Hauser B3-DR Jig Boring Machine

About Hauser B3-DR Jig Boring Machine

Make - Hauser (Switzerland)

Model - B3-DR

Table Size - 600 mm x 380 mm

Longitudinal Travel of Table - 400 mm

Cross Travel of Table - 250 mm

Spindle Speeds - 30 rpm to 2500 rpm

Spindle Feed Travel - 140 mm

Spindle Feed Rates - 0.02 mm/rev to 0.23 mm/rev

Spindle Diameter - 85 mm

Spindle Taper - ISO 30

Vertical Travel of Boring Head - 450 mm

Max. Distance between Table & Spindle - 550 mm

Max. Bore Capacity - 220 mm

Max. Drilling Capacity - 30 mm

Max. Job Weight - 300 kg

- Complete with Tilting type Rotary Table, Toolings, Dust Collector etc.

- Equipped with a 2-Axis DRO.

- Feature of Automatic Tool Clamping.

- Operating Manual and Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/K0-z0cRGxQo
