XYZ England 1000 mm Lathe Machine

Name: XYZ England 1000 mm Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

XYZ England 1000 mm Lathe Machine Specification

Product Type
Manual Lathe Machine

Material
Cast Iron, Mild Steel

Cutting Thickness
Up to 12 mm

Cutting Speed
35-2000 RPM

CNC Or Not
No, Conventional

Automatic Grade
Manual

Control System
Manual Gearbox

Max. Swing Diameter
400 mm

Voltage
415 V, 3 Phase

Weight (kg)
Approx. 850 kg

Dimension (L*W*H)
1900 mm x 750 mm x 1200 mm

Capacity
1000 mm between centers

Feature
High Precision, Rigid Construction

Color
Machine Gray

Spindle Bore
52 mm

Distance Between Centers
1000 mm

Application
Turning, Facing, Threading, Drilling

Bed Type
Hardened & Ground Bed

Lubrication System
Manual

Tailstock
Quill Travel 120 mm

Main Motor
2 HP

Coolant System
Provided

Power Source
Electric

Surface Finish
Machined & Painted

Number Of Spindle Speeds
8

Tailstock Taper
MT-3

Chuck Size
200 mm 3-Jaw Self Centering

Spindle Nose
Camlock D1-4

Lead Screw
Metric & Imperial Threads

Drive Type
Belt Driven

XYZ England 1000 mm Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About XYZ England 1000 mm Lathe Machine

Make - XYZ (England)

Model - 1340

Center Height - 165 mm

Max. Length of Job - 1000 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 190 mm

Spindle Speeds - 53 rpm to 2000 rpm

Bed Width - 190 mm

Spindle Bore - 35 mm

Max. Job Diameter in Gap - 490 mm

3-Jaw Chuck Diameter - 160 mm

4-Jaw Chuck Diameter - 200 mm

Year of Make - 2007

- Complete with 3-Point Steady and other accessories.

- Equipped with Foot Operated Spindle Brake.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/h642-7ZUiG8

Precision Engineering and Durable Build

The XYZ England 1000 mm Lathe Machines rigid cast iron and mild steel build provides long-lasting structural stability. Its hardened and ground bed supports precise machining, while the machined and painted surface finish ensures both function and aesthetics. Designed for challenging metalwork, this lathe is well suited for demanding industrial environments.

Versatile Capabilities for Multiple Applications

Capable of handling turning, facing, threading, and drilling, this lathe supports a wide range of machining tasks. It accommodates a maximum swing diameter of 400 mm and up to 12 mm cutting thickness, providing ample flexibility for both standard and intricate workpieces. The tailstock features MT-3 taper and 120 mm quill travel for added versatility.

Enhanced Operator Experience

Manual gearbox control, belt-driven main motor, and self-centering chuck streamline operation. The provided coolant and manual lubrication systems maintain cutting efficiency and component longevity. Ergonomically designed and easy to operate, the XYZ England Lathe meets the needs of workshops prioritizing both precision and user comfort.

FAQs of XYZ England 1000 mm Lathe Machine:

Q: How is the XYZ England 1000 mm Lathe Machine maintained for optimal performance?

A: Regular manual lubrication, checking belt tension, and cleaning the coolant system ensure smooth operation and longevity. Following prescribed maintenance routines will keep the hardened and ground bed and other critical components in excellent condition.

Q: What types of machining processes can be performed with this lathe?

A: The lathe is ideal for turning, facing, threading (metric and imperial), and drilling. Its versatile design enables it to handle an array of standard and complex metalworking tasks with precision.

Q: When should the coolant system be used during operation?

A: For operations generating significant heatsuch as prolonged turning or heavy-duty facingthe integrated coolant system should be engaged. This helps to reduce tool wear and maintain surface finish quality.

Q: Where is the XYZ England 1000 mm Lathe Machine typically installed?

A: Commonly found in manufacturing plants, workshops, and training institutes, the machines dimensions (1900 mm x 750 mm x 1200 mm) and weight (approx. 850 kg) allow for flexible floor placement in industrial settings.

Q: What are the benefits of the 3-jaw self-centering chuck and Camlock spindle nose?

A: The 3-jaw self-centering chuck simplifies workpiece alignment, enhancing productivity and precision. The Camlock D1-4 spindle nose allows for quick, secure changes of chucks and accessories, reducing setup time.

Q: How does the manual control system affect usage?

A: Manual gearbox and control systems give operators precise command over speed selection and machining steps, ideal for applications where careful adjustment and skilled craftsmanship are valued over automation.
