WMW SI 400 x 500 Heavy Duty Internal Grinder

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WMW SI 400 x 500 Heavy Duty Internal Grinder Specification

Model
SI 400 x 500

Rotation
Yes

Product Type
Internal Grinder

General Use
Heavy Duty Internal Grinding Operations

Material
Cast Iron / Graded Steel

Type
Heavy Duty Industrial

Capacity
400 x 500 mm (Swing x Grinding Length)

Weight (kg)
Approx. 7600 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
No

Control System
Conventional

Table Size
Refer Manufacturer

Table Slide Way
V and Flat Guideways

Magnetic Chuck Size
400 mm

Grinding Wheel Size
400 mm

Grinding Wheel Speed
1200 rpm

Grinding Length
500 mm

Floor Space
~3200 mm x 1960 mm x 1620 mm

Spindle Speed
Variable, up to 1200 rpm

Power
9 kW

Voltage
415 V

Dimension (L*W*H)
3200 x 1960 x 1620 mm

Feature
High Rigidity, Precision Ground Guides, Heavy Duty Design

Color
Manufacturer Standard

WMW SI 400 x 500 Heavy Duty Internal Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About WMW SI 400 x 500 Heavy Duty Internal Grinder

Make - WMW (Germany)

Model - SI 400 x 500

Max. Outside Diameter of Job - 800 mm

Max. Internal Diameter of Job - 400 mm

Max. Grinding Length of Job - 500 mm

Cross Travel of Work-Head - 650 mm

Chuck Diameter - 600 mm

Minimum Internal Diameter of Job - 20 mm

Work-Head Speeds - 16 rpm to 250 rpm

Swivel Angle of Work-Head - 0 Degree to 30 Degree

Least Count - 2.5 Microns (0.0025 mm)

Max. Table Stroke - 650 mm

Spindle Diameter - 100 mm

Weight of the Machine - 5.8 Tons Approximately

- Electrical Drawings are available.

- Hydraulic Rapid Cross Travel of the Work-Head.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/qQNmBebGFVk

Superior Grinding Capacity

Offering a generous workpiece capacity with swing and grinding lengths up to 400 mm and 500 mm, the SI 400 x 500 is designed for heavy-duty internal grinding. It supports grinding diameters ranging from 30 mm up to 250 mm, covering a vast range of industrial needs.

Precision and Efficiency

With high rigidity construction, precision-ground guideways, and advanced hydraulic and lubrication systems, this machine ensures exceptional accuracy and durability. Its semi-automatic operation streamlines workflow without compromising control or consistency.

Versatile Industrial Applications

The WMW SI 400 x 500 excels in precision bore grinding for components made of cast iron or graded steel. Applications span general industrial parts, high-precision assemblies, and demanding environments where consistent, quality finishes are critical.

FAQs of WMW SI 400 x 500 Heavy Duty Internal Grinder:

Q: How does the integral coolant system benefit the grinding process?

A: The integral coolant system helps maintain consistent temperatures, reduces thermal distortion, and removes grinding debris, which in turn extends tool life and ensures a finer surface finish during precision internal grinding operations.

Q: What is the process for adjusting the work head and wheel head movement?

A: The work head can be swiveled +/- 90 for versatile component setups, while the wheel head traverses up to 300 mm. Adjustments are made via conventional controls, allowing operators to align precisely for various bore grinding applications.

Q: When is the WMW SI 400 x 500 most effectively used?

A: This grinder is ideal when high-precision internal bore grinding is required on large or heavy workpieces, particularly for achieving fine surface finishes and strict dimensional tolerances in industrial and manufacturing environments.

Q: Where can the WMW SI 400 x 500 be installed and operated?

A: Designed for industrial settings, this machine requires floor space of approximately 3200 mm x 1960 mm x 1620 mm and access to a 415 V, 10 kVA electrical supply. Its suitable for production floors involved in machining and heavy-duty component manufacturing.

Q: What materials are suitable for grinding using this machine?

A: The SI 400 x 500 is engineered for materials such as cast iron and graded steel, ensuring that it meets the needs of sectors requiring robust, high-precision internal grinding performance.

Q: How does the semi-automatic control improve usability?

A: Semi-automatic controls enable greater operator efficiency by automating key movements while retaining manual adjustment for fine-tuning. This balance helps achieve consistent results without extensive programming or setup.

Q: What are the advantages of the electro-magnetic chuck during grinding operations?

A: The electro-magnetic chuck securely holds ferromagnetic workpieces, minimizing vibration and slippage during internal grinding. This enhances operational safety and enables high-precision results across various component geometries.
