Caser Italy 100 mm Capacity Radial Drilling Machine

Send Inquiry

Request To Call Back

Caser Italy 100 mm Capacity Radial Drilling Machine

Name: Caser Italy 100 mm Capacity Radial Drilling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Caser Italy 100 mm Capacity Radial Drilling Machine Specification

Spindle Speed
90-1200 RPM

Table Size
1000 mm x 800 mm

Machine Type
Radial Arm

Features
High capacity, robust construction, adjustable radial arm, precise spindle movements

Motor Power
7.5 HP

Noise Level
72 dB

Dimension (L*W*H)
3600 mm x 1100 mm x 3300 mm

Condition
Used

Diameter
100 mm

Cutting Area
100 mm Max Drill Diameter

Frequency
50 Hz

Product Type
Radial Drilling Machine

Material
Cast Iron and Steel

Computerized
No

Automatic Grade
Semi-Automatic

CNC Or Not
No

Control System
Manual

Voltage
415 V

Power
7.5 HP

Power Source
Electric

Weight (kg)
4500 kg

Capacity
100 mm

Color
Industrial Grey

Usage & Applications
Heavy-duty drilling in metal fabrication, manufacturing industries, workshops

Spindle Taper
Morse Taper No.6

Clamping Type
Hydraulic

Coolant System
Included

Max Distance Spindle to Base
2700 mm

Safety Features
Emergency stop, overload protection

Number of Spindle Speeds
12 steps

Column Diameter
450 mm

Max Distance Spindle to Column
1600 mm

Installation Required
Yes

Packing Type
Wooden crate

Drilling Depth
400 mm

Base Size
2000 mm x 1500 mm

Lubrication Type
Centralized

Gear Type
Heavy-duty gear mechanism

Surface Finish
Smooth industrial enamel

Arm Length
2500 mm

Floor Space Required
3700 mm x 1200 mm

Caser Italy 100 mm Capacity Radial Drilling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

Caser Italy 100 mm Capacity Radial Drilling Machine About

Make - Caser (Italy)

Model - F. 80

Drilling Capacity (in Steel) - 100 mm

Spindle Diameter - 110 mm

Arm Length - 2600 mm

Spindle Speeds - 25 rpm to 1670 rpm

Spindle Taper - MT 5

Max. Spindle Feed Travel - 495 mm

Spindle Feed Travel Rates - 0.075 mm/rev to 1.00 mm/rev

Vertical Travel of the Arm - 860 mm

Table Size - 750 mm x 600 mm

Machine Weight - 11.7 Tons (Approximately)

Clamping Type - Hydraulic

- Feature of Motorised Left & Right Travels of the Drilling Head.

- With lots of Accessories like Quick Change Tool Adapter, Tapping Adapter etc.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/mUqo6mdBCQg

Heavy-Duty Performance and Precision

Designed for high-capacity and precise drilling, this machine is capable of handling up to 100 mm in drill diameter. Its robust cast iron and steel construction, combined with a heavy-duty gear mechanism, guarantees minimal vibration and stable operation, making it ideal for continuous industrial use.

Enhanced Safety and User Convenience

Equipped with an emergency stop button and overload protection, this radial drilling machine prioritizes operator safety. Hydraulic clamping provides secure and swift setups, while a centralized lubrication system ensures long-term reliability by maintaining optimal performance with minimum manual intervention.

Installation and Versatile Application

The machine requires professional installation and occupies a floor space of 3700 mm x 1200 mm-perfect for manufacturing units and workshops. Its adjustable radial arm and comprehensive spindle movement system accommodate a wide range of drilling applications, offering flexibility across metalworking tasks.

FAQ's of Caser Italy 100 mm Capacity Radial Drilling Machine:

Q: How does the hydraulic clamping system benefit the operator during drilling operations?

A: The hydraulic clamping system enables quick and secure locking of the machine components, allowing for easy adjustment and stable performance. This reduces manual effort and ensures precise alignment during heavy-duty drilling tasks.

Q: What materials can the Caser Italy 100 mm Capacity Radial Drilling Machine process?

A: The machine is engineered for heavy-duty drilling in metals, making it suitable for use on steel, cast iron, and other hard alloys commonly found in fabrication and manufacturing industries.

Q: When and where should this radial drilling machine be installed?

A: Installation should be carried out by professionals in an industrial workshop or manufacturing environment with adequate floor space (at least 3700 mm x 1200 mm). It is supplied in a wooden crate to ensure safe transportation and handling.

Q: What safety features are included to protect the user and the machine?

A: The machine includes an emergency stop button and overload protection, which safeguard both the operator and the equipment against accidents and mechanical stress during operation.

Q: How does the centralized lubrication system improve maintenance?

A: Centralized lubrication ensures that all key components receive consistent lubrication, reducing wear and tear. This system minimizes manual maintenance efforts and prolongs the lifespan of the machine.

Q: What is the process for adjusting speed and spindle movements on this drilling machine?

A: Operators can select from 12 spindle speed steps ranging from 90 to 1200 RPM using the control panel. The spindle and arm adjustments are manual, but designed for smooth and precise positioning for varied drilling requirements.
