Colchester England Student 1800 Lathe Machine

Name: Colchester England Student 1800 Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester England Student 1800 Lathe Machine Specification

Product Type
Centre Lathe Machine

Material
Cast Iron, Steel

Cutting Thickness
Up to 6 mm depending on tool

Cutting Speed
35 to 2000 RPM variable

CNC Or Not
Manual

Automatic Grade
Semi-Automatic

Control System
Handwheel & Lever Operated

Max. Swing Diameter
360 mm over bed

Voltage
415 V / 3 Phase

Weight (kg)
Approx. 1100 kg

Dimension (L*W*H)
2150 x 950 x 1350 mm

Capacity
Standard 1800 mm between centers

Feature
Robust construction, hardened bedways

Color
Standard Colchester Grey

Coolant Pump
Fitted as standard

Tailstock Quill Travel
120 mm

Gearbox Type
Enclosed, splash lubricated

Tool Post Type
4-way

Spindle Bore
40 mm

Accessories Included
Faceplate, steady rest, centers

Lead Screw Diameter
25 mm

Chuck Size
250 mm

Threads Range
0.2 mm to 14 mm pitch

Bed Width
187 mm

Motor Power
2.2 kW (3 HP)

Surface Finish
Precision ground

Max Distance Between Centers
1000 mm

Colchester England Student 1800 Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Colchester England Student 1800 Lathe Machine

Make - Colchester (England)

Model - Student 1800

Center Height - 165 mm

Max. Length of Job - 650 mm

Max. Job Diameter over Bed - 330 mm

Max. Job Diameter over Cross-Slide - 210 mm

Chuck Diameter - 200 mm

Bed Width - 230 mm

Spindle Speeds - 22 rpm to 1800 rpm

Spindle Bore - 40 mm

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/xOIIHSzFOsk

Engineered for Versatility and Accuracy

The Colchester Student 1800 Lathe stands out for its precision ground surface and hardened bedways, ensuring consistent accuracy over years of heavy use. Its adjustable cutting speeds and variable threads support a range of turning and threading operations, making it suitable for students, engineers, and machinists who demand reliability across different materials and applications.

Complete Feature Set for Enhanced Usability

Standard with a 250 mm chuck, robust 4-way tool post, and automatic coolant pump, this lathe handles complex jobs with ease. Enclosed, splash-lubricated gearbox offers long term efficiency while minimizing maintenance. The machine arrives with essential accessories - faceplate, steady rest, and centers - enabling immediate, versatile operation upon installation.

Safe and Efficient Operation

Manual control via intuitive handwheel and lever mechanisms gives operators total command while semi-automatic grade automation streamlines repetitive processes. The cast iron and steel construction offers stability for smooth, vibration-free operation, all while supporting heavy workpieces securely between centers up to 1800 mm apart.

FAQ's of Colchester England Student 1800 Lathe Machine:

Q: How do I operate the Colchester Student 1800 Lathe safely?

A: To operate the Colchester Student 1800 Lathe safely, always ensure the machine is properly secured and the workpiece is clamped between centers or in the chuck. Use handwheels and lever controls with caution, keep guards and shields in place, and wear appropriate personal protective equipment. Familiarize yourself with all controls and settings before starting.

Q: What types of materials can the Student 1800 Lathe handle?

A: This lathe is constructed from cast iron and steel, designed to machine a wide variety of materials such as mild steel, aluminum, brass, and certain plastics, depending on tool selection and setup. Its solid design and variable speed capabilities make it versatile for different workshop tasks.

Q: When should the coolant pump be used during machining?

A: The coolant pump, fitted as standard, should be used when performing extended cutting or threading operations with higher friction to prevent overheating, improve surface finish, and prolong tool life. Activate the pump as recommended based on your specific material and cutting requirements.

Q: Where is the Colchester Student 1800 Lathe best utilized?

A: This lathe excels in educational institutions, training centers, industrial workshops, and repair facilities where precise manual turning, threading, and facing operations are required. Its durability and ease of use make it ideal for both instruction and production environments.

Q: What is the process for changing cutting speed on the machine?

A: Changing the cutting speed involves selecting the appropriate gearbox setting using the enclosed, splash-lubricated gearbox system and adjusting the handwheel or lever controls. Consult the machine's manual to ensure the correct speed selection for your material and operation.

Q: How does the semi-automatic operation benefit users?

A: Semi-automatic operation streamlines machining tasks by reducing manual input for repetitive movements while maintaining the user's ability to make fine adjustments. This results in greater productivity without sacrificing the hands-on control essential for complex machining jobs.

Q: What accessories are included with the Colchester Student 1800 Lathe?

A: The machine comes complete with a faceplate, steady rest, and centers, supporting a variety of operations right from initial setup. These accessories enhance versatility and allow you to start basic and advanced turning applications immediately after installation.
