Send InquiryPoreba TR-90 x 4000 Heavy Duty Lathe Machine
Price 100000 INR/ Piece
MOQ : 1 Piece
Poreba TR-90 x 4000 Heavy Duty Lathe Machine Specification
- Product Type
- Heavy Duty Lathe Machine
- Material
- Heavy Duty Cast Iron
- Cutting Thickness
- Up to 30 mm (depending on material)
- Cutting Speed
- Variable, up to 1200 RPM
- CNC Or Not
- Conventional
- Automatic Grade
- Manual
- Control System
- Manual
- Max. Swing Diameter
- 900 mm
- Voltage
- 415V / 3 Phase / 50 Hz
- Weight (kg)
- Approx. 8500 kg
- Dimension (L*W*H)
- Approx. 6700 mm x 1800 mm x 1700 mm
- Capacity
- 4 meters (center distance)
- Feature
- Robust construction, precision hardened bed ways, high rigidity
- Color
- Standard Industrial Grey
- Lead Screw Diameter and Pitch
- 50 mm / 8 mm
- Distance Between Centers
- 4000 mm
- Taper in Spindle
- MT-7
- Tail Stock Quill Travel
- 250 mm
- Carriage Travel
- 3900 mm
- Coolant System
- Fitted
- Motor Power
- 15 HP
- Tail Stock Quill Diameter
- 100 mm
- Lubrication System
- Centralized
- Electricals
- Standard with safety features
- Spindle Speeds
- 16 steps
- Thread Cutting Range
- Metric: 1120 mm, Inch: 248 TPI
- Chuck Size
- 500 mm (manual 4-jaw)
- Max. Turning Length
- 4000 mm
- Spindle Nose
- A1-11
- Bed Width
- 600 mm
- Spindle Bore
- 105 mm
- Bed Type
- Hardened and ground double V-type
Poreba TR-90 x 4000 Heavy Duty Lathe Machine Trade Information
- Minimum Order Quantity
- 1 Piece
- Main Domestic Market
- All India
Poreba TR-90 x 4000 Heavy Duty Lathe Machine About
Make - Poreba (Poland)
Model - TR-90
Center Height - 450 mm
Max. Length of Job - 4000 mm
Max. Job Diameter over Bed - 900 mm
Max. Job Diameter over Cross-Slide - 600 mm
Chuck Diameter - 800 mm
Bed Width - 660 mm
Spindle Speeds - 7.5 rpm to 380 rpm
Spindle Bore - 105 mm
- Motorised Rapid Travels on the Carriage & Cross-Slide
- Complete with Job Steady etc.
- Machine is in excellent working condition.
Video of The Machine -
Heavy Duty Performance with Precision
Engineered for versatility, the Poreba TR-90 x 4000 offers exceptional stability and accuracy thanks to its heavy-duty cast iron body and precision-hardened bed ways. Capable of handling workpieces up to 4 meters and supporting turning thicknesses up to 30 mm, this lathe excels in demanding workshops requiring both productivity and high-quality results.
Reliable Manual Control and Safety
With its conventional manual control system, operators have full command over the machine, allowing for flexible and intuitive machining. The inclusion of centralized lubrication, standard safety electricals, and a fitted coolant system ensures smooth, reliable operation and prolongs the lifespan of machine components.
FAQ's of Poreba TR-90 x 4000 Heavy Duty Lathe Machine:
Q: How does the Poreba TR-90 x 4000 enhance machining precision and stability?
A: This lathe is built with a hardened and ground double V-type bed and a robust cast iron body, which provide excellent rigidity, minimize vibration, and maintain accuracy even during heavy-duty operations.Q: What are the main uses for the Poreba TR-90 x 4000 lathe machine?
A: It is ideal for turning, facing, threading, and other cylindrical machining operations on long and heavy workpieces, making it highly suitable for industries such as manufacturing, energy, and fabrication.Q: When should I perform maintenance on this lathe machine?
A: Routine maintenance should be conducted according to usage intensity, typically involving lubrication checks, cleaning, and inspection of moving parts after each significant job or at least once per week for continuous operation.Q: Where can the Poreba TR-90 x 4000 be installed?
A: Due to its large dimensions and weight (approx. 8500 kg), the lathe requires a stable, reinforced industrial floor space measuring at least 6700 mm x 1800 mm for proper installation and safe operation.Q: What is the spindle speed range, and how is it selected?
A: The lathe offers a 16-step spindle speed selection, ranging up to 1200 RPM, which is manually adjusted to suit various material and machining requirements, providing flexibility for different operations.Q: How does the coolant and lubrication system benefit machine usage?
A: The fitted coolant system helps manage heat during cutting, while the centralized lubrication ensures smooth, wear-resistant movement of all critical components, enhancing both performance and longevity.Q: What benefits does the manual control system offer?
A: Manual control allows experienced operators precise adjustments and immediate intervention, ensuring flexibility across a wide variety of complex and non-repetitive turning projects.
