Alpa Italy RT-800 Surface Grinding Machine

Send Inquiry

Request To Call Back

Alpa Italy RT-800 Surface Grinding Machine

Name: Alpa Italy RT-800 Surface Grinding Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000.0 INR
Availability: InStock

Price 100000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Alpa Italy RT-800 Surface Grinding Machine Specification

Rotation
Horizontal

Model
RT-800

Product Type
Surface Grinding Machine

General Use
Alpa (Italy) make Surface Grinding Machine in excellent working condition. The model of the machine is the RT-800 and the Magnet Size is 300 mm x 800 mm. It is an Extra-Height machine with a maximum Height between Magnet Top and the Wheel Center of 565 mm. The technical details are as follows -

Material
Cast Iron, Mild Steel

Type
Horizontal Spindle

Capacity
Heavy Duty

Weight (kg)
Approx. 2200 kg

Computerized
No

Automatic
Semi-Automatic

CNC Or Not
Not CNC

Control System
Manual / Semi-Automatic

Table Size
Approx. 800 x 400 mm

Table Slide Way
V and Flat Guideways

Magnetic Chuck Size
800 mm

Grinding Wheel Size
Standard (refer to manual)

Grinding Wheel Speed
Approx. 1400 rpm

Grinding Length
800 mm

Floor Space
Approx. 2200 x 1500 mm

Fuel Tank Capacity
Standard (refer to technical sheet)

Spindle Speed
Approx. 1400 rpm

Power
Approx. 5 HP

Voltage
415 V / 3 Phase

Dimension (L*W*H)
Approx. 2200 x 1500 x 2000 mm

Feature
High Precision, Robust Construction

Color
Green

Lubrication System
Centralized Lubrication

Condition
Used, Excellent Working Condition

Table Cross Travel
340 mm

Table Longitudinal Travel
900 mm

Coolant System
Yes, Fitted

Max Grinding Height Under Wheel
400 mm

Working Speed
Variable Table Speed

Application
Precision Surface Grinding for Tool Room and Production

Alpa Italy RT-800 Surface Grinding Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
1 Piece Per Week

Delivery Time
7 Days

About Alpa Italy RT-800 Surface Grinding Machine

Make - Alpa (Italy)

Model - RT-800

Magnet Size - 300 mm x 800 mm

Longitudinal Travels - 935 mm

Cross Travels - 400 mm

Grinding Wheel Size - Diameter 300 mm x 50 mm Width

Max. Height between Magnet Top to Wheel Center - 565 mm

- Equipped with a Wheel-Top Mounted Wheel Dresser.

- Feature of Automatic Depth Adjustment.

- Complete with Coolant tank & Coolant Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/zlUOC8hih-o

Superior Precision and Versatility

The RT-800 excels in delivering accurate grinding results, thanks to its horizontal spindle design and precision hand wheel graduations. With a maximum table travel of 900 mm and a vertical clearance of 565 mm, it accommodates a range of workpieces, making it suitable for various industrial applications requiring high precision.

Efficient and User-Friendly Operation

Featuring manual or semi-automatic control and variable speed options, the RT-800 allows operators to fine-tune working speeds for optimal surface finish and efficiency. Its centralized automatic lubrication system and integrated coolant unit ensure smooth operations and reduce maintenance downtime.

Robust Construction and Durability

Constructed from cast iron and mild steel, the RT-800 is engineered for durability and stability. The V and flat guideways on the table ensure long-lasting accuracy and minimal wear, while the low-noise design offers a comfortable working environment.

FAQ's of Alpa Italy RT-800 Surface Grinding Machine:

Q: How does the Alpa Italy RT-800 Surface Grinding Machine handle lubrication and cooling during operation?

A: The RT-800 is equipped with a centralized automatic lubrication system that ensures all moving parts receive consistent lubrication, reducing wear and maintenance needs. The machine also features an integrated coolant system, which helps maintain optimal temperatures and ensures a smooth surface finish while grinding.

Q: What types of materials can the RT-800 grind and what is its maximum workpiece size?

A: This machine can effectively grind components made from cast iron, mild steel, and similar robust materials. With a magnetic chuck size of 800 mm and a maximum table travel of 900 mm, it supports large and heavy-duty workpieces, making it ideal for a variety of industrial grinding applications.

Q: When is reconditioning possible for this machine, and in what condition is it generally supplied?

A: The Alpa RT-800 is primarily supplied in good, working condition, ensuring immediate usability. However, reconditioning services can be provided upon request, allowing the machine to be refurbished to meet specific operational standards or preferences.

Q: Where was the RT-800 manufactured and what are its main export advantages?

A: This surface grinding machine is manufactured in Italy and is well-regarded for its high build quality and precision engineering. Its robust performance and reliability make it a preferred choice for exporters, importers, manufacturers, and traders seeking dependable grinding solutions.

Q: What is the typical process for using the RT-800 for surface grinding?

A: To operate the RT-800, the workpiece is secured on the electro-magnetic chuck. The operator sets the grinding parameters using the manual or variable feed controls, adjusts the hand wheel for depth of cut, activates the coolant system, and commences surface grinding. The machine's precision adjustments and stable table guideways facilitate excellent results.

Q: What are the key benefits of using the RT-800 over standard surface grinding machines?

A: The RT-800 provides extra height for larger workpieces, high-precision grinding capabilities, and user-friendly manual or semi-automatic controls. Its heavy-duty construction, automatic lubrication system, and efficient coolant setup contribute to longer service life, reduced operational noise, and consistent surface quality.
