Colchester England 2000 mm Length Gap-Bed Lathe Machine

Name: Colchester England 2000 mm Length Gap-Bed Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Colchester England 2000 mm Length Gap-Bed Lathe Machine Specification

Product Type
Gap-Bed Lathe Machine

Material
Cast Iron Body

Cutting Thickness
Varies with tool & setup, typically 0.01 mm to several mm per pass

Cutting Speed
Manual control, up to 2000 mm length capacity

CNC Or Not
No, Manual lathe

Automatic Grade
Manual

Control System
Geared manual controls

Max. Swing Diameter
540 mm over bed

Voltage
415 V, 3 phase

Weight (kg)
Approx. 2000 kg

Dimension (L*W*H)
Approx. 3200 mm x 850 mm x 1400 mm

Capacity
2000 mm between centers

Feature
Heavy-duty construction, precision spindle, removable gap

Color
Industrial grey

Lead Screw Size
35 mm diameter

Bed Type
Hardened and ground gap-bed

Chuck Size
Standard 3-jaw chuck; 250 mm

Distance Between Centers
2000 mm

Spindle Bore
76 mm

Feed System
Automatic and manual longitudinal/cross feed

Headstock Type
Geared, high precision

Coolant System
Integrated

Tailstock Quill Travel
150 mm

Lubrication
Centralized lubrication system

Power Requirement
5 HP motor

Number of Spindle Speeds
Multiple speeds (typically 1216) selectable

Colchester England 2000 mm Length Gap-Bed Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Colchester England 2000 mm Length Gap-Bed Lathe Machine

Make - Colchester (England)

Model - Mascot 1600

Center Height - 225 mm

Max. Length of Job - 2030 mm

Max. Job Diameter over Bed - 440 mm

Max. Job Diameter over Cross-Slide - 265 mm

3-Jaw Chuck Diameter - 310 mm

4-Jaw Chuck Diameter - 410 mm

Spindle Speeds - 20 rpm to 1600 rpm

Bed Width - 342 mm

Max. Swing Diameter in Gap - 710 mm

Spindle Bore - 78 mm

- Complete with 3-Jaw Chuck and Job Steady.

- Equipped with a 2-Axis DRO.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/3gEcok19ZVo

Precision Heavy-Duty Engineering

Engineered with a hardened and ground gap-bed, the Colchester lathe delivers unmatched stability and accuracy for heavy loads and long workpieces. Its high-precision geared headstock, large lead screw, and robust power system ensure superior performance throughout intensive machining jobs.

Flexible Machining Capability

The machine accommodates a maximum swing diameter of 540 mm over bed and offers variable spindle speeds, making it ideal for diverse materials and cutting depths. The removable gap further increases the versatility, allowing easy machining of oversized or irregular workpieces.

User-Friendly Manual Operation

Though fully manual, this lathe is equipped with straightforward geared controls and both automatic and manual feeds, offering operators reliable and effortless handling. The integrated coolant and centralized lubrication system enhances longevity while minimizing maintenance downtime.

FAQ's of Colchester England 2000 mm Length Gap-Bed Lathe Machine:

Q: How does the gap-bed design benefit users working with oversized workpieces?

A: The gap-bed design allows for the removable section near the chuck, enabling operators to machine larger diameter components that would otherwise not fit over the bed. This flexibility makes the machine suitable for varied turning applications.

Q: What is the process for selecting spindle speeds on this manual lathe?

A: The operator can choose from multiple spindle speeds (usually 12-16) through the geared manual controls located on the headstock, allowing precise speed adjustments to suit different materials and cutting operations.

Q: Where is this lathe machine most commonly used?

A: This Colchester gap-bed lathe is widely utilized in metal workshops, manufacturing plants, and heavy engineering industries, especially where long and heavy components need precise turning and reliable performance.

Q: What maintenance processes help ensure machine longevity?

A: Regular checks and use of the integrated coolant and centralized lubrication system are key to reducing wear on moving parts and maintaining smooth operation, thereby extending the lathe's operational life.

Q: When should the tailstock quill travel be used during machining?

A: The tailstock quill, with a 150 mm travel range, should be engaged when supporting long workpieces to minimize deflection and vibrations, ensuring accurate turning results during operations.

Q: How can operators benefit from the feed system options?

A: Users can choose between automatic and manual longitudinal or cross feed, giving them the flexibility for both high-precision hand-finished operations and consistent, controlled feeds suited for bulk or repetitive machining tasks.

Q: What types of workpieces can this lathe accommodate regarding size and capacity?

A: With a 2000 mm distance between centers and a 540 mm swing over bed, the lathe accommodates large shafts, pipes, rollers, and similar heavy-duty components, delivering stable and accurate results across a broad spectrum of industrial uses.
