WMW 630 mm Vertical Rotary Surface Grinder

Send Inquiry

Request To Call Back

WMW 630 mm Vertical Rotary Surface Grinder

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WMW 630 mm Vertical Rotary Surface Grinder Specification

Rotation
Rotary table

Model
WMW 630 mm Wheel

Product Type
Rotary Surface Grinder

General Use
Industrial surface grinding

Material
Cast Iron, Steel

Type
Vertical

Capacity
Heavy Duty

Weight (kg)
Approx. 6500 kg

Computerized
No

Automatic
No, manual operation

CNC Or Not
Not CNC

Control System
Manual

Table Size
630 mm diameter

Table Slide Way
Hydraulic

Magnetic Chuck Size
630 mm

Grinding Wheel Size
500 mm

Grinding Wheel Speed
1450 rpm

Grinding Length
Up to 630 mm

Floor Space
Approx. 2500 x 2200 mm

Fuel Tank Capacity
100 liters

Spindle Speed
1450 rpm

Power
12 kW

Voltage
415 V

Dimension (L*W*H)
2500 mm x 2200 mm x 2000 mm

Feature
High precision, robust body, magnetic table

Color
Industrial Blue

Chuck Type
Electromagnetic

Table Motor
2.2 kW

Surface Finish Accuracy
Up to 0.02 mm

Lubrication
Automatic central lubrication

Cooling System
Integrated coolant tank and pump

Max Table Load Capacity
800 kg

Working Speed
Variable

Application
Tool room, Production floor, Heavy engineering

Max Grinding Height
300 mm

Noise Level
<75 dB

Installation Requirement
Concrete foundation recommended

WMW 630 mm Vertical Rotary Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About WMW 630 mm Vertical Rotary Surface Grinder

Make - WMW (Germany)

Model - BRW-63

Magnetic Table Diameter - 630 mm

Segmented Cup Wheel Diameter - 400 mm

Wheel Type - Segmented ; 8 pcs.

Max. Height of Job - 350 mm

Magnet Type - Electro-Magnet

- Motorized Rapid Vertical Travel of Wheel-Head.

- Hydraulic Rapid Forward & Backward Movement of Table.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/MBqRT3jJXwA

High Precision and Reliability

This grinder delivers remarkable precision and repeatability, with a surface finish accuracy as fine as 0.02 mm. Its durable design handles heavy-duty workloads with a maximum table load capacity of 800 kg. Built from top-quality cast iron and steel, it minimizes vibration, ensuring consistent performance for both tool rooms and production floors.

Efficient Manual Operation

Designed for manual control, the machine enables operators to fine-tune settings to meet diverse grinding requirements. A variable working speed and hydraulic table slide way optimize performance for various workpiece materials and thicknesses. With an automatic central lubrication system and integrated coolant supply, the machine remains efficient even during prolonged operations.

Safety and Installation

With a noise output maintained below 75 dB and an automatic lubrication system, the grinder prioritizes both operator comfort and machine longevity. For optimal stability during use, a concrete foundation is recommended. The electromagnetic chuck and robust structural design support safe, efficient, and secure operation in any industrial environment.

FAQs of WMW 630 mm Vertical Rotary Surface Grinder:

Q: How does the integrated coolant system benefit the grinding process?

A: The integrated coolant tank and pump ensure efficient heat dissipation during prolonged grinding, reduce thermal distortion, and help maintain precision while prolonging both workpiece and grinding wheel life.

Q: What materials can be processed with the WMW 630 mm Vertical Rotary Surface Grinder?

A: This machine is suitable for grinding cast iron, steel, and other hard metals commonly used in tool rooms, production lines, and heavy engineering environments.

Q: Where should the WMW 630 mm Grinder be installed for optimal performance?

A: For maximum stability and precision, installation on a concrete foundation is recommended, particularly due to its heavy duty weight and load capacity.

Q: What is the recommended usage process for this grinder?

A: Secure the workpiece on the electromagnetic chuck, adjust the manual controls for speed and grinding height, activate the coolant and lubrication systems, and then proceed with surface grinding to achieve the desired finish.

Q: When is it necessary to use the automatic lubrication system?

A: The automatic central lubrication system runs continuously during operation, ensuring all key moving parts are properly lubricated for optimal performance and reduced wear.

Q: How does the electromagnetic chuck enhance the grinding process?

A: The electromagnetic chuck allows for rapid, secure clamping and releasing of ferrous workpieces, providing a stable surface and improving both safety and operational efficiency during grinding.
