TOS SU80A 2900 mm Heavy Duty Lathe Machine
TOS SU80A 2900 mm Heavy Duty Lathe Machine

TOS SU80A 2900 mm Heavy Duty Lathe Machine

Price 15000 INR/ Piece

MOQ : 1 Piece

TOS SU80A 2900 mm Heavy Duty Lathe Machine Specification

  • Product Type
  • Heavy Duty Lathe Machine
  • Material
  • High-grade Cast Iron and Alloy Steel
  • Cutting Thickness
  • Up to 20 mm (depending on material)
  • Cutting Speed
  • Up to 1800 rpm
  • CNC Or Not
  • No (Conventional Lathe)
  • Automatic Grade
  • Manual
  • Control System
  • Manual
  • Max. Swing Diameter
  • 800 mm
  • Voltage
  • 415 V / 3 Phase / 50 Hz
  • Weight (kg)
  • Approx. 6500 kg
  • Dimension (L*W*H)
  • 4300 mm x 1600 mm x 1500 mm
  • Capacity
  • Workpiece Length up to 2900 mm
  • Feature
  • Heavy Duty, High Precision, Long Bed
  • Color
  • Standard Industrial Grey / Green
  • Distance Between Centers
  • 2900 mm
  • Lead Screw Diameter
  • 50 mm
  • Tailstock Quill Diameter
  • 90 mm
  • Number of Spindle Speeds
  • 18
  • Main Motor Power
  • 11 kW
  • Bed Type
  • Hardened and Ground
  • Coolant System
  • Included
  • Lubrication System
  • Centralized
  • Thread Range (Metric)
  • 1 to 120 mm
  • Spindle Nose
  • Camlock DIN 55029
  • Cross Slide Travel
  • 500 mm
  • Thread Range (Inch)
  • 2 to 60 TPI
  • Chuck Size
  • 400 mm (3- or 4-jaw supplied)
  • Spindle Bore
  • 105 mm
  • Tailstock Quill Travel
  • 230 mm


TOS SU80A 2900 mm Heavy Duty Lathe Machine Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Main Domestic Market
  • All India


About TOS SU80A 2900 mm Heavy Duty Lathe Machine

Make - TOS (Czech Republic)

Model - SU 80A

Center Height - 415 mm

Max. Length of Job - 2900 mm

Max. Job Diameter over Bed - 820 mm

Max. Job Diameter over Cross-Slide - 510 mm

4-Jaw Chuck Diameter - 850 mm

Bed Width - 700 mm

Spindle Speeds - 6.7 rpm to 1000 rpm

Spindle Bore - 70 mm

Max. Job Size (in Gap) - Diameter 870 mm x 225 mm Length

- Complete with Steady & Follow Rest.

- Motorised Rapid Travels of the Carriage & Cross-Slide.

- Machine is in excellent working condition


Video of The Machine -

https://youtu.be/m0HAsguq90U



Engineered for Precision & Durability

Constructed from high-grade cast iron and alloy steel, the TOS SU80A lathe integrates a hardened and ground bed, ensuring stability and precision during extended use. Its robust structure supports heavy-duty applications, while the 11 kW motor delivers consistent power, and the centralized lubrication guarantees smooth machine operation.


Versatile Cutting & Threading Capabilities

The machine offers impressive cutting speeds up to 1800 rpm and handles cutting thicknesses up to 20 mm, varying by material. Its threading range is widesupporting both metric threads (1-120 mm) and inch threads (2-60 TPI)making it suitable for diverse metalworking requirements. Spindle speed options and a 400 mm chuck further add to its flexibility.


Practical Design for Industrial Use

With a 2900 mm distance between centers and a maximum swing diameter of 800 mm, the TOS SU80A is ideal for large-part machining. The bed design and manual controls cater to straightforward operation, while included systems for coolant and lubrication contribute to efficient, long-term use. Its industrial color, voltage compatibility, and heavy-duty nature fit demanding manufacturing settings.

FAQs of TOS SU80A 2900 mm Heavy Duty Lathe Machine:


Q: How is the TOS SU80A 2900 mm Heavy Duty Lathe Machine operated?

A: This lathe operates manually, utilizing conventional controls for precision machining tasks. Operators set the desired spindle speed, feed, and cutting parameters using user-friendly controls, allowing for hands-on adjustments during turning, threading, or facing operations.

Q: What materials can the TOS SU80A lathe machine process?

A: Thanks to its high-grade cast iron and alloy steel construction, combined with a powerful 11 kW motor, the TOS SU80A can process a variety of metals, including steel, cast iron, and non-ferrous materials, with a cutting thickness up to 20 mm (depending on material properties).

Q: When should I use the coolant and centralized lubrication systems?

A: Engage the coolant system during high-speed or continuous cutting operations to prevent tool overheating and prolong tool life. The centralized lubrication system should run as recommended by maintenance schedules to ensure all moving parts are properly lubricated, minimizing wear and ensuring smooth operation.

Q: Where is this lathe machine most effectively utilized?

A: The TOS SU80A is designed for industrial settings such as fabrication workshops, heavy machinery manufacturing plants, and repair facilities requiring precision, durability, and an extended machining capacity for large or heavy workpieces.

Q: What is the process for threading on the TOS SU80A lathe?

A: Threading involves selecting the appropriate thread type (metric or inch) using the machines controls, setting the lead screw, and engaging the carriage to follow the thread path. The machine accommodates a broad thread range, supporting various component requirements.

Q: What benefits does the hardened and ground bed provide?

A: A hardened and ground bed delivers exceptional wear resistance and maintains alignment across long-term, heavy-duty use. This ensures repeatable machining accuracy, making it ideal for consistently producing precision parts over time.
