Berco 1600 mm External Cylindrical Grinder

Send Inquiry

Request To Call Back

Berco 1600 mm External Cylindrical Grinder

Name: Berco 1600 mm External Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 78000 INR
Availability: InStock

Price 78000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Berco 1600 mm External Cylindrical Grinder Specification

Product Type
External Cylindrical Grinder

General Use
Grinding external cylindrical surfaces

Material
Cast Iron, Steel

Type
Heavy Duty Grinder

Capacity
1600 mm between centers

Weight (kg)
Approx. 4000 kg

Computerized
No

Automatic
Semi-Automatic

Control System
Manual/PLC (varies by configuration)

Drive Type
Electric Motor

Grinding Diameter
Max 350 mm

Grinding Length
1600 mm

Spindle Speed
20 - 1200 RPM (variable)

Grinding Wheel Size
500 x 80 x 203 mm

Voltage
415 V, 3 Phase, 50 Hz

Dimension (L*W*H)
3400 x 1500 x 1800 mm

Feature
Precision grinding, robust construction, adjustable wheelhead

Color
Grey/Green

Wheelhead Movement
Hydraulic/Manual

Max Workpiece Weight
Up to 350 kg

Lubrication System
Centralized Automatic

Bed Type
Hardened and ground

Power Consumption
Approx. 7.5 kW

Workpiece Mounting
Centers/Chucks

Table Traverse
Manual/Automatic

Tailstock
Manually Operated

Coolant System
Integrated

Wheel Dressing Device
Built-in

Accuracy
0.003 mm

Berco 1600 mm External Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Berco 1600 mm External Cylindrical Grinder

Make - Berco (Italy)

Model - RUY180

Center Height - 180 mm

Max. Job Diameter - 360 mm

Max. Length of Job - 1600 mm

Grinding Wheel Size - Diameter 450 mm x 75 mm Width

- Features like Delay, Auto-Cut & Plunge Grinding.

- Equipped with Hydraulic Tail-Stock.

- Machine is in very good working condition.

Video of the Machine-

https://youtu.be/kAuAl3xzwao

Precision Engineering for Demanding Applications

The Berco 1600 mm External Cylindrical Grinder is built for industries requiring high accuracy and strong performance. Its robust construction, adjustable wheelhead, and built-in wheel dressing device allow for efficient grinding operations on heavy workpieces. The manually operated tailstock and hydraulic/manual wheelhead movement provide flexibility, catering to both simple and complex grinding tasks.

Integrated Systems for User Convenience

Featuring an integrated coolant system and a centralized automatic lubrication system, this grinder maximizes efficiency while minimizing routine maintenance. The table traverse offers both manual and automatic options, giving operators control over the grinding process. With centralized lubrication, critical machine parts remain optimally oiled for prolonged machine life and consistent performance.

FAQs of Berco 1600 mm External Cylindrical Grinder:

Q: How is the workpiece mounted on the Berco 1600 mm External Cylindrical Grinder?

A: The workpiece can be mounted using centers or chucks, allowing for stable and accurate positioning during grinding operations. This flexibility accommodates a variety of workpiece shapes and sizes.

Q: What types of materials can this cylindrical grinder handle?

A: The machine is designed for use with cast iron and steel workpieces, making it suitable for heavy-duty industrial applications where robust and precise machining is required.

Q: When should the built-in wheel dressing device be used?

A: The built-in wheel dressing device should be employed whenever the grinding wheel needs to be reshaped or cleaned to maintain consistent grinding accuracy and surface finish during extended operations.

Q: Where is this grinder typically used?

A: The Berco 1600 mm grinder is commonly utilized in manufacturing plants, workshops, and facilities involved in exporting, importing, or supplying industrial machinery, especially in sectors requiring high-precision grinding.

Q: What is the benefit of the integrated coolant and centralized automatic lubrication systems?

A: The integrated coolant system efficiently manages heat during grinding, protecting both the workpiece and the machine, while the centralized automatic lubrication ensures all moving parts receive appropriate lubrication, reducing wear and maintenance frequency.

Q: How can operators control the grinding process on this machine?

A: Operators can select between manual and PLC (programmable logic controller) control systems, as well as manual or hydraulic wheelhead movement, offering flexibility to suit different operational preferences and application needs.

Q: What safety and precision features does the Berco 1600 mm grinder include?

A: With a hardened and ground bed, precise spindle speed control (20 1200 RPM), and accuracy up to 0.003 mm, the machine is equipped for both safety and high-precision performance in demanding environments.
