XYZ England Tool Room Lathe Machine

Name: XYZ England Tool Room Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 35000 INR
Availability: InStock

Price 35000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

XYZ England Tool Room Lathe Machine Specification

Product Type
Tool Room Lathe Machine

Material
High-Grade Cast Iron

Cutting Thickness
Up to 20 mm

Cutting Speed
25-2000 RPM

CNC Or Not
No, Manual Operation

Automatic Grade
Manual

Control System
Manual Control

Max. Swing Diameter
410 mm

Voltage
415 V

Weight (kg)
1250 kg

Dimension (L*W*H)
2100 mm x 950 mm x 1300 mm

Capacity
Light to Medium Duty

Feature
Precision Ground Bed, Hardened Gears, Wide Range of Threads & Feeds

Color
Light Blue / Silver

Tailstock Quill Travel
110 mm

Centre Height
205 mm

Headstock Type
All Geared

Surface Finish
Gear Teeth Induction Hardened

Lead Screw Diameter
25 mm

Power Requirement
2 HP

Bed Length
1500 mm

Spindle Bore
40 mm

Chuck Mounting
Threaded Nose

Usage/Application
Precision Turning, Thread Cutting, Facing & Drilling

Thread Pitch Range
0.5 - 7 mm

Distance Between Centers
1000 mm

Coolant System
Fitted

Feed Range
0.05 - 0.75 mm/rev

XYZ England Tool Room Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

XYZ England Tool Room Lathe Machine About

Make - XYZ (England)

Model - E Turn 1430

Center Height - 178 mm

Max. Length of Job - 760 mm

Max. Job Diameter over Bed - 350 mm

Max. Job Diameter over Cross-Slide - 215 mm

Spindle Speeds - 50 rpm to 2000 rpm

Bed Width - 190 mm

Spindle Bore - 42 mm

Chuck Diameter - 160 mm

Max. Job Diameter in Gap - 500 mm

Year of Make - 2012

- Equipped with Foot Operated Spindle Brake.

- Complete with a Follow Rest.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/fqqo9WEN8aA

Precision Engineering and Robust Build

Constructed from high-grade cast iron and featuring a precision ground bed, the XYZ England Tool Room Lathe delivers stability and accuracy with every operation. Its all-geared headstock and hardened gear teeth ensure long-term durability, ideal for demanding workshops that require consistent results in light to medium-duty work.

Versatile Performance and Wide Applications

This lathe is designed for precision turning, threading, facing, and drilling, accommodating various job requirements with ease. Its wide feed and thread pitch rangescombined with the ability to cut up to 20 mm thicknessmake it adaptable for numerous applications. The fitted coolant system and threaded nose chuck allow efficient, safe, and repeatable setups.

Manual Control for Skilled Machinists

With a manual control system and no CNC integration, this machine is perfect for experienced operators who require hands-on manipulation and real-time adjustments. The ergonomic design, clear controls, and reliable performance provide an optimal balance between traditional craftsmanship and modern engineering.

FAQs of XYZ England Tool Room Lathe Machine:

Q: How does the XYZ England Tool Room Lathe Machine ensure precision in machining operations?

A: The XYZ lathe features a precision ground bed, high-grade cast iron construction, and induction-hardened gears. These design elements, along with its all-geared headstock, deliver exceptional stability, minimal vibration, and consistent accuracy during turning, threading, and facing work.

Q: What types of tasks can this lathe machine handle effectively?

A: This tool room lathe is built for precision turning, threading, facing, and drilling, capable of handling light to medium-duty tasks. Its wide speed (252000 RPM), feed, and threading ranges make it suitable for manufacturing or repair jobs requiring detailed, repeatable operations.

Q: When is manual operation preferred over CNC for this machine?

A: Manual control allows skilled machinists greater flexibility and tactile feedback, making it ideal for custom jobs, prototyping, or situations where real-time adjustments are necessary. This lathe is suited for those who favor hands-on control for detailed metalworking applications.

Q: Where should the XYZ Tool Room Lathe be installed for optimal performance?

A: For best results, the lathe should be placed on a stable, level surface in a well-ventilated and adequately lit workshop environment. Proper installation ensures safety, accurate machining, and extends the lifespan of the machines components.

Q: What is the process for cutting threads or turning precision parts on this lathe?

A: Thread cutting and precision turning are performed by securely mounting the workpiece between the centers or in the chuck, selecting the appropriate speed and feed based on the material and desired finish, and engaging the lead screw or feed mechanism for controlled movement.

Q: How does the fitted coolant system benefit the machining process?

A: The lathes fitted coolant system helps dissipate heat generated during cutting, reducing tool wear and maintaining workpiece integrity. This leads to smoother finishes, heightened safety, and a longer tool life, especially during intensive operations.
