TOS BUA-16A Precision Cylindrical Grinder

Name: TOS BUA-16A Precision Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS BUA-16A Precision Cylindrical Grinder Specification

Product Type
Precision Cylindrical Grinder

General Use
Industrial Grinding, Metalworking

Material
Cast Iron and Steel

Type
Horizontal

Capacity
250 mm

Weight (kg)
2500 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual

Drive Type
Electric Motor Driven

Grinding Diameter
160 mm

Grinding Length
320 mm

Spindle Speed
2100 RPM

Grinding Wheel Size
400 x 40 x 203 mm

Voltage
415 V

Dimension (L*W*H)
2100 x 1300 x 1500 mm

Feature
High Precision, Heavy-Duty Construction, Accurate Operation

Color
Industrial Green/Grey

Power Required
3.5 kW

Surface Finish
Up to 1.5 Ra m

Coolant Equipment
Equipped

Tailstock
Included

Distance Between Centres
400 mm

Chuck Size
Optional

Table Traverse
430 mm

Wheel Speed
35 m/s

Internal Grinding Attachment
Available

Centre Height
100 mm

Workpiece Weight (max)
50 kg

TOS BUA-16A Precision Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS BUA-16A Precision Cylindrical Grinder

Make - TOS-Hostivar (Czech Republic)

Model - BUA 16 A

Max. Diameter of Job - 160 mm

Max. Length of Job - 300 mm

Grinding Wheel Size - Diameter 250 mm x 25 mm Width

Least Count of Wheel-Head Slide - 1 Micron (0.001 mm)

Table Rotation - 10 degree to -10 degree

- Micro-Feed Adjustments in both - Table Longitudinal Travel & in Wheel-Head Travel.

- Features like Auto-Cut, Auto-Compensation, Plunge, Auto-Slow etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/YGdVq6YJ0Mw

Built for Precision and Durability

The TOS BUA-16A is constructed from robust cast iron and steel, ensuring long-lasting performance in demanding industrial environments. Its heavy-duty frame minimizes vibration, allowing for accurate grinding operations on various metals. The industrial green/grey finish reflects its professional build and continuous use capability.

Versatile Grinding Capabilities

Designed for both external and internal cylindrical grinding, this machine supports components of up to 400 mm between centers and 50 kg in weight. The included internal grinding attachment and fully featured tailstock offer flexibility for diverse metalworking applications, making it suitable for exporters, manufacturers, and traders alike.

Efficient Operation and Control

The semi-automatic TOS BUA-16A features a manual control system, enabling operators to fine-tune grinding operations with accessibility and precision. Its electric motor-driven system delivers consistent results, and the powerful coolant equipment ensures both the tool and workpiece remain at optimal temperatures throughout prolonged use.

FAQ's of TOS BUA-16A Precision Cylindrical Grinder:

Q: How does the TOS BUA-16A ensure high-precision grinding?

A: The TOS BUA-16A is built with a rigid cast iron and steel structure and operates at a wheel speed of 35 m/s. This robust build, combined with a spindle speed of 2100 RPM, minimizes vibrations and allows for consistent accuracy, achieving surface finishes as fine as 1.5 Ra m.

Q: What types of workpieces are suitable for this grinder?

A: This grinder is perfect for cylindrical components made from cast iron, steel, and similar metals, with diameters up to 160 mm, lengths up to 320 mm, and total weights not exceeding 50 kg. It is widely used in industrial settings for precision metalworking tasks.

Q: When should the internal grinding attachment be used?

A: The internal grinding attachment is designed for operations that require machining of inner surfaces or bores within workpieces. Use this attachment when your application demands tight internal tolerances or smooth internal finishes.

Q: Where is the TOS BUA-16A typically installed or used?

A: The BUA-16A is commonly found in industrial workshops, manufacturing plants, and job shops, particularly those involved in metalworking, automotive, and machinery production. Its standard dimensions (2100 x 1300 x 1500 mm) make it suitable for standard production floor layouts.

Q: What is the process for operating the grinder's table traverse and tailstock?

A: The machine's table traverse, measuring 430 mm, is manually controlled, allowing the operator to precisely position the workpiece. The heavy-duty tailstock supports the workpiece, ensuring stability and accuracy during grinding operations.

Q: How does the coolant equipment benefit the grinding process?

A: The integrated coolant system helps maintain low temperatures on both the grinding wheel and workpiece, preventing thermal distortion and tool wear. This ensures a consistent surface finish and prolongs the lifespan of grinding components.

Q: What are the advantages of choosing a semi-automatic, non-computerized grinder like this model?

A: Semi-automatic, manually controlled grinders like the TOS BUA-16A provide hands-on control, allowing skilled operators to adjust settings for each specific task. This flexibility is ideal for custom jobs, small batch production, or situations requiring direct operator oversight for highest accuracy.
