CIMA P4-AUR Hydraulic Gear Hobbing Machine

Name: CIMA P4-AUR Hydraulic Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

CIMA P4-AUR Hydraulic Gear Hobbing Machine Specification

Feature
Hydraulic powered, precision machining, robust construction

Dimension (L*W*H)
2000 mm x 1200 mm x 1800 mm

Voltage
415 V

Capacity
Hob up to 4 Module gears

Weight
Approx. 2200 kg

Color
Green

Power
4.5 kW

Used For
Gear cutting and hobbing operations

Output
High production capacity

Machine Type
Hydraulic Gear Hobbing Machine

Condition
Used

Hydraulic System Pressure
Up to 20 Bar

Max Hob Size
Diameter 100 mm x Length 160 mm

Table Diameter
180 mm

Model
P4-AUR

Minimum Module
0.5

Main Spindle Speed Range
50 - 500 rpm

Electrical Control
Manual and automatic modes

Max Workpiece Diameter
250 mm

Coolant System
Integrated

Tailstock Provided
Yes

Number of Axis
2 (Work and Hob)

Maximum Table Speed
120 rpm

Clamping Type
Hydraulic and mechanical

CIMA P4-AUR Hydraulic Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About CIMA P4-AUR Hydraulic Gear Hobbing Machine

Make - CIMA (Italy)

Model - P4-AUR

Max. Gear Diameter - 300 mm

Max. Module - 6 Modules

Max. Width of Gear Cutting - 220 mm

Max. Hob Cutter Size - Diameter 120 mm x 120 mm Length

Hob Rotation Speeds - 70 rpm to 476 rpm

Max. Height from Table Top to Center - 800 mm

Table Diameter - 310 mm

Table Bore - 85 mm

Hob Shifting - 100 mm

Type - Hydraulic ; Auto-Cycle High Production.

- Complete with Change Gears, Arbours & other accessories.

- Features like Taper Gear Cutting, Automatic Hob Shifting etc.

- Electrical Drawing of the machine is available.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/p7RlAGltekQ

Reliable Performance and High Precision

Engineered for accuracy, the CIMA P4-AUR provides precise gear hobbing with two-axis control on the work and hob. The hydraulic system ensures consistent pressure and clamping, resulting in stable machining for high-quality gears. Its robust construction ensures durability even during continuous high-capacity production.

Flexible Operations and Integrated Features

This machine supports both manual and automatic electrical modes, allowing operators to switch according to job requirements. The integrated coolant system enhances tool life and cutting quality, while the tailstock ensures accurate workpiece alignment. The machine's hydraulic-powered system facilitates easy and secure clamping for various gear sizes.

FAQ's of CIMA P4-AUR Hydraulic Gear Hobbing Machine:

Q: How does the CIMA P4-AUR Hydraulic Gear Hobbing Machine improve gear production efficiency?

A: Thanks to its hydraulic-powered clamping and integrated coolant system, the P4-AUR allows for faster setup, stable machining, and higher cutting speeds. Its ability to handle up to 4 Module gears and workpieces with diameters up to 250 mm supports high production rates with consistent precision.

Q: What kind of gear types and sizes are compatible with this machine?

A: The CIMA P4-AUR can process workpieces up to 250 mm in diameter and accepts hobs up to 100 mm in diameter by 160 mm in length. It efficiently produces gears up to 4 Module and operates with a minimum module of 0.5, making it suitable for various industrial gear applications.

Q: When should I use the manual or automatic mode on this hobbing machine?

A: Manual mode is ideal for setup, adjustment, or unique production runs requiring operator control. Automatic mode is best utilized during consistent, repetitive jobs for increased productivity and reduced operator intervention.

Q: Where can the CIMA P4-AUR Hydraulic Gear Hobbing Machine be installed and used?

A: This model is intended for use in industrial environments such as gear production workshops, manufacturing plants, and specialized machining centers. Its compact footprint (2000 mm x 1200 mm x 1800 mm) allows easy installation in most production facilities.

Q: What is the process for gear cutting on this machine?

A: The gear blank is securely clamped utilizing the hydraulic and mechanical system. The hob is mounted and aligned using the tailstock and set to the required specification. With the appropriate power and coolant, the gear cutting operation begins as the work table and hob spindle rotate as per programmed settings.

Q: How does the integrated coolant system benefit operations?

A: The coolant system maintains optimal cutting temperatures, prevents overheating, and prolongs tool life. It also enhances surface finish and overall gear quality, especially during high-speed or prolonged production runs.
