WMW 80 mm Capacity Drilling and Tapping Machine

Name: WMW 80 mm Capacity Drilling and Tapping Machine
Brand: Liberty Metal & Machines Private Limited
Price: 40000 INR
Availability: InStock

Price 40000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WMW 80 mm Capacity Drilling and Tapping Machine Specification

Frequency
50 Hz

Features
High Rigidity, Precision Machined, Heavy-Duty Construction

Motor Power
7.5 HP

Noise Level
Less than 80 dB

Machine Type
Heavy Duty Column Type

Dimension (L*W*H)
3200 x 1000 x 2500 mm

Cutting Area
600 mm x 800 mm

Spindle Speed
16 Steps, 32 - 1600 RPM

Table Size
800 x 600 mm

Diameter
80 mm (Max. Drill Diameter)

Condition
New

Product Type
Drilling and Tapping Machine

Material
Cast Iron Body with Steel Components

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual Control

Voltage
415 V

Power
7.5 HP

Power Source
Electric

Weight (kg)
Approx. 2000 kg

Capacity
80 mm Drilling, Tapping up to M60

Color
Industrial Blue & Grey

Usage & Applications
Industrial Drilling and Tapping Operations

Base Size
1000 x 700 mm

Main Drive Motor
7.5 HP, 3 Phase

Max Distance from Spindle Nose to Table
700 mm

Quill Feed
Manual & Power

Coolant System
Yes, Inbuilt

Tapping Capacity
Up to M60

Worktable Movement
300 mm (Vertical)

Number of Spindle Speeds
16

Column Diameter
250 mm

Spindle Travel
250 mm

Throat Depth
420 mm

WMW 80 mm Capacity Drilling and Tapping Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About WMW 80 mm Capacity Drilling and Tapping Machine

Make - WMW (Germany)

Model - BK 5 AI

Drilling Capacity - 80 mm

Tapping Capacity - 50 mm

Spindle Taper - MT 5

Spindle Feed Travel - 280 mm

Spindle Speeds - 32 rpm to 1400 rpm

Feed Rate of Travel - 0.11 mm/rev to 1.73 mm/rev

Table Size - 625 mm x 500 mm

Spindle Diameter - 85 mm

Distance between Spindle Center to Vertical Column - 355 mm

Max. Height between Spindle to Table Top - 750 mm

Max. Height between Spindle to Base Top - 1200 mm

- Features like Automatic Tapping, Automatic Reaming etc.

- Motorised Up/Down Movement of Drilling Head.

- Complete with Coolant Tank and Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/SCMEqUM6FQM

Precision and Power in Heavy-Duty Operations

Built to deliver unmatched precision, the WMW drilling and tapping machine supports complex industrial applications with its robust 7.5 HP main drive motor, capable of drilling up to 80 mm. The precision-machined cast iron structure ensures stability and reliability during intensive usage, while 16 variable spindle speeds enhance operational versatility for a range of materials and applications.

Versatility and User-Friendly Features

This machine comes equipped with both manual and power quill feed, an inbuilt coolant system, and a semi-automatic control scheme for smooth operation. The generous table and cutting area, along with a 250 mm column diameter, offer flexibility for diverse workpieces, making it indispensable for modern workshops and manufacturing floors.

Quality Construction for Long-Term Performance

Engineered with a heavy-duty column type design and crafted from cast iron and steel, the WMW machine withstands industrial rigors. Its semi-automatic, manually controlled system provides ease of maintenance and minimizes downtime, ensuring long service life. The low noise output demonstrates its suitability for environments where comfort and safety are paramount.

FAQs of WMW 80 mm Capacity Drilling and Tapping Machine:

Q: How does the WMW 80 mm Drilling and Tapping Machine enhance industrial productivity?

A: This machine offers high drilling and tapping capacities (up to 80 mm and M60), multiple spindle speeds, and an inbuilt coolant system, enabling efficient, continuous operations across demanding industrial environments. Its heavy-duty construction allows for precision work with minimal downtime.

Q: What materials can be machined using this equipment?

A: With its robust cast iron body and precision steel components, the WMW machine is suitable for drilling and tapping various metals, including steel and cast iron, making it versatile for both manufacturing and maintenance applications.

Q: When is it best to use the power quill feed rather than manual feed?

A: The power quill feed is ideal for consistent, repetitive drilling or tapping in harder materials, reducing operator fatigue and ensuring uniform results. Manual feed is suitable for delicate operations or when greater control is needed for specific tasks.

Q: Where is the WMW Drilling and Tapping Machine typically deployed?

A: It is widely used in manufacturing plants, heavy machinery workshops, metal fabrication units, and industrial production facilities. Its heavy-duty design and adaptability make it a preferred choice for large-scale operations.

Q: What is the process for changing spindle speeds on this model?

A: Spindle speeds are adjusted via a 16-step manual control system, allowing operators to quickly select the appropriate RPM (ranging from 32 to 1600) for their material and desired finish, optimising performance and tool life.

Q: How does the inbuilt coolant system benefit machining operations?

A: The integrated coolant system helps maintain optimal tool and workpiece temperatures, reduces wear, prevents overheating, and ensures cleaner, more precise machining outcomes, prolonging the life of both tools and workpieces.

Q: What are the key benefits of investing in this machine for industrial purposes?

A: Key benefits include high-capacity drilling and tapping, superior rigidity, low noise levels, flexibility with large workpieces, and reduced operator effort due to its power feeds and ergonomic design. Its durable construction ensures reliability for intensive, long-term usage.
