WMW Union BFT 90/3 Horizontal Boring Machine

Send Inquiry

Request To Call Back

WMW Union BFT 90/3 Horizontal Boring Machine

Price 30000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

WMW Union BFT 90/3 Horizontal Boring Machine Specification

Power Rating
12 kW

Production Capacity
Large-scale batch production

Frequency
50 Hz

Operating Temperature
5C to 45C

Features
Heavy-duty frame, high rigidity, multiple spindle speeds, power feed

Drive
Mechanical Gear Drive

Voltage
380 V / 415 V, 3 phase

Control System
Analog Controls

Lubricating System
Centralized automatic lubrication

Motor Power
12 kW

Cooling System
Integrated coolant pump system

Accuracy
0.02 mm

Noise Level
Standard industrial range (<80 dB)

Frame Type
Cast iron structured

Machine Type
Floor type horizontal boring

Model No
BFT 90/3

Product Type
Horizontal Boring Machine

Technology
Conventional Mechanical

Power Source
Electric

Operating Type
Manual / Semi-Automatic

Power
12 kW

Surface Treatment
Painted

Dimension (L*W*H)
Approx. 4000 x 2200 x 2400 mm

Weight (kg)
Approx. 12000 kg

Color
Industrial Blue & Grey

Usage & Applications
Boring, drilling, milling, and reaming of heavy metal workpieces

Quill Stroke
710 mm

Safety Features
Emergency stop, interlocked guards

Table Load Capacity
3,000 kg

Rapid Traverse
2000 mm/min

Number of Feeds
24

Spindle Taper
Morse Taper No.6 / ISO 50

Maximum Table Cross Travel
1000 mm

Working Speed
Table longitudinal travel up to 1250 mm/min

Spindle Speed Range
8 - 1600 rpm

Vertical Travel of Headstock
1100 mm

Condition
Used / Good working condition

Main Construction Material
High-grade cast iron and steel

Spindle Diameter
90 mm

Table Size
1250 x 1120 mm

Feed Range
4 - 630 mm/min

Maximum Table Travel (Longitudinal)
1250 mm

Number of Spindle Speeds
24

WMW Union BFT 90/3 Horizontal Boring Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About WMW Union BFT 90/3 Horizontal Boring Machine

Make - WMW-Union (Germany)

Model - BFT 90/3

Spindle Diameter - 90 mm

Table Size - 1000 mm x 1120 mm

Cross Travel (X Axis) - 1000 mm

Vertical Travel (Y Axis) - 1000 mm

Longitudinal Travel (Z Axis) - 1600 mm

Spindle Travel (W Axis) - 710 mm

Table Rotation (U Axis) - 360 Degrees (Continuous)

Spindle Taper - MT 5

Spindle Speeds - 8 rpm to 1600 rpm

- Complete with Facing Chuck, Tail-Stock, & Milling Head.

- Equipped with Ball-Screws on all the 3-Axis.

- Equipped with 3-Axis DRO.

- Complete with Operating Manuals, Electrical Drawings etc.

- Machine is in excellent working condition.

Video Of The Machine -

https://youtu.be/WRcTk5pbAts

Precision Machining for Demanding Industries

The WMW Union BFT 90/3 Horizontal Boring Machine delivers high performance for applications that require exacting standards. Its advanced mechanical design, 12 kW motor, and large working surface make it suitable for heavy metalworking industries, including automotive, aerospace, and large-scale manufacturing. With accurate positioning, multiple feeds and speeds, and robust safety features, it optimizes production workflows while ensuring operator safety and operational integrity.

User-Friendly Operation and Advanced Safety

This machines intuitive analog controls, manual and semi-automatic operating modes, and mechanical gear drive ensure ease of operation even for complex tasks. Emergency stop, interlocked guards, and centralized auto-lubrication enhance both user safety and equipment lifespan. The system maintains stable performance under various operating conditions (5C45C), making it a practical solution for diverse industrial settings.

FAQs of WMW Union BFT 90/3 Horizontal Boring Machine:

Q: How does the WMW Union BFT 90/3 enhance machining productivity for large workpieces?

A: The machines sizeable table (1250 x 1120 mm) with a load capacity of 3,000 kg, long travel distances, and multiple spindle speeds allow it to handle large and heavy components efficiently. Its rapid traverse and precise feeds contribute to faster cycle times and higher throughput for batch production.

Q: What types of processes can be performed with this horizontal boring machine?

A: The WMW Union BFT 90/3 is suitable for boring, drilling, milling, and reaming operations, making it ideal for multi-functional metalworking tasks. Its high rigidity and variability in spindle speed and feed rates ensure precise machining for a range of applications.

Q: When is it beneficial to use this machine in manufacturing?

A: This horizontal boring machine shows its benefits particularly when working with large, heavy metal pieces requiring high accuracy and repeatabilitycommon in large-scale manufacturing, toolrooms, and repair workshops needing versatility and robust construction.

Q: Where should the WMW Union BFT 90/3 ideally be installed?

A: Given its substantial dimensions (4000 x 2200 x 2400 mm) and weight (~12,000 kg), the machine is best installed in spacious, well-ventilated industrial environments with proper electrical infrastructure (380 V / 415 V, 3-phase).

Q: What is the process for operating this machine safely and efficiently?

A: Operators should follow standard guidelines: secure workpieces, select suitable spindle speeds and feeds using analog controls, and ensure guards and safety features are engaged. Regular maintenance, such as checking lubrication and cooling systems, is vital for continued safe, efficient operation.

Q: How does the integrated lubrication and cooling system benefit users?

A: The centralized automatic lubrication and integrated coolant pump help maintain optimal operating temperatures and reduce wear on moving parts, increasing accuracy, reducing downtime, and extending the machines service life.
