Pfauter R1 Gear Hobbing Machine

Name: Pfauter R1 Gear Hobbing Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Pfauter R1 Gear Hobbing Machine Specification

Weight
Approximately 1500 kg

Color
Green

Voltage
415 V

Power
3.5 kW

Dimension (L*W*H)
1700mm x 1400mm x 1750mm

Condition
Used

Feature
High accuracy, robust construction, user-friendly operation

Capacity
Module up to 4 mm, Max gear diameter 400 mm

Machine Type
Gear Hobbing Machine

Used For
Precision cutting and shaping of gears

Output
High-quality gear profiles

Table Diameter
340 mm

Safety Features
Overload protection, emergency stop switch

Gear Material Compatibility
Steel, Cast Iron, Aluminium

Model
Pfauter R1

Mounting Type
Floor-mounted, standalone

Coolant System
Integrated

Main Drive Motor
Reliable 3-phase induction motor

Number of Teeth
Up to 999

Max Hob Diameter
120 mm

Axial Slide Travel
180 mm

Control System
Conventional mechanical controls

Hob Arbor Diameter
22 mm

Lubrication
Centralized automatic

Spindle Speed
Adjustable, up to 100 rpm

Max Hob Length
220 mm

Pfauter R1 Gear Hobbing Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Pfauter R1 Gear Hobbing Machine

Make - Pfauter (Germany)

Model - R1

Max. Module - 5 Modules

Max. Gear Diameter (without Tail-Stock) - 600 mm

Vertical Travel of Hob Slide - 310 mm

Table Diameter - 500 mm

Max. Gear Diameter (with Tail-Stock) - 400 mm

- Equipped with a VFD drive for Hob-Speeds.

- Machine is complete with Change Gears.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/yZNDLmxVTwA

Precision Engineering for Gear Manufacturing

The Pfauter R1 is engineered for high-accuracy gear cutting, supporting up to 999 teeth and adjustable spindle speed up to 100 rpm. Its robust construction ensures long-term reliability, making it suitable for continuous industrial use and mass production environments.

Versatile Gear Material Compatibility

Able to handle materials such as steel, cast iron, and aluminium, this gear hobbing machine delivers consistent performance across various applications. The integrated coolant and automatic lubrication systems help sustain optimal cutting conditions, reducing wear for enhanced durability.

User-Friendly and Safe Operation

Featuring conventional mechanical controls, the Pfauter R1 is easy to operate. Floor-mounted and standalone, it incorporates key safety features like overload protection and an emergency stop, prioritizing operator safety during intensive gear-shaping processes.

FAQ's of Pfauter R1 Gear Hobbing Machine:

Q: How does the Pfauter R1 Gear Hobbing Machine facilitate precise gear cutting?

A: The Pfauter R1 supports precision with its high-accuracy construction, adjustable spindle speed up to 100 rpm, and robust axial slide travel (180 mm). Its advanced design allows for meticulous control of hob feeds and gear tooth profiles ensuring quality output.

Q: What types of gear materials can be processed with this machine?

A: This machine is compatible with steel, cast iron, and aluminium, making it suitable for a wide range of gear manufacturing needs in automotive, industrial, and machinery sectors.

Q: Where is the Pfauter R1 most commonly installed and operated?

A: As a floor-mounted, standalone machine, it is typically installed in manufacturing facilities, gear workshops, and industrial environments where precision gear production is required.

Q: When should the integrated coolant and lubrication systems be utilized during operation?

A: These systems operate automatically to maintain optimal temperature and reduce friction during gear cutting, ensuring consistent performance and prolonging the machine's working life throughout each production run.

Q: What is the process for operating the Pfauter R1 Gear Hobbing Machine?

A: Operators mount the gear blank and hob, set mechanical controls including spindle speed and required tooth parameters, and engage safety features. The integrated systems manage cooling and lubrication, while gears are precisely cut to the desired specifications.

Q: What are the main benefits of using this gear hobbing machine?

A: Key benefits include high-quality gear profiles, reliable performance for module up to 4 mm, user-friendly conventional controls, and robust safety measures. The machine is designed for accuracy and extended operational life with minimal maintenance requirements.

Q: How many gear teeth can the Pfauter R1 produce in a single operation?

A: The Pfauter R1 supports gear cutting with up to 999 teeth per gear, enabling the manufacturing of a wide range of gear types for various applications.
