Ajax England Universal Cylindrical Grinder Machine

Name: Ajax England Universal Cylindrical Grinder Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ajax England Universal Cylindrical Grinder Machine Specification

Product Type
Universal Cylindrical Grinder Machine

General Use
Precision external and internal grinding of cylindrical and conical parts

Material
Cast Iron (Body), Hardened Steel (Working Parts)

Capacity
Between centres: 1000 mm

Weight (kg)
Approx. 2500

Computerized
No

Automatic
No

Control System
Manual lever and wheel operation

Drive Type
Belt Driven

Grinding Diameter
Up to 250 mm

Grinding Length
Up to 1000 mm

Spindle Speed
Variable, up to 1800 RPM

Grinding Wheel Size
350 mm x 40 mm x 127 mm

Voltage
415V, 3 Phase

Dimension (L*W*H)
Approx. 2500 mm x 1700 mm x 1400 mm

Feature
Swiveling workhead, Internal and external grinding capability, Heavy-duty construction

Color
Industrial Green/Blue

Grinding Accuracy
Within 0.002 mm

Internal Grinding Spindle
Available (Optional)

Max Workpiece Weight
Approx. 80 kg

Distance Between Centers
1000 mm

Center Height
165 mm

Coolant System
Integrated

Work Head Taper
MT4

Motor Power
2.2 kW

Wheelhead Motor Power
2 HP

Table Swivel Range
+/- 9°

Headstock Swivel Range
360°

Cross-Fee Travel
Approx. 210 mm

Ajax England Universal Cylindrical Grinder Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ajax England Universal Cylindrical Grinder Machine

Make - Ajax (England)

Model - AJ.260

Center Height - 130 mm

Max. Diameter of Job - 260 mm

Max. Length of Job - 500 mm

Grinding Wheel Size - 400 mm Diameter x 50 mm Width

Least Count of the Machine - 1 Micron (0.001 mm)

Work-Head Speeds - 56 rpm to 630 rpm

Internal Grinding Spindle Diameter - 80 mm

- Equipped with Internal Grinding Attachment.

- Complete with many different types of Wheel Dressers.

- Lots of Accessories like Wheels, Chucks, Centers, Gauges etc. etc.

- Features like Auto-Cut, Delay, Auto-Compensation, Spark-Out etc.

- Features like Plunge Grinding, Automatic Wheel Retraction etc.

- Machine can work in complete Auto-Cycle Mode.

- Complete with Coolant Tank & Pump.

- Operating Manual and Electrical Drawings are available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/d_gfmYlBj6Y

Heavy-Duty Construction and Design

Built with a solid cast iron base and hardened steel components, the Ajax Universal Cylindrical Grinder ensures excellent vibration dampening and durability. Its industrial green/blue finish signifies ruggedness tailored for intensive operations, while its manual control system offers tactile feedback for precision grinding.

Versatile Grinding Capabilities

This machine supports both external and internal grinding jobs with optional internal grinding spindle. The swiveling workhead and table make it suitable for a range of cylindrical and conical components, beneficial for exporters, manufacturers, and workshop traders seeking flexibility in machining options.

Precision Performance and Operation

With a grinding accuracy within 0.002 mm and a wheelhead motor rated at 2 HP, the Ajax Cylindrical Grinder delivers consistent, high-quality results. Its advanced coolant system supports continuous operation, ensuring both the machine and workpieces remain within optimal temperature for sustained accuracy.

FAQ's of Ajax England Universal Cylindrical Grinder Machine:

Q: How is the Ajax England Universal Cylindrical Grinder Machine used in precision manufacturing?

A: This machine is employed for precision external and internal grinding of cylindrical and conical parts. Its fine-tuned manual controls and integrated coolant system ensure high accuracy, making it ideal in environments requiring exact tolerances and smooth finishes for industrial components.

Q: What types of materials can be processed using this grinder?

A: The Ajax Cylindrical Grinder's robust construction is suitable for grinding components from metals such as steel, cast iron, and hardened alloys, accommodating workpieces up to 80 kg. It is designed for heavy-duty machining environments in manufacturing and repair workshops.

Q: Where is the Ajax Universal Cylindrical Grinder typically installed?

A: This machine is commonly installed in industrial workshops, factories, and toolrooms. Its solid construction and dimensional size make it well-suited for both standalone use and integration into larger production lines by exporters, manufacturers, and traders.

Q: What benefits does the table and headstock swivel feature provide?

A: The table's +/-9 swivel range and headstock's full 360 rotation enable precise setting for complex grinding jobs, allowing users to easily accommodate a variety of component shapes and angles. This adaptability increases job versatility and enhances machining efficiency.

Q: When would the optional internal grinding spindle be necessary?

A: The internal grinding spindle is beneficial when processing parts that require internal surfaces to be ground, such as bushings and bearing races. It expands the machine's capability for detailed finishing, making it suitable for job shops handling diverse component needs.

Q: How does the integrated coolant system enhance operation?

A: The built-in coolant system maintains low temperatures during grinding, reducing heat buildup and preventing thermal expansion, which could affect accuracy. This feature supports longer operational cycles and helps maintain the tight tolerance of within 0.002 mm.

Q: What is the process for operating this cylindrical grinder?

A: Operation involves manually setting the workpiece between centers and using the lever and wheel controls to position the table and headstock as needed. The variable spindle speed and coolant flow are adjusted for the material and grinding job, ensuring precise and safe completion of each cycle.
