CC France 1200 mm Universal Cylindrical Grinder

Send Inquiry

Request To Call Back

CC France 1200 mm Universal Cylindrical Grinder

Price 50000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CC France 1200 mm Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Industrial Grinding of Metal Components

Material
Cast Iron / Hardened Steel

Type
Cylindrical Grinder

Capacity
1200 mm

Weight (kg)
2100 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual

Drive Type
Electric

Grinding Diameter
320 mm

Grinding Length
1200 mm

Spindle Speed
30-350 RPM

Grinding Wheel Size
400 x 50 x 203 mm

Voltage
415 V

Dimension (L*W*H)
3150 x 1675 x 1475 mm

Feature
High Precision, Durable, Versatile

Color
Standard Grey

Coolant System
Provided

Tailstock Quill Travel
35 mm

Wheel Head Motor Power
3 HP

Installation
Floor Mounted

Surface Finish (Ra)
0.2 µm

Power Requirement
3 Phase, 50 Hz

Table Traverse
1200 mm

Work Head Center Taper
MT-4

Application
Precision cylindrical surface grinding of shafts, rods, and other components

Max Distance Between Centers
1350 mm

Workpiece Max Swing Over Bed
320 mm

CC France 1200 mm Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About CC France 1200 mm Universal Cylindrical Grinder

Make - CC (France)

Center Height - 130 mm

Max. Job Diameter - 250 mm

Max. Job Length - 1200 mm

Grinding Wheel Size - Diameter 350 mm x 50 mm Width

Work-Head Speeds - 30 rpm to 305 rpm (Continuously Variable)

Least Count - 0.5 Micron (0.0005 mm)

- Equipped with Internal Grinding Attachment.

- With 2-point steady, 3-point steady, 2 x Wheel Dressers etc.

- With Wheel Balancing Stand, Chuck, Spare Wheels & Flanges etc.

- With Magnetic Coolant Filtration Unit, Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/ams6hm6Mi-0

Superior Precision and Versatility

Offering a surface finish of Ra 0.2 m, this universal cylindrical grinder delivers exceptional accuracy across a wide range of industrial applications. The machine accepts workpieces up to 1200 mm in length and 320 mm diameter, making it suitable for shafts, rods, and numerous metal parts. Its manually controlled semi-automatic operation provides versatility for both small- and large-scale production environments.

Robust Design and Efficiency

Constructed from premium cast iron and hardened steel, the CC France 1200 mm grinder is built for durability and stability, even under continuous use. The electric-driven spindle offers speeds from 30 to 350 RPM, efficiently handling a variety of grinding operations. The included coolant system supports prolonged workloads, ensuring the longevity of both the grinding wheel and workpiece.

FAQs of CC France 1200 mm Universal Cylindrical Grinder:

Q: How does the CC France 1200 mm Universal Cylindrical Grinder ensure high-precision results?

A: This machine achieves superior accuracy with a surface finish Ra of 0.2 m, a robust build from cast iron/hardened steel, and precise manual controls. These features enable consistent, high-quality grinding results for shafts, rods, and other components.

Q: What is the maximum size of workpiece that can be ground on this cylindrical grinder?

A: The grinder supports workpieces up to 320 mm in diameter (swing over bed) and up to 1200 mm in grinding length, with a 1350 mm maximum distance between centers, allowing for a wide range of component sizes.

Q: Where is the CC France 1200 mm cylindrical grinder typically used?

A: This grinder is ideal for industrial environments such as manufacturing plants, workshops, and facilities involved in the export, import, and supply of metal components, where precision cylindrical surface grinding is required.

Q: What are the power and installation requirements for this grinder?

A: The machine requires a 3-phase, 50 Hz power supply at 415 V and is designed for floor mounting, ensuring stable operation. Its dimensions are 3150 x 1675 x 1475 mm and it weighs 2100 kg.

Q: How is the grinding process controlled on this machine?

A: Operation is semi-automatic with manual controls, allowing the operator to adjust settings such as spindle speed (30-350 RPM) and table positioning, which helps accommodate various workpieces and ensures precise finishing.

Q: What benefits does the provided coolant system offer?

A: The integrated coolant system prevents overheating of both the workpiece and grinding wheel, prolongs tool life, enhances surface finish, and maintains dimensional accuracy during prolonged grinding tasks.
