TOS 6 Module 600 mm Diameter Gear Hobbing Machine

Name: TOS 6 Module 600 mm Diameter Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS 6 Module 600 mm Diameter Gear Hobbing Machine Specification

Condition
Used

Weight
Approx. 3500 kg

Capacity
6 Module, max workpiece diameter 600 mm

Power
5.5 kW main motor

Output
Accurate Spur, Helical and Worm Gears

Dimension (L*W*H)
Approx. 2200 mm x 1500 mm x 2000 mm

Color
Industrial Green

Feature
High precision, robust construction, easy operation

Machine Type
Gear Hobbing Machine

Voltage
380 V, 3 Phase

Used For
Hobbing gears up to 600 mm diameter

Coolant System
Included

Max. Hob Length
180 mm

Distance Between Centres
60 - 600 mm

Floor Space Required
Approx. 4 m x 2 m

Lubrication System
Automatic Lubrication

Max. Table Load
600 kg

Max. Gear Width
220 mm

Hob Spindle Speed Range
40 to 400 rpm

Precision Class
ISO Certified

Country of Make
Czech Republic (TOS)

Table Speed Range
4 to 200 rpm

Max. Cutting Module
6 Module

Max. Hob Diameter
160 mm

Table Bore Diameter
80 mm

Control Type
Conventional Manual

TOS 6 Module 600 mm Diameter Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS 6 Module 600 mm Diameter Gear Hobbing Machine

Make - TOS (Czech Republic)

Model - FO-6

Max. Module - 6 modules

Max. Diameter of Gear (with Tail-Stock) - 600 mm

Table Diameter - 420 mm

Vertical Travel of Hob Slide - 350 mm

Hob Cutter Speeds - 15 rpm to 190 rpm

- Complete with Change Gears, Arbours, Mandrels etc.

- Operating Manual and Electrical Drawings are available.

- Machine is in excellent working condition.

Video Of The Machine -

https://youtu.be/g5_i3G2p1w0

High Precision and Versatility

The TOS 6 Module 600 mm Diameter Gear Hobbing Machine stands out for its high-precision cutting capability and robust construction. Its capacity to cut up to 6 module gears and handle workpieces with a diameter up to 600 mm allows for flexible operation across various gear types, including spur, helical, and worm gears. The machine's ISO-certified class ensures consistent, quality results every time.

User-Friendly Operation and Maintenance

Engineered for straightforward usage, the machine features conventional manual controls, making it accessible for a wide range of operators. The inclusion of an automatic lubrication system reduces maintenance efforts, while a reliable coolant system helps to prolong tool and machine life during extended production runs.

Efficiency and Durability in Industrial Settings

With a heavy-duty table capable of supporting up to 600 kg and a sturdy 5.5 kW motor, this gear hobbing machine is designed for demanding industrial tasks. Its floor space requirement of approximately 4 m x 2 m makes it suitable for most manufacturing environments, combining substantial output with manageable footprint and energy use.

FAQ's of TOS 6 Module 600 mm Diameter Gear Hobbing Machine:

Q: How does the TOS 6 Module 600 mm Gear Hobbing Machine ensure high precision in gear cutting?

A: The machine is ISO certified for precision, features robust construction, and utilizes an automatic lubrication system to maintain accuracy throughout the production process.

Q: What types of gears can be produced with this hobbing machine?

A: You can manufacture accurate spur, helical, and worm gears with a maximum diameter of 600 mm and up to 6 module cutting capacity.

Q: Where is this gear hobbing machine manufactured and what is its build quality like?

A: This machine is manufactured in the Czech Republic by TOS, recognized for its high-quality, durable, and precise machine tools.

Q: What is the maximum workpiece size and table load the machine can handle?

A: The TOS machine accommodates workpieces up to 600 mm in diameter and a maximum gear width of 220 mm, with a table load capacity of 600 kg.

Q: How does the machine support reliable and prolonged operation?

A: It includes an automatic lubrication system for reduced wear, a coolant system to prevent overheating, and heavy-duty components engineered for continuous, industrial use.

Q: What are the power requirements and operational speed ranges for this machine?

A: The gear hobbing machine operates on 380V, 3 phase power, with a 5.5 kW main motor, hob spindle speeds from 40 to 400 rpm, and table speeds from 4 to 200 rpm.

Q: What are the key benefits of using this gear hobbing machine in a manufacturing setup?

A: Key benefits include high precision, robust performance, user-friendly controls, versatility for various gear types, and reliable output for industrial manufacturing needs.
