Send InquiryZocca 1000 mm Universal Cylindrical Grinder
Price 6000 INR/ Piece
MOQ : 1 Piece
Zocca 1000 mm Universal Cylindrical Grinder Specification
- Product Type
- Universal Cylindrical Grinder
- General Use
- Precision Grinding of Metal Cylindrical Parts
- Material
- Cast Iron Body, Precision Steel Components
- Type
- Manual
- Capacity
- 1000 mm Between Centers
- Weight (kg)
- Approx. 2500 kg
- Computerized
- No
- Automatic
- No
- Control System
- Manual Control
- Drive Type
- Belt Driven
- Grinding Diameter
- 250 mm
- Grinding Length
- 1000 mm
- Spindle Speed
- Up to 1800 RPM
- Grinding Wheel Size
- 350 mm x 50 mm x 127 mm
- Voltage
- 415 V
- Dimension (L*W*H)
- Approx. 2500 x 1600 x 1500 mm
- Feature
- Universal; Suitable for External and Internal Grinding
- Color
- Machine Grey with Blue Accents
- Wheel Head Motor Power
- 2.2 kW (3 HP)
- Application
- Automotive, Tool Room, General Engineering
- Max Job Weight Between Centers
- 150 kg
- Workhead Speed Range
- 45-350 RPM
- Centre Height
- 135 mm
- Tailstock Quill Travel
- 35 mm
- Internal Grinding Spindle Speed
- Up to 24000 RPM
- Lubrication System
- Centralized
- Coolant System
- Included
About Zocca 1000 mm Universal Cylindrical Grinder
Zocca (Italy) make Hydraulic Universal Cylindrical Grinding Machine in excellent working condition.The model of the machine is RU 1000 and the technical details are as follows -
Make - Zocca (Italy)
Model - RU 1000
Center Height - 180 mm
Max. Diameter of Job - 360 mm
Length of Job - 1000 mm (1100 mm)
Grinding Wheel Diameter - 450 mm
Grinding Wheel Width - 50 mm
- With Internal Grinding Attachment.
- Complete with Wheel Dresser.
- Features like Delay Feature, Hydraulic Tail-Stock.
- Complete with coolant tank & pump and many other accessories.
- Machine is in excellent working condition.
Video Link - https://youtu.be/nKu64IkMxss
Versatile Precision Grinding Solution
Adaptable for both external and internal cylindrical grinding, the Zocca 1000 mm Universal Cylindrical Grinder meets the needs of a wide array of metalworking applications. Its universal design and manual controls make it ideal for automotive, tool room, and general engineering settings, offering superior accuracy and repeatability for intricate tasks.
Robust Construction and Reliable Performance
Manufactured using a cast iron body and precision steel components, this grinder offers exceptional rigidity and stability during operation. With a capacity of 1000 mm between centers and a grinding diameter of 250 mm, it can efficiently handle diverse workpieces while reducing vibrations for enhanced surface finish quality.
Convenient and Efficient Operation
Featuring a centralized lubrication system and included coolant mechanism, the Zocca grinder facilitates smooth operation and ease of maintenance. Its manual belt-driven structure allows for direct control and fine adjustments tailored to specific job requirements, resulting in optimal grinding results every time.
FAQs of Zocca 1000 mm Universal Cylindrical Grinder:
Q: How do I operate the Zocca 1000 mm Universal Cylindrical Grinder?
A: The Zocca cylindrical grinder is manually controlled, allowing you to set and adjust workhead speed, spindle speed, grinding wheel parameters, and job positioning. Refer to the user manual for safety precautions and step-by-step setup instructions for both external and internal grinding processes.Q: What materials and components are suitable for grinding with this machine?
A: This grinder is ideal for precision grinding of metal cylindrical parts, particularly those used in automotive, tool room, and general engineering applications. It features a cast iron body and precision steel components, ensuring stability and accuracy when working with various metals.Q: When should the centralized lubrication system be maintained?
A: Regular maintenance of the centralized lubrication system is recommended, typically after every 100 hours of operation or as specified in the manufacturers maintenance schedule. Proper lubrication ensures smooth movement, reduces wear, and increases the lifespan of critical machine parts.Q: Where can I install the Zocca Universal Cylindrical Grinder?
A: With approximate dimensions of 2500 x 1600 x 1500 mm and a weight of 2500 kg, the machine should be installed in a well-prepared, stable workshop with adequate space and a 415 V power supply. Proper installation reduces vibration and improves safety.Q: What is the process for achieving internal grinding with this model?
A: To perform internal grinding, use the grinders internal spindle, which operates up to 24,000 RPM. Mount appropriate fixtures and grinding wheels, secure the workpiece, and follow the stepwise adjustment protocols outlined in the manual for precise results.Q: How does the coolant system benefit the grinding operation?
A: The included coolant system maintains a stable grinding temperature, flushes away debris, and prevents thermal distortion of both workpiece and grinding wheel. This enhances surface finish quality and prolongs the life of machine components.Q: What advantages does manual control offer for precision grinding?
A: Manual control enables the operator to make detailed adjustments and respond promptly to specific job requirements. This ensures higher precision and versatility, particularly for intricate or customized metal grinding tasks.
