Skoda Czech 3000 mm Length Heavy Duty Lathe Machine

Name: Skoda Czech 3000 mm Length Heavy Duty Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Skoda Czech 3000 mm Length Heavy Duty Lathe Machine Specification

Product Type
Heavy Duty Lathe Machine

Material
Cast Iron, Steel

Cutting Thickness
Up to 25 mm

Cutting Speed
20 - 1000 RPM

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual

Max. Swing Diameter
800 mm

Voltage
415V

Weight (kg)
3400 kg

Dimension (L*W*H)
3000 mm x 1100 mm x 1450 mm

Capacity
High

Feature
Robust Construction, High Precision, Durable

Color
Industrial Grey

Phase
Three Phase

Bed Length
3000 mm

Spindle Bore
105 mm

Distance Between Centers
2500 mm

Tailstock Quill Travel
200 mm

Tool Post Type
Four-way

Power Consumption
7 kW

Lead Screw Pitch
6 mm

Spindle Speed Range
201000 RPM

Chuck Size
400 mm

Application
Heavy Industrial Turning

Skoda Czech 3000 mm Length Heavy Duty Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Skoda Czech 3000 mm Length Heavy Duty Lathe Machine About

Make - Skoda (Czech Republic)

Model - S-500 M1

Center Height - 525 mm

Max. Length of Job - 3000 mm

Max. Job Diameter over Bed - 1050 mm

Max. Job Diameter over Cross-Slide - 740 mm

Chuck Diameter - 1065 mm

Bed Width - 995 mm

Spindle Speeds - 0.71 rpm to 140 rpm

Weight of the Machine - 16 Tons (Approximately)

- Complete with Job Steady.

- With Motorized Rapid Travels of Carriage, Cross-Slide & Tool-Slide.

- Tool-Slide (Top Slide) also has powered Feed Travels.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/3HG-OVggI2Y

Robust Construction for Heavy Industrial Use

Built with industrial grey cast iron and steel, the Skoda Czech heavy duty lathe machine is designed to withstand rigorous industrial demands. Its robust architecture promises long-term stability and high precision, making it suitable for heavy-duty turning tasks and challenging environments.

Precision-Engineered Performance

With an impressive spindle speed range of 20 to 1000 RPM and a maximum swing diameter of 800 mm, this lathe offers versatility for various turning needs. The four-way tool post enables efficient tool changes, while manual controls provide fine-tuned accuracy for each job.

High Capacity and Versatile Application

Supporting a bed length of 3000 mm and a distance between centers of 2500 mm, the machine accommodates sizable workpieces with ease. Its cutting thickness up to 25 mm makes it ideal for a wide array of heavy industrial turning, from manufacturing components to large-scale repairs.

FAQ's of Skoda Czech 3000 mm Length Heavy Duty Lathe Machine:

Q: How do I operate the Skoda Czech 3000 mm heavy duty lathe machine for best results?

A: To achieve optimal results, ensure the machine is securely installed on a stable surface and connected to a three-phase 415V power source. Set the desired spindle speed (20-1000 RPM) according to the material and operation. Use the manual control system for precise adjustments, and regularly maintain the tool post and lead screw to ensure accuracy.

Q: What materials can be machined with this lathe machine?

A: The lathe is ideal for working on cast iron and steel, supporting heavy industrial applications. Its robust construction and high cutting thickness (up to 25 mm) allow for efficient turning of large and hard materials, making it suitable for fabrication, repair shops, and manufacturing plants.

Q: When is it appropriate to use this heavy duty lathe over a CNC lathe?

A: Choose this manual lathe when precision hand-operation, versatility, and cost-effectiveness are required, especially for unique, irregular, or one-off jobs. For long production runs requiring automation or complex geometries, a CNC lathe may be preferable.

Q: Where can this lathe machine be installed for effective performance?

A: Install the machine in spacious, well-ventilated industrial settings with a stable foundation. Ensure availability of adequate three-phase power supply (7 kW, 415V) and space for moving large workpieces (machine dimensions: 3000 mm x 1100 mm x 1450 mm).

Q: What is the process of changing spindle speed or tool post settings?

A: To change the spindle speed, use the manual control levers provided on the headstock, selecting the appropriate RPM for your material. The four-way tool post allows for quick tool swaps-simply unlock, rotate to the desired tool, and secure before resuming operation.

Q: What are the key benefits of using the Skoda Czech heavy duty lathe?

A: This lathe boasts high capacity, robust construction, and excellent precision, making it ideal for heavy, continuous use. Its versatility, manual control for customization, and durable build contribute to cost savings and dependable, long-term service.

Q: How does the machine ensure high precision during heavy machining operations?

A: The rigid cast iron and steel construction minimizes vibrations, while the lead screw with 6 mm pitch ensures smooth and accurate feed movement. Regular maintenance of the manual tool post and tailstock also preserves machining accuracy over time.
