TOS Czech 400 mm Universal Cylindrical Grinder

Name: TOS Czech 400 mm Universal Cylindrical Grinder
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

TOS Czech 400 mm Universal Cylindrical Grinder Specification

Product Type
Universal Cylindrical Grinder

General Use
Precision grinding of cylindrical and conical surfaces

Material
Cast Iron, Steel

Type
Manual

Capacity
400 mm

Weight (kg)
1200

Computerized
No

Automatic
No

Control System
Manual Operation

Drive Type
Belt drive

Grinding Diameter
400 mm

Grinding Length
1000 mm

Spindle Speed
25-380 RPM

Grinding Wheel Size
400 x 50 x 203 mm

Voltage
415 Volt

Dimension (L*W*H)
2600 x 2500 x 1600 mm

Feature
High precision, Robust construction, Easy operation

Color
Industrial Green

Table Feed
Preset manual & automatic

Cross Feed
Manual & automatic

Application
Toolrooms, Workshops, Engineering Industries

Chuck Size
180 mm

Tailstock Quill Travel
40 mm

Max. Table Load
100 kg

Coolant System
Fitted

Workhead Spindle Motor Power
2 HP

Wheel Surface Speed
30 m/s

Headstock Taper
Morse Taper No. 5

Internal Grinding Attachment
Optional

Wheelhead Motor Power
3 HP

Grinding Wheel Speed
1900 RPM

TOS Czech 400 mm Universal Cylindrical Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About TOS Czech 400 mm Universal Cylindrical Grinder

Make - TOS (Czech Republic)

Model - 1U

Center Height - 130 mm

Max. Diameter of Job - 250 mm

Max. Length of Job - 400 mm

Grinding Wheel Size - Diameter 300 mm x 32 mm Width

Work-Head Speed - 38 rpm to 380 rpm (Continuously Variable)

- Features like Delay, Auto-Slow, Auto-Cut etc.

- Complete with Coolant Tank and Pump.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1QDgSXK-j5U

Superior Construction and Performance

Built with a solid cast iron and steel frame, the TOS Czech Universal Cylindrical Grinder provides outstanding durability and stability during high-precision operations. Its powerful 3 HP wheelhead motor and 2 HP workhead motor ensure consistent results even during extended use. The industrial green finish underscores its robust construction, making it a reliable choice for demanding workshop environments.

Flexible Grinding Applications

This universal cylindrical grinder is highly versatile, catering to diverse grinding needs in toolrooms, workshops, and various engineering industries. It supports both cylindrical and conical surface grinding and features a chuck size of 180 mm. Manual and automatic feed options allow for adaptable, precise work, with an optional internal grinding attachment to further expand its range of applications.

Ease of Operation and Maintenance

The grinder features intuitive manual operation controls and a preset table feed mechanism, simplifying workflow and reducing operator fatigue. The belt-driven system and integrated coolant system support efficient and safe operation, while its straightforward construction makes regular maintenance quick and hassle-free, keeping downtime to a minimum.

FAQ's of TOS Czech 400 mm Universal Cylindrical Grinder:

Q: How is the TOS Czech 400 mm Universal Cylindrical Grinder operated?

A: The machine is operated manually, featuring both preset manual and automatic table feed, as well as manual and automatic cross feed. All primary machine functions are controlled directly by the operator, ensuring precise and responsive grinding adjustments.

Q: What types of materials can be ground using this grinder?

A: The TOS Czech cylindrical grinder is suitable for precision grinding of cast iron, steel, and similar materials used in engineering industries, workshops, and toolrooms, making it highly versatile for a broad range of applications.

Q: When is the internal grinding attachment required?

A: The internal grinding attachment is optional and should be used when you need to perform precision internal surface grinding, such as for bores in cylindrical components. This feature broadens the machine's application without being necessary for standard external grinding tasks.

Q: Where is this cylindrical grinder typically utilized?

A: This machine is commonly used in toolrooms, engineering workshops, manufacturing facilities, and general industrial environments where precision cylindrical and conical grinding is required.

Q: What is the maximum workpiece size the grinder can accommodate?

A: The grinder is capable of handling workpieces with a maximum diameter of 400 mm, a grinding length up to 1000 mm, and a maximum table load of 100 kg, making it ideal for various medium-sized grinding tasks.

Q: How does the coolant system benefit the grinding process?

A: The fitted coolant system efficiently manages heat and debris during grinding, preserving the integrity of the workpiece, extending grinding wheel life, and ensuring consistent high-quality results.

Q: What are the main benefits of using the TOS Czech Universal Cylindrical Grinder?

A: Key benefits include high-precision grinding, flexible manual and automatic feeds, robust construction for long-term durability, easy maintenance, and suitability for both cylindrical and conical surfaces, ensuring consistent results for demanding industrial tasks.
