Stanko USSR 2.5 Module Gear Hobbing Machine

Name: Stanko USSR 2.5 Module Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 20000 INR
Availability: InStock

Price 20000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Stanko USSR 2.5 Module Gear Hobbing Machine Specification

Dimension (L*W*H)
2200 mm x 1200 mm x 1800 mm

Capacity
2.5 Module (maximum gear module capacity)

Used For
Gear Cutting, Spline Cutting, Worm Cutting

Color
Industrial Green

Weight
Approx. 2,000 kg

Feature
Semi-Automatic, Robust Cast Iron Frame, Precision Adjustment

Machine Type
Gear Hobbing Machine

Voltage
380V, 3 Phase

Manufacturing Year
USSR Era (Approx. 1960s-1980s)

Condition
Used

Output
High-Precision Gear Production

Power
5 kW

Max Hob Width
130 mm

Noise Level
<80 dB

Spindle Speed
200 - 800 rpm

Table Rotation Speed
45 - 180 rpm (adjustable)

Min Number of Teeth Cut
10

Mounting
Floor mounted

Hob Slide Travel
180 mm

Number of Axis
2 (X and Y movement)

Safety
Integrated Emergency Stop Button

Max Hob Diameter
120 mm

Max Length of Workpiece
350 mm

Arbor Diameter
22 mm

Transmission Type
Gear Drive

Max Workpiece Diameter
250 mm

Lubrication System
Centralized

Stanko USSR 2.5 Module Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Stanko USSR 2.5 Module Gear Hobbing Machine

Make - Stanko (Russia)

Model - 5B310

Max. Module Capacity - 2.5 Modules

Max. Gear Diameter - 125 mm

Max. Clamping Length - 300 mm

Max. Width of Gear Cutting - 140 mm

Helical Angle - +45 degree to -45 degree

Max. Hob Cutter Diameter - 75 mm

Hob Cutter Speeds - 50 rpm to 1000 rpm

Feed Travel Rates - 0.35 mm/min to 45 mm/min

- Working in fully Auto-Cycle mode also capable of Double-Cut cycle.

- Operating Manual and Electrical Drawings are available.

- Change Gears and many other accessories available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/CSavDGUEKlQ

Precision Engineering for Gear Production

Engineered to deliver high accuracy and reliability, the Stanko USSR Gear Hobbing Machine can efficiently manufacture a variety of gear types, including gears, splines, and worms. Its semi-automatic operation and adjustable speeds allow precision adjustment for different manufacturing requirements.

Robust Construction and Safety Features

Constructed with a durable cast iron frame and weighing approximately 2,000 kg, this machine ensures longevity in heavy-duty environments. Integrated features such as centralized lubrication and an emergency stop button provide a safer and smoother workflow for operators.

Versatile and Efficient Performance

With its capacity for 2.5 module gears and ability to handle workpieces up to 250 mm in diameter, this gear hobbing machine meets the needs of manufacturers requiring versatility. The adjustable table and spindle speeds further optimize efficiency for various gear cutting tasks.

FAQs of Stanko USSR 2.5 Module Gear Hobbing Machine:

Q: How is the Stanko USSR 2.5 Module Gear Hobbing Machine operated for gear cutting?

A: This gear hobbing machine features a semi-automatic operation with X and Y axis movements, allowing users to set up workpieces, adjust table and spindle speeds, and initiate precision gear, spline, or worm cutting according to specific requirements.

Q: What types of gears and workpieces can be produced using this machine?

A: The Stanko USSR hobbing machine can cut gears, splines, and worms with a maximum diameter of 250 mm, 2.5 module capacity, and a minimum of 10 teeth. It accommodates workpieces up to 350 mm in length and utilizes hobs up to 120 mm in diameter.

Q: When should the centralized lubrication system be maintained?

A: The centralized lubrication system is designed for continuous operation; it is recommended to inspect and refill the lubrication at regular intervals according to the factory schedule to ensure optimal machine performance and component longevity.

Q: Where is this gear hobbing machine best installed?

A: This floor-mounted machine is suitable for installation in industrial manufacturing environments, such as workshops and factories specializing in gear production, where stable, robust equipment is essential.

Q: What is the process for adjusting table rotation and spindle speeds?

A: Operators can adjust the table rotation speed between 45 to 180 rpm and the spindle speed from 200 to 800 rpm. These settings accommodate different types of gears and cutting processes for enhanced precision and efficiency.

Q: How does the machine benefit manufacturers and exporters in gear production?

A: With its semi-automatic precision, high-output capability, and robust USSR-era construction, manufacturers and exporters benefit from reliable, high-quality gear production, reduced downtime, and flexibility for multiple gear types and sizes.
