Voumard 5A Internal Grinder

Price 9800 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Voumard 5A Internal Grinder Specification

Model
Voumard 5A

Rotation
Clockwise & Anti-clockwise

Product Type
Internal Grinder

General Use
Precision internal grinding of cylindrical and conical bores

Material
Cast Iron

Type
Universal

Capacity
50mm Maximum Dia

Weight (kg)
2000 kg Approx

Computerized
No

Automatic
No

CNC Or Not
No

Control System
Manual

Table Size
220 x 800 mm

Table Slide Way
V-flat

Magnetic Chuck Size
200 mm

Grinding Wheel Size
Max. 300 mm

Grinding Wheel Speed
19,000 rpm

Grinding Length
150 mm

Floor Space
2000 x 1700 mm

Spindle Speed
400 - 12000 rpm (work head)

Power
3 HP

Voltage
415 V

Dimension (L*W*H)
2000 x 1700 x 1800 mm

Feature
Rigid construction; High accuracy

Color
Green

About Voumard 5A Internal Grinder

Make - Voumard (Switzerland)

Model - 5A

Grinding Diameter - 5 mm to 200 mm

Center Height - 180 mm

Max. Swing Diameter of Job - 360 mm

Grinding Depth - 250 mm

Maximum Table Stroke - 600 mm

Spindle Speeds - 3,600 rpm to 40,000 rpm

Work-Head Speeds - 125 rpm to 1,000 rpm

Work-Head Swivel - 0 Degree to 90 Degree

- Equipped with Face Grinding Attachment.

- Equipped with a Hydraulic Wheel-Dresser.

- Working in Auto Cycle.

- Operating Manual & Electrical Drawings available.

- Machine is in excellent working condition.

Video link - https://youtu.be/CaaocsjOt5E

Precision Internal Grinding Performance

The Voumard 5A Internal Grinder is engineered for exceptional performance in high-accuracy grinding of cylindrical and conical bores. Its robust design and variable working speeds make it suitable for various industrial requirements, especially where precise machining of internal surfaces is essential. With a maximum grinding diameter of 50 mm and workpiece weight of up to 30 kg, this manual machine delivers consistent results for heavy-duty manufacturing settings.

User-Friendly and Manual Control System

Equipped with a manual control system, the Voumard 5A provides complete operator oversight during the grinding process. This non-CNC, non-computerized design allows for tactile precision and adaptability, enabling skilled users to achieve optimal finishes. The machine is suitable for workshops where manual adjustment is favored over automation, without compromising performance.

Durability and Rigid Construction

Built with high-quality cast iron and a robust frame, the Voumard 5A is designed for longevity in demanding workshop environments. Its V-flat table slideway, rigid structure, and precision engineering contribute to minimal vibration, allowing for reliable, repeatable high-accuracy grinding. The built-in coolant system ensures components stay within optimal operating temperatures, extending machine life and improving workpiece quality.

FAQs of Voumard 5A Internal Grinder:

Q: How is the Voumard 5A Internal Grinder operated?

A: The Voumard 5A is operated manually, providing the user with direct control over each aspect of the grinding process. It does not use CNC or computerized controls, making it ideal for operators who prefer hands-on precision.

Q: What types of components can be processed with this grinder?

A: This machine is suitable for high-precision internal grinding of cylindrical and conical bores on workpieces up to 30 kg in weight and 50 mm in diameter, commonly used in the production of component parts across various industries.

Q: When should I use the coolant system during grinding operations?

A: The coolant system should be used during all grinding operations to control temperature, reduce wear on grinding wheels and quills, and ensure superior surface finish accuracy on workpieces.

Q: Where is the Voumard 5A commonly installed or used?

A: The Voumard 5A Internal Grinder is typically found in manufacturing plants, tool rooms, and precision engineering workshops internationally, including exporters, importers, manufacturers, suppliers, and traders in Swaziland and beyond.

Q: What is the process for adjusting grinding speeds on this model?

A: Grinding and spindle speeds can be manually adjusted using the machines control mechanisms. The wheelhead spindle supports up to 19,000 rpm, and the work head spindle speeds vary from 400 to 12,000 rpm, allowing you to tailor operation for different materials and requirements.

Q: How does the Voumard 5A benefit my production processes?

A: With its rigid construction, high speed capability, and precise manual control, the Voumard 5A enables enhanced accuracy, improved workflow flexibility, and reliable performance, lowering downtime and maintenance needs.
