining stability during operation.

Q: What safety features are incorporated in the UPAM UP2 Bandsaw Machine?

A: Safety is prioritized with an emergency stop switch and a protective blade guard included as standard. These features help protect users during operation, reducing the risk of accidents and enhancing workplace safety.

Q: What is the process for changing the saw blade on the UPAM UP2 Bandsaw?

A: Changing the blade is straightforward thanks to the easy blade change design. Release the tension, remove the worn blade, and fit a new 3500 mm x 27 mm x 0.9 mm high-speed steel blade, ensuring it is correctly aligned before retensioning.

Q: What are the main benefits of using the UPAM UP2 Bandsaw Machine?

A: Key benefits include high cutting accuracy, efficient and versatile operation, low noise levels, durable construction, safety integration, and easy maintenance. The integrated coolant pump and manual lubrication further enhance performance and longevity.

Tell us about your requirement
product

Price:

Quantity
Select Unit

  • 50
  • 100
  • 200
  • 250
  • 500
  • 1000+
Additional detail
Mobile number

Email

More Products in Miscellaneous Machines Category

Gloria Super Italy Automatic Pitch Controlled Tapping Machine

Gloria Super Italy Automatic Pitch Controlled Tapping Machine

Price 100000 INR / Piece

Minimum Order Quantity : 1 Piece

Color : Blue & Silver

Usage & Applications : Thread cutting, Metal fabrications

Features : Adjustable pitch, precision threading, robust frame

Operating Type : Other, SemiAutomatic

Piesok NPM-10 Ironworker Machine
