Poreba TR-90 x 4000 Heavy Duty Lathe Machine Best Price and Features

जांच भेजें

Request To Call Back

Price 100000 आईएनआर/ टुकड़ा

मूल्य/उद्धरण प्राप्त करें

MOQ : 1 टुकड़ा

Specification

प्रॉडक्ट टाइप

मटेरियल
Heavy Duty Cast Iron

काटने की मोटाई
Up to 30 mm (depending on material)

कटिंग स्पीड
Variable, up to 1200 RPM

सीएनसी या नहीं

स्वचालित ग्रेड

कंट्रोल सिस्टम

मैक्स। स्विंग डायमीटर
900 mm

वोल्टेज
415V / 3 Phase / 50 Hz

वजन (किग्रा)
Approx. 8500 kg

आयाम (एल* डब्ल्यू* एच)
Approx. 6700 mm x 1800 mm x 1700 mm

क्षमता
4 meters (center distance)

फ़ीचर

रंग
Standard Industrial Grey

Tail Stock Quill Diameter
100 mm

Distance Between Centers
4000 mm

Taper in Spindle
MT-7

Spindle Nose
A1-11

Spindle Speeds
16 steps

Spindle Bore
105 mm

Motor Power
15 HP

Carriage Travel
3900 mm

Bed Type
Hardened and ground double V-type

Bed Width
600 mm

Coolant System
Fitted

Tail Stock Quill Travel
250 mm

Max. Turning Length
4000 mm

Lead Screw Diameter and Pitch
50 mm / 8 mm

Chuck Size
500 mm (manual 4-jaw)

Electricals
Standard with safety features

Thread Cutting Range
Metric: 1–120 mm, Inch: 2–48 TPI

Lubrication System
Centralized

Trade Information

Minimum Order Quantity
1 टुकड़ा

मुख्य घरेलू बाज़ार

About

Make - Poreba (Poland)

Model - TR-90

Center Height - 450 mm

Max. Length of Job - 4000 mm

Max. Job Diameter over Bed - 900 mm

Max. Job Diameter over Cross-Slide - 600 mm

Chuck Diameter - 800 mm

Bed Width - 660 mm

Spindle Speeds - 7.5 rpm to 380 rpm

Spindle Bore - 105 mm

- Motorised Rapid Travels on the Carriage & Cross-Slide

- Complete with Job Steady etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/Q1m0sk0VAQg

Heavy Duty Performance with Precision

Engineered for versatility, the Poreba TR-90 x 4000 offers exceptional stability and accuracy thanks to its heavy-duty cast iron body and precision-hardened bed ways. Capable of handling workpieces up to 4 meters and supporting turning thicknesses up to 30 mm, this lathe excels in demanding workshops requiring both productivity and high-quality results.

Reliable Manual Control and Safety

With its conventional manual control system, operators have full command over the machine, allowing for flexible and intuitive machining. The inclusion of centralized lubrication, standard safety electricals, and a fitted coolant system ensures smooth, reliable operation and prolongs the lifespan of machine components.

FAQ's of Poreba TR-90 x 4000 Heavy Duty Lathe Machine:

Q: How does the Poreba TR-90 x 4000 enhance machining precision and stability?

A: This lathe is built with a hardened and ground double V-type bed and a robust cast iron body, which provide excellent rigidity, minimize vibration, and maintain accuracy even during heavy-duty operations.

Q: What are the main uses for the Poreba TR-90 x 4000 lathe machine?

A: It is ideal for turning, facing, threading, and other cylindrical machining operations on long and heavy workpieces, making it highly suitable for industries such as manufacturing, energy, and fabrication.

Q: When should I perform maintenance on this lathe machine?

A: Routine maintenance should be conducted according to usage intensity, typically involving lubrication checks, cleaning, and inspection of moving parts after each significant job or at least once per week for continuous operation.

Q: Where can the Poreba TR-90 x 4000 be installed?

A: Due to its large dimensions and weight (approx. 8500 kg), the lathe requires a stable, reinforced industrial floor space measuring at least 6700 mm x 1800 mm for proper installation and safe operation.

Q: What is the spindle speed range, and how is it selected?

A: The lathe offers a 16-step spindle speed selection, ranging up to 1200 RPM, which is manually adjusted to suit various material and machining requirements, providing flexibility for different operations.

Q: How does the coolant and lubrication system benefit machine usage?

A: The fitted coolant system helps manage heat during cutting, while the centralized lubrication ensures smooth, wear-resistant movement of all critical components, enhancing both performance and longevity.

Q: What benefits does the manual control system offer?

A: Manual control allows experienced operators precise adjustments and immediate intervention, ensuring flexibility across a wide variety of complex and non-repetitive turning projects.
