Csepel RF 20 Radial Drilling Machine

Price 5500 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Csepel RF 20 Radial Drilling Machine Specification

Machine Type
Radial Drilling Machine

Diameter
20mm

Spindle Speed
Variable

Features
High rigidity Smooth operation

Frequency
50 Hz

Condition
Used

Noise Level
Low

Product Type
Drilling Machine

Material
Cast Iron

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual

Voltage
440V

Power
3 HP

Power Source
Electricity

Capacity
20mm

Color
Grey and Red

Usage & Applications
Industrial drilling applications in metal and wood

About Csepel RF 20 Radial Drilling Machine

Make - Csepel (Hungary)

Model - RF 20

Drilling Capacity - 50 mm

Spindle Diameter - 78 mm

Arm Length - 1140 mm

Spindle Speeds - 45 rpm to 2000 rpm

Spindle Taper - MT 4

Vertical Travel of Arm - 730 mm

Spindle Feed Travel - 300 mm

Spindle Feed Travel Rate - 0.05 mm/rev to 1.25 mm/rev

Tilting-Cube Table Size - 600 mm x 500 mm

Clamping - Manual

- Machine is in excellent working condition.

Versatile Drilling Performance

The Csepel RF 20 Radial Drilling Machine delivers exceptional flexibility in industrial drilling tasks. It caters to both metal and woodwork, making it ideal for manufacturing units and workshops that require multi-material capabilities. Its semi-automatic grade and manual control system enable operators to adjust parameters for optimal performance, enhancing operational accuracy and reliability.

Robust Construction for Longevity

Made from sturdy cast iron, the RF 20 stands out with high rigidity, ensuring it endures heavy-duty usage with minimal deformation. Its smooth operation sustains productivity, while the distinct grey and red color ensures easy identification in busy settings. This durability lowers maintenance requirements, contributing to overall cost effectiveness.

Adaptable Power and Control

Powered by a 3 HP motor and a 440V electrical connection, this radial drilling machine suits industrial environments with standard power supplies. The variable spindle speed feature lets users efficiently process different materials and diameters. Manual controls provide direct handling for operators, refining the drilling process according to specific project needs.

FAQs of Csepel RF 20 Radial Drilling Machine:

Q: How does the Csepel RF 20 Radial Drilling Machine operate in industrial settings?

A: The Csepel RF 20 functions efficiently within factories and workshops, utilizing its semi-automatic and manual control features. Its 3 HP electric motor and variable spindle speed allow operators to seamlessly drill through metal and wood, while its low noise level supports a conducive work environment.

Q: What materials and applications can this radial drilling machine handle?

A: The RF 20 is suitable for drilling in both metal and wood, ideal for industrial applications such as fabrication, assembly, and production lines. Its sturdy cast iron build and 20mm drilling capacity make it a preferred choice for jobs demanding precision and durability.

Q: When is the Csepel RF 20 most beneficial to use?

A: This machine is most beneficial during repetitive industrial drilling tasks that require consistency, smooth operation, and material versatility. It excels in situations where manual control and operational flexibility are needed to meet specific project requirements.

Q: Where can I source or trade the RF 20 Radial Drilling Machine?

A: The RF 20 is available through exporters, importers, manufacturers, suppliers, and traders, particularly those operating in Hungary or dealing with Hungarian machinery. You can contact these channels to acquire either new or used units matching your specification needs.

Q: What is the process for adjusting spindle speed on the RF 20?

A: Adjusting spindle speed on this manual, semi-automatic machine involves using the built-in controls. Operators can set speeds according to material type and drilling diameter, optimizing the process for either metal or woodwork, thus achieving precise drilling results.

Q: How does the smooth operation and high rigidity benefit users?

A: Smooth operation ensures continuous production without abrupt interruptions, reducing wear on the machine and boosting operational efficiency. High rigidity maintains drilling accuracy, prevents deformation, and lowers maintenance frequency, providing users with a reliable tool for demanding applications.
