Ajax England 40 mm All Geared Pillar Drilling Machine

Name: Ajax England 40 mm All Geared Pillar Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ajax England 40 mm All Geared Pillar Drilling Machine Specification

Features
Heavy Duty, All Geared Head, Precise Drilling

Table Size
500 x 500 mm

Machine Type
Pillar Drilling Machine

Noise Level
Low

Spindle Speed
8 Speed, 62 to 2000 RPM

Motor Power
3 HP

Diameter
Drilling Capacity 40 mm

Frequency
50 Hz

Cutting Area
Cylindrical up to 40 mm

Dimension (L*W*H)
1150 x 650 x 2100 mm

Condition
New

Product Type
All Geared Pillar Drilling Machine

Material
Cast Iron Body

Computerized
No

Automatic Grade
Manual

CNC Or Not
Not CNC

Control System
Mechanical Lever

Voltage
415 V

Power
2.2 kW (3 HP)

Power Source
Electric

Weight (kg)
Approx. 750 kg

Capacity
40 mm in Steel

Color
Industrial Blue/Grey

Usage & Applications
For Drilling, Tapping, Reaming in Workshops & Industrial Factories

Coolant System
Provided

Base Size
600 x 430 mm

Table Travel
400 mm

Drive Type
All Geared

Spindle Travel
250 mm

Distance from Spindle to Table
690 mm

Spindle Taper
MT-4

Maximum Drilling Depth
250 mm

Distance from Spindle to Base
1150 mm

Column Diameter
120 mm

Number of Gears
8

Ajax England 40 mm All Geared Pillar Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ajax England 40 mm All Geared Pillar Drilling Machine

Make - Ajax (England/Bulgaria)

Capacity - 40 mm

Spindle Diameter - 75 mm

Spindle Taper - MT 4

Spindle Feed Travel - 255 mm

Spindle Speeds - 56 rpm to 1000 rpm

Spindle Feed Travel Rates - 0.10 mm/rev to 0.25 mm/rev

Table Size - 400 mm x 400 mm

Base Clamping Size - 565 mm x 445 mm

Distance between Spindle Center to Vertical Pillar - 320 mm

Height between Spindle to Top of Base - 1185 mm

Max. Height between Spindle to Table Top - 715 mm

Min. Height between Spindle to Table Top - 70 mm

Vertical Pillar Diameter - 152 mm

- Equipped with Coolant Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/yT4vAdv5OPE

Precision Engineering for Demanding Tasks

The Ajax England 40 mm All Geared Pillar Drilling Machine is tailored for reliability and accuracy, making it suitable for various industrial tasks like drilling, tapping, and reaming. Its heavy-duty, all-geared head and solid cast-iron body ensure stable performance and consistent precision, even with tough materials.

Heavy-Duty Construction and User-Friendly Design

Crafted with a robust cast-iron frame and a large base, this pillar drilling machine promises longevity and stability. The thoughtfully engineered spindle travel and gear range accommodate a wide array of workshop tasks, while the manual control lever provides intuitive operation for operators of all skill levels.

Enhanced Productivity and Versatile Applications

Equipped with a spacious work table and an efficient coolant system, this machine is ideal for demanding production environments. Its eight-speed gearbox allows seamless adjustments, facilitating various applications from simple drilling in steel to precise tapping and reaming, ultimately boosting productivity and flexibility.

FAQ's of Ajax England 40 mm All Geared Pillar Drilling Machine:

Q: How does the all-geared driving mechanism benefit industrial users?

A: The all-geared drive in the Ajax England Pillar Drilling Machine facilitates smooth and efficient transfer of power from the motor to the spindle, resulting in consistently precise rotation and allowing easy speed changes to suit different materials and tasks. This enhances accuracy and productivity in workshop settings.

Q: What materials and applications is the Ajax 40 mm Pillar Drilling Machine suitable for?

A: This machine is designed for drilling, tapping, and reaming, particularly in industrial workshops and factories. Its robust build and 40 mm drilling capacity in steel make it ideal for processing a variety of metals and other tough materials, accommodating both light and heavy-duty applications.

Q: When should I use the coolant system provided with the machine?

A: The coolant system should be used during extended drilling or machining sessions, especially with hard metals, to prevent overheating of tools and workpieces. This helps maintain dimensional accuracy and prolongs tool life, ensuring smoother operation and safer, more efficient workflows.

Q: Where can the Ajax pillar drilling machine be installed?

A: Designed for industrial environments, this machine is best installed in workshops and factories with adequate space to accommodate its dimensions (1150 x 650 x 2100 mm) and a compatible three-phase power supply (415 V). Solid, level flooring is recommended for best performance and safety.

Q: What is the process for adjusting spindle speeds on this machine?

A: Spindle speeds can be easily adjusted through the mechanical lever that controls the 8-gear system, allowing users to select any speed between 62 and 2000 RPM. This process enables operators to adapt the drilling speed precisely according to material properties and desired machining operations.

Q: How does the manual control system affect operation?

A: The mechanical lever control system offers users hands-on adjustment and precise control over drilling operations. Its straightforward design ensures reliability and allows operators to fine-tune spindle movement for meticulous tasks, maintaining safety and high-quality output.

Q: What are the key benefits of using this machine in an industrial setting?

A: Key benefits include its heavy-duty construction, high drilling precision, versatile speed options, low operational noise, and a built-in coolant system. These features synergize to deliver reliable, efficient, and accurate results for a wide range of industrial machining needs.
