Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine
Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine

Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine

Price 25000.0 INR/ Piece

MOQ : 1 Piece

Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine Specification

  • Spindle Speed
  • 55-1400 RPM (Multiple Steps)
  • Machine Type
  • Heavy-Duty Column Type
  • Cutting Area
  • Full Table Surface
  • Table Size
  • 700 x 540 mm (approx.)
  • Diameter
  • Max. Drilling Diameter: 50 mm
  • Noise Level
  • Low
  • Frequency
  • 50 Hz
  • Dimension (L*W*H)
  • Approx. 1100 x 850 x 2350 mm
  • Motor Power
  • 4.5 kW Electric Motor
  • Condition
  • Used/Excellent Working Condition
  • Features
  • Heavy Duty Construction, High Accuracy, Smooth Operation, Adjustable Table Height
  • Product Type
  • Heavy-Duty Column Type Drilling & Tapping Machine manufactured by Stanko (Russia), Model 2H135, available in excellent working condition. The machine has a Drilling Capacity of 40 mm, Spindle Diameter of 90 mm, and Main Spindle Motor Power of 4 kW. It is an all-geared machine equipped with Automatic Spindle Feed and is suitable for Drilling, Tapping, and Reaming Operations. The technical details are as follows -
  • Material
  • High-Grade Cast Iron / Steel Components
  • Computerized
  • No
  • Automatic Grade
  • Semi-Automatic
  • CNC Or Not
  • No, Conventional
  • Control System
  • Manual Lever/Push Button Panel
  • Voltage
  • 415 V (Three Phase)
  • Power
  • 4.5 kW
  • Power Source
  • Electric
  • Weight (kg)
  • Approx. 2500 kg
  • Capacity
  • Max Drilling: 50 mm, Max Tapping: 40 mm in Mild Steel (approx.)
  • Color
  • Industrial Green
  • Usage & Applications
  • Industrial Drilling, Tapping, Production Workshops, Engineering Applications
  • Quill Diameter
  • 72 mm
  • Base Type
  • Box Table with T-Slots
  • Spindle Travel
  • 200 mm
  • Distance from Spindle to Table
  • 700 mm (Max.)
  • Distance from Column to Spindle Center
  • 380 mm
  • Coolant System
  • Integrated Pump
  • Number of Spindle Speeds
  • 9 speeds
  • Safety Features
  • Emergency Stop, Overload Protection
  • Model
  • 2H135
  • Chuck Mount
  • Morse Taper MT4
  • Table Adjustment
  • Vertical (Manual crank handle)



About Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine

Make - Stanko (Russia)
Model - 2H135
Drilling Capacity - 40 mm
Spindle Diameter - 90 mm
Spindle Taper - MT-4
Spindle Feed Travel - 250 mm
Spindle Speed Range - 31.5 to 1400 RPM
Spindle Feed Rates - 0.1 to 1.6 mm/rev
Table Size - 500 mm x 450 mm
Distance between Spindle Centre and Column - 300 mm
Max. Height between Spindle and Table Top - 750 mm
Spindle Motor Power - 4 kW
Approx. Machine Weight - 1.18 Tons
- Features an All-Geared Head for Heavy-Duty Drilling and Tapping Operations.
- Features Automatic Spindle Feed.
- Suitable for Drilling, Tapping, and Reaming Operations.
- Machine is in excellent working condition.

Video of The Machine -


Outstanding Performance for Heavy-Duty Tasks

Equipped with a 4.5 kW electric motor and a spindle capable of 55-1400 RPM across nine speed settings, the Stanko Russia 2H135 handles demanding drilling and tapping operations with ease. It accommodates large workpieces with a maximum drilling diameter of 50 mm and tapping up to 40 mm in mild steel, making it ideal for tough industrial environments.


Versatility and Precision Engineering

The machine's manual crank table adjustment allows for precise vertical movement and positioning, while a spindle-to-table distance up to 700 mm maximizes operational flexibility. With its robust construction, box table featuring T-slots, adjustable speed settings, and Morse Taper MT4 chuck mount, this machine ensures high accuracy and consistent results across varied applications.

FAQ's of Stanko Russia 2H135 Heavy-Duty Column Drilling and Tapping Machine:


Q: How does the Stanko Russia 2H135 ensure both safety and reliability during operation?

A: This machine is built with high-grade cast iron and steel components for maximum durability. It includes essential safety features such as an emergency stop and overload protection, ensuring safe operation for users, even during extended industrial use.

Q: What is the process for adjusting the working table height on this machine?

A: The table height on the 2H135 is adjusted manually using a crank handle. This allows operators to precisely set the optimal position for drilling or tapping, accommodating a range of workpiece sizes and enhancing machining versatility.

Q: When is the Stanko 2H135 most beneficial in industrial applications?

A: The machine is particularly advantageous for heavy-duty production environments requiring accurate, repeatable drilling and tapping operations on large or thick workpieces. Its high power output, large spindle travel, and multiple speed options make it suitable for workshops demanding robust and consistent performance.

Q: Where can this drilling and tapping machine be installed?

A: The 2H135 is best suited for installation in industrial settings such as production workshops, engineering facilities, manufacturing plants, and repair shops where heavy-duty machining operations are conducted regularly.

Q: What are the main benefits of using the integrated coolant pump system?

A: The integrated coolant pump helps dissipate heat during drilling or tapping, minimizing tool wear and workpiece deformation. This enhances cutting efficiency, prolongs tool life, and supports smooth, high-quality machining results.

Q: How does manual control and semi-automatic operation benefit users?

A: Manual lever and push-button controls give users direct command over the machining process. This ensures high precision and flexibility, allowing operators to make real-time adjustments and reducing the likelihood of error in complex or varied operations.

Q: What types of materials can be processed with this machine?

A: Designed for heavy-duty machining, the 2H135 can efficiently drill and tap various metals, especially mild steel, thanks to its robust construction, adaptable spindle speeds, and powerful electric motor.
