G. Rastelli RT-1 Surface Grinding Machine

Name: G. Rastelli RT-1 Surface Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

G. Rastelli RT-1 Surface Grinding Machine Specification

Rotation
Clockwise

Model
RT-1

Product Type
Surface Grinding Machine

General Use
Industrial/Workshop Surface Grinding

Material
Cast Iron & Steel

Type
Manual

Capacity
Precision Flat Surface Grinding

Weight (kg)
Approx. 500 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
150 x 300 mm

Table Slide Way
V & Flat Slideways

Magnetic Chuck Size
150 x 300 mm

Grinding Wheel Size
200 x 13 x 31.75 mm

Grinding Wheel Speed
2800 RPM

Grinding Length
300 mm

Floor Space
1000 x 870 mm

Fuel Tank Capacity
Built-in Lubrication Tank

Spindle Speed
2800 RPM

Power
1 HP

Voltage
415V, 50Hz

Dimension (L*W*H)
1000 x 870 x 1600 mm

Feature
Durable, Precise Grinding

Color
Industrial Grey/White

Cross Feed (Manual)
150 mm

Vertical Feed (Manual)
200 mm

Traverse Feed (Longitudinal)
300 mm

Max Workpiece Height
210 mm

Grinding Accuracy
0.003 mm

Coolant System
Provided

Table Travel (Longitudinal)
330 mm

Spindle Bearings
High Precision, Hardened

Chuck To Spindle Center Distance
340 mm

Table Hand Traverse
Provided

Lubrication
Automatic/Centralized

G. Rastelli RT-1 Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About G. Rastelli RT-1 Surface Grinding Machine

Make - G. Rastelli (Italy)

Model - RT-1

Magnet Size - 300 mm x 600 mm

Max. Longitudinal Travel - 670 mm

Max. Cross Travel - 340 mm

Grinding Wheel Diameter - 300 mm

Grinding Wheel Width - 40 mm

Max. Height between Magnet Top to Wheel Center - 425 mm

- Features like Automatic Depth Adjustment "Auto-Cut".

- Complete with lots of spare Grinding Wheels.

- Complete with a Dust Collection Unit and Coolant Tank & Pump.

- Machine is in excellent working condition.

Video of the Machine -

https://youtu.be/CviQvmyzEw8

Exceptional Grinding Precision

The RT-1 Surface Grinding Machine achieves a superior flatness with a grinding accuracy of up to 0.003 mm. Ideal for industrial settings and workshops, its high-precision spindle bearings and stable hardened construction ensure repeatable and consistent results on a wide range of metal components.

Robust Design and Durable Build

Constructed from high-grade cast iron and steel, the RT-1 ensures durability and reliability even with prolonged use. The V & flat slideway table, combined with a centralized lubrication system, minimizes wear and sustains optimal machine performance for years, making it a solid investment for businesses.

Simple Manual Operation

With a manual control system and hand traverse, users can easily adjust the table's longitudinal, cross, and vertical feeds to match specific grinding requirements. Its intuitive interface, combined with the magnetic chuck, provides convenience and safe workpiece handling without complex programming.

FAQ's of G. Rastelli RT-1 Surface Grinding Machine:

Q: How does the RT-1 Surface Grinding Machine achieve precise flat surface grinding?

A: The RT-1 employs high-precision, hardened spindle bearings, V & flat slideways, and a stable cast iron structure to minimize vibrations and maintain a grinding accuracy of up to 0.003 mm, which is ideal for precision applications.

Q: What types of workpieces can be processed on the RT-1 Surface Grinding Machine?

A: The RT-1 is designed for flat surface grinding of metallic workpieces, with a maximum workpiece height of 210 mm. Its magnetic chuck and table size of 150 x 300 mm accommodate various industrial and workshop parts.

Q: When should the machine's lubrication system be maintained?

A: The RT-1 comes with an automatic, centralized lubrication system. Regular inspections and periodic replenishment of the built-in lubrication tank are recommended to ensure smooth operation and extend machine life.

Q: Where can the RT-1 Surface Grinding Machine be installed?

A: Due to its compact floor space requirement (1000 x 870 mm) and robust design, the RT-1 is suitable for installation in industrial workshops, tool rooms, and manufacturing facilities where precision surface grinding is needed.

Q: What is the process of adjusting feeds on this machine?

A: Feeds are adjusted manually via hand traverse controls. Longitudinal (300 mm), cross (150 mm), and vertical (200 mm) feeds can be set using the respective hand-operated levers, giving operators direct control over grinding operations.

Q: How does using this machine benefit industrial users?

A: Industrial users benefit from the machine's high accuracy, durable construction, and user-friendly manual controls. It reduces rework and ensures consistent surface finishes, improving productivity for tooling, maintenance, and manufacturing departments.
