Camut Italy 400 mm x 600 mm Surface Grinder Machine

Send Inquiry

Request To Call Back

Camut Italy 400 mm x 600 mm Surface Grinder Machine

Name: Camut Italy 400 mm x 600 mm Surface Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Camut Italy 400 mm x 600 mm Surface Grinder Machine Specification

Rotation
Grinding Wheel Rotation 1450 RPM

Model
Camut Italy 400 x 600

Product Type
Surface Grinder

General Use
Precision Surface Grinding

Material
Cast Iron, Alloy Steel

Type
Manual Surface Grinding Machine

Capacity
Heavy Duty

Weight (kg)
Approx. 2500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
400 mm x 600 mm

Table Slide Way
V and Flat Guideways

Magnetic Chuck Size
400 mm x 600 mm

Grinding Wheel Size
Approx. 300 mm

Grinding Wheel Speed
1450 RPM

Grinding Length
600 mm

Floor Space
Approx. 2200 mm x 1600 mm

Fuel Tank Capacity
Approximately 60 Liters

Spindle Speed
1450 RPM

Power
7.5 HP

Voltage
380/440 V

Dimension (L*W*H)
2200 mm x 1600 mm x 1700 mm

Feature
High Precision Grinding, Sturdy Design, Smooth Table Movement

Color
Turquoise Blue & Cream

Safety Features
Overload Protection

Surface Finish Accuracy
Up to 0.005 mm

Lubrication System
Automatic

Working Speed
Variable Table Traverse

Max Workpiece Height
350 mm

Max Workpiece Weight
600 kg

Wheel Head Movement
Vertical and Horizontal Manual Feed

Chuck Type
Electromagnetic

Coolant System
Fitted with Separate Pump

Table Travel
Up to 650 mm

Usage Environment
Industrial Workshop

Installation
Floor Mounted

Table Feed
Hydraulic & Manual

Noise Level
Low

Camut Italy 400 mm x 600 mm Surface Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Camut Italy 400 mm x 600 mm Surface Grinder Machine

Make - Camut (Italy)

Model - mini 406

Grinding Capacity - 400 mm x 600 mm

Longitudinal Travel of Table - 725 mm

Cross Travel of Table - 400 mm

Grinding Wheel Size - Diameter 400 mm x 50 mm Width

Height between Table Top to Wheel Center - 575 mm

Least Count of Vertical Travels - 2 Microns (0.002 mm)

Spindle Motor Power - 20 HP

- Micro-Feed Travels on Vertical & Cross Movements.

- Equipped with a Hydraulic Top Mounted Wheel Dresser.

- Feature of Automatic Depth Adjustment and Plunge Grinding.

- Equipped with 2-Axis DRO on Vertical & Cross Travels.

- Electrical Drawings of the machine are available.

- Complete with spare new wheels, flange and other accessories.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1MtACY7llZI

Superior Precision and Build Quality

Constructed with sturdy cast iron and alloy steel, the Camut Italy 400 x 600 Surface Grinder is engineered for longevity and exceptional performance. Its robust design supports heavy-duty workpieces, while smooth table movement and V and flat guideways guarantee consistent accuracy, making it ideal for industrial workshops requiring reliable, high-precision grinding.

Advanced Features for Optimal Performance

Equipped with an electromagnetic chuck, automatic lubrication system, and variable table traverse speeds, this grinder maximizes productivity and operator convenience. The inclusion of overload protection and a separate coolant pump ensures both machine safety and a superior surface finish, while manual vertical and horizontal feed controls support detailed adjustments.

User-Friendly Operation and Maintenance

Designed for ease of use, the Camut Italy 400 x 600 grinder features intuitive manual controls and a low-noise design, making it suitable for busy industrial environments. Floor mounting ensures stability, and the automatic lubrication system reduces maintenance time, allowing operators to focus on quality results and efficient workflows.

FAQ's of Camut Italy 400 mm x 600 mm Surface Grinder Machine:

Q: How does the hydraulic and manual table feed system work on this surface grinder?

A: The Camut Italy grinder's table feed operates both hydraulically for smooth, consistent movement and manually for precise adjustments. This dual capability allows the operator to select the best mode for the specific grinding task-hydraulic feed for longer, uniform grinding cycles and manual feed for fine-tuning and detailed work.

Q: What materials can be processed with this surface grinding machine?

A: This machine is designed to grind a variety of metals and alloys, particularly suited for precision work on cast iron, alloy steel, and other hard materials commonly used in industrial workshops and manufacturing facilities.

Q: When should the coolant system be used during operation?

A: The separate pump-fitted coolant system should be used throughout the grinding process to prevent overheating, achieve optimal surface finishes, and extend the lifespan of both the grinding wheel and workpieces.

Q: Where is the ideal installation location for this surface grinder?

A: This grinder is best suited for installation in an industrial workshop environment. It requires floor mounting with a stable, level area measuring approximately 2200 mm x 1600 mm to accommodate the machine's footprint and ensure safe, efficient operation.

Q: What benefits does the automatic lubrication system provide?

A: The automatic lubrication system ensures that all critical moving parts receive consistent oiling without manual intervention. This reduces wear, enhances the machine's longevity, and minimizes downtime for maintenance, leading to higher operational efficiency.

Q: How does the machine's precision contribute to the manufacturing process?

A: With a surface finish accuracy of up to 0.005 mm, the grinder delivers high-precision results essential for applications requiring tight tolerances and excellent surface quality, making it invaluable in toolrooms, assembly lines, and component finishing operations.

Q: What safety features are included with the Camut Italy 400 x 600 grinder?

A: The machine includes overload protection as a standard safety feature, helping prevent motor and component damage from excessive loads. Additionally, the electromagnetic chuck provides secure workpiece holding, contributing to safer operation for the user.
