Jones and Shipman 1302 Universal Cylindrical Grinding Machine

Name: Jones and Shipman 1302 Universal Cylindrical Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000.00 INR
Availability: InStock

Price 100000.00 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Jones and Shipman 1302 Universal Cylindrical Grinding Machine Specification

Material
Aluminum

Computerized
Yes

Automatic
Yes

Control System
Manual

Drive Type
Electric

Feature
Environmental Friendly

Color
Blue

Warranty
yes

Jones and Shipman 1302 Universal Cylindrical Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Jones and Shipman 1302 Universal Cylindrical Grinding Machine About

Make - Jones & Shipman (England)

Model - 1302

Center Height - 178 mm

Max. Job Diameter - 355 mm

Max. Length of Job - 686 mm

Grinding Wheel Size - Diameter 305 mm x 40 mm Width

Work-Head Speeds - 25 rpm to 293 rpm

Table Rotation - 20 Degree to -18 Degree

- Equipped with Internal Grinding Attachment.

- Micro-Feed Adjustments on both Table & Wheel-Head Travel.

- Complete with Wheel Dresser, Coolant Tank & Pump etc.

- Machine is in excellent working condition.

Video of the Machine-

https://youtu.be/D9EoEpX6yBo

Advanced Grinding Capabilities

With both manual and automatic operations, the Jones and Shipman 1302 adapts to different workflow needs. Its computerized control ensures high precision and consistency, making it suitable for complex cylindrical grinding tasks across industries.

Environmental Responsibility

Made from aluminum and engineered with environmentally friendly features, this machine adheres to sustainable manufacturing practices. Its efficient design minimizes waste and energy consumption, contributing positively to your company's environmental goals.

FAQ's of Jones and Shipman 1302 Universal Cylindrical Grinding Machine:

Q: How does the computerized system improve the performance of the Jones and Shipman 1302 grinding machine?

A: The integrated computerized system enhances precision, repeatability, and ease of operation, allowing users to program complex grinding tasks and optimize production throughput for various cylindrical components.

Q: What are the advantages of using both manual and automatic control modes on this cylindrical grinding machine?

A: Operators can choose between manual control for bespoke, delicate tasks or automatic mode for high-volume production. This flexibility ensures the machine is suited for diverse applications and operator preferences.

Q: When should manufacturers consider using the Jones and Shipman 1302 grinding machine?

A: This machine is ideal for use when high accuracy, repeatability, and efficiency are required in grinding operations, particularly for medium to large-scale manufacturing projects or prototyping.

Q: Where can one purchase or source the Jones and Shipman 1302 Universal Cylindrical Grinding Machine?

A: It can be acquired from authorized exporters, importers, manufacturers, suppliers, or traders in the United Kingdom. These channels provide access to warranty and after-sales support.

Q: What is the process for operating this universal cylindrical grinding machine?

A: Users can operate the machine via its manual controls or switch to automatic, computerized mode. The electric drive ensures consistent power, while the computerized system handles input programming for efficient grinding operations.

Q: How does the environmentally friendly feature benefit users and operators?

A: The use of recyclable aluminum and efficient design reduces environmental impact, lowers operational costs, and supports companies' sustainability initiatives while maintaining high functional standards.

Q: What warranty coverage is provided with the Jones and Shipman 1302 grinding machine?

A: The machine comes with a warranty covering manufacturing defects and essential components, providing peace of mind for businesses investing in this technology.
