Ezio Pensotti CNC Plano Miller Machine

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ezio Pensotti CNC Plano Miller Machine Specification

Noise Level
Less than 80 dB

Table Size
3000 x 1200 mm (typical size, other sizes available)

Dimension (L*W*H)
8000 x 3500 x 2500 mm (varies by model)

Cutting Area
Up to 3000 x 1200 mm

Features
High rigidity, precision CNC control, large working area, robust structure, anti-vibration design, programmatic automation

Machine Type
CNC Plano Miller

Motor Power
15 HP main motor

Spindle Speed
30-1500 RPM (variable)

Condition
New

Frequency
50/60 Hz

Diameter
N/A (not applicable to planomiller)

Product Type
CNC Plano Miller Machine

Material
Heavy-duty Cast Iron & Alloy Steel

Computerized
Yes

Automatic Grade
Automatic

CNC Or Not
CNC

Control System
Siemens/Fanuc CNC Control (as per model)

Voltage
380-415 V, Three Phase

Power
15 kW (main drive, typical)

Power Source
Electric

Weight (kg)
22000 - 25000 kg (approx.)

Capacity
Heavy Duty, up to 8 Tons table load

Color
Blue & White (standard for Ezio Pensotti)

Usage & Applications
Precision milling of large and heavy components for automotive, steel, aerospace, shipbuilding, and general engineering industries.

Drive Type
Gear/AC Servo Motor

Number of Axis
3 (+ optional 4th axis)

Positioning Accuracy
±0.02 mm

Vertical Travel (Head)
Up to 1000 mm

Feed Rate
Max 6000 mm/min

Lubrication System
Centralized forced lubrication

Protection
Overload, short-circuit, and limit switch protection

Table Travel (Longitudinal)
Up to 3200 mm

Coolant System
Integrated automatic coolant system

Rapid Traverse Rate
Up to 8000 mm/min

Work Table T-Slot
22-28 mm (quantity and size as per table)

Repeatability
±0.01 mm

Cross Travel (Transverse)
Up to 1500 mm

Tool Change
Manual/Automatic (optional)

Ezio Pensotti CNC Plano Miller Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ezio Pensotti CNC Plano Miller Machine

Make - Ezio Pensotti (Italy)

Model - DFS 150

Table Size - 3000 mm x 1250 mm

Distance b/w Columns - 1750 mm

Longitudinal Travel of Table - 4800 mm

Cross Travel - 2670 mm

Vertical Travel of Crossrail - 1000 mm

Vertical Travel of RAM - 800 mm

Max. Job Height - 1600 mm

CNC Controller - ECS 2101

Weight - 42 Tons Approximately

- Double Spindle type Milling Head.

- Milling Head can be indexed in 4 positions (90 degrees).

- Machine is in excellent working condition.

Video of The Machine-

https://youtu.be/1Rl4MlznDgA

Robust Construction for Heavy-Duty Milling

Crafted with heavy-duty cast iron and alloy steel, the Ezio Pensotti CNC Plano Miller ensures exceptional stability and resistance to vibrations during operation. This solid construction allows for the precise machining of large and heavy components, making it ideal for industries where accuracy and durability are non-negotiable.

Advanced CNC Control for Precision and Automation

Featuring a computerized Siemens or Fanuc CNC control system, this plano miller offers precise programming, automated tool changes (optional), and seamless multi-axis operations. Thanks to its high positioning accuracy and repeatability, users can achieve intricate milling tasks on substantial workpieces with consistency and minimal operator intervention.

Highly Versatile with Large Working Capacities

With a working area and table size accommodating up to 3000 x 1200 mm components, along with manual or automatic tool changing options, this machine is highly adaptable for various milling applications. The expansive table travel and table load capacity of up to 8 tons ensure suitability for sectors such as aerospace, shipbuilding, and heavy engineering.

FAQs of Ezio Pensotti CNC Plano Miller Machine:

Q: How does the Ezio Pensotti CNC Plano Miller Machine enhance precision in milling operations?

A: The machine integrates high-rigidity construction, CNC-based controls (Siemens/Fanuc), and an anti-vibration design, providing repeatability up to 0.01 mm and positioning accuracy of 0.02 mm. These features enable accurate and consistent results, even when machining large and heavy components.

Q: What industries typically use this CNC Plano Miller Machine, and why?

A: Automotive, steel fabrication, aerospace, shipbuilding, and general engineering sectors commonly utilize this machine. Its high table load capacity (up to 8 tons), large work area, and precise CNC control make it suitable for heavy-duty and high-precision milling of oversized or complex parts.

Q: When should I consider adding the optional 4th axis or automatic tool changer?

A: If your milling operations require complex multi-sided machining or frequent tool changes for diverse or intricate parts, upgrading to an optional 4th axis or automatic tool changer can significantly enhance productivity, flexibility, and process automation.

Q: Where can the Ezio Pensotti CNC Plano Miller Machine be installed, and does it require special site preparation?

A: Given its considerable weight (up to 25,000 kg) and dimensions, the machine should be installed in an industrial facility with a reinforced foundation and ample space. Proper electrical supply (380415 V, Three Phase) and provision for coolant and lubrication systems are also essential.

Q: What is the general process for using the Ezio Pensotti CNC Plano Miller?

A: Operators program the required machining sequence into the Siemens or Fanuc CNC control. After securing the workpiece onto the T-slotted table, the machine executes the machining tasks automatically or semi-automatically, depending on configuration, while the integrated coolant and forced lubrication systems maintain optimal working conditions.

Q: How do the integrated coolant and lubrication systems benefit machine operation?

A: The automatic coolant system helps maintain tool temperature, improving tool life and machining accuracy, while centralized forced lubrication ensures continuous and uniform lubrication to moving components, reducing wear, downtime, and maintenance needs.

Q: What safety protections are built into this CNC milling machine?

A: The machine offers protection through overload safeguards, short-circuit protection, and limit switch systems, enhancing operational safety for both the operator and equipment during high-load or extended milling processes.
