Fortuna Germany Angular Cylindrical Grinder

Name: Fortuna Germany Angular Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Fortuna Germany Angular Cylindrical Grinder Specification

Product Type
Angular Cylindrical Grinder

General Use
Precise Surface and Cylindrical Grinding

Material
Cast Iron (Body), Steel (Components)

Type
Universal, Heavy Duty

Capacity
Up to 200 mm Diameter

Weight (kg)
Approx. 3500

Computerized
No

Automatic
Semi-Automatic

Control System
Manual / Hydraulic

Drive Type
Belt Driven

Grinding Diameter
200 mm

Grinding Length
600 mm

Spindle Speed
Up to 3500 RPM (Variable)

Grinding Wheel Size
350 x 50 x 127 mm

Voltage
415 V

Dimension (L*W*H)
2500 x 1700 x 1500 mm

Feature
High Precision, Angular Head, Rigid Structure

Color
Light Green / Grey

Table Feed
Automatic and Fine Manual Feed

Tailstock
Adjustable with Micro Adjustment

Headstock
Swivelling Headstock for Angular Grinding

Lubrication
Centralized Lubrication

Machine Bed
Heavily Ribbed, Vibration Free

Manufacturing Brand
Fortuna Germany

Max. Workpiece Weight
100 kg Between Centers

Coolant System
Integrated Coolant System

Application
Automotive, Tool Room, Aerospace

Fortuna Germany Angular Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Fortuna Germany Angular Cylindrical Grinder

Make - Fortuna (Germany)

Model - AFCD Series

Center Height - 140 mm

Max. Job Diameter - 270 mm

Max. Length of Job - 1000 mm

Grinding Wheel Diameter - 600 mm

Grinding Wheel Width - 100 mm

- Equipped with a Wheel-Top Mounted Hydraulic Wheel Dresser.

- Features like Rough Cut, Finish Cut, Spark-Out, Auto-Wheel Retraction.

- Machine can work in complete Auto-Cycle mode.

- Complete with Magnetic-and-Paper-type Coolant Filtration Unit.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/IarwqoU8j00

Superior Precision and Versatility

Boasting a swivelling headstock for angular grinding and a tailstock with micro adjustment, the Fortuna Germany Angular Cylindrical Grinder delivers exacting tolerances across a variety of workpieces. Its flexible controls make it suitable for both routine production and specialized tool room functions in diverse industries.

Rugged Construction for Stability

Manufactured from cast iron and featuring a heavily ribbed, vibration-free bed, this grinder ensures excellent durability and minimal deflection under heavy loads. Precision components and a rigid structure enable consistent, high-quality results even with workpieces weighing up to 100 kg.

Efficiency and Operator Ease

Integrated features, including centralized lubrication, an advanced coolant system, and combined automatic/fine manual feed, streamline maintenance and operation. The belt-driven system and variable spindle speeds maximize adaptability and workflow efficiency for users.

FAQ's of Fortuna Germany Angular Cylindrical Grinder:

Q: How does the swivelling headstock benefit angular grinding?

A: The swivelling headstock allows for precise angular positioning during grinding, enabling the Fortuna Germany grinder to tackle complex surface and cylindrical profiles with enhanced flexibility and accuracy.

Q: What types of applications is this grinder suitable for?

A: This machine is designed for automotive, aerospace, and tool room applications, as well as general precision engineering requirements, thanks to its robust design and high level of accuracy.

Q: When should the coolant and lubrication systems be used?

A: The integrated coolant system and centralized lubrication should be activated during all grinding operations to reduce heat buildup, minimize wear, and maintain consistent performance and part quality.

Q: What is the process for adjusting the tailstock for high-precision jobs?

A: Using the micro-adjustment feature on the tailstock, operators can finely align and secure the workpiece, ensuring optimal concentricity and surface finish during grinding operations.

Q: Where can this grinder be installed, and what are its space requirements?

A: With dimensions of 2500 x 1700 x 1500 mm, the grinder requires a dedicated workspace with stable flooring and access to 415 V power. It is suitable for professional workshops, tool rooms, and manufacturing environments.

Q: What is the maximum workpiece diameter and weight that the grinder can handle?

A: The Fortuna Germany Angular Cylindrical Grinder can accommodate workpieces up to 200 mm in diameter and weights up to 100 kg between centers, offering flexibility for a wide range of grinding tasks.

Q: How does the semi-automatic, manual/hydraulic control system enhance operation?

A: The combination of manual and hydraulic controls allows operators to adapt grinding parameters quickly and efficiently, ensuring both operator involvement for precision tasks and enhanced productivity during repetitive processes.
