Deber Heavy Duty Universal Milling Machine

Name: Deber Heavy Duty Universal Milling Machine
Brand: Liberty Metal & Machines Private Limited
Price: 14700 INR
Availability: InStock

Price 14700 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Deber Heavy Duty Universal Milling Machine Specification

Rotation
Clockwise & Counterclockwise

Model
Deber Heavy Duty Universal

Product Type
Universal Milling Machine

General Use
Heavy Duty Metal Milling

Material
Cast Iron

Type
Universal

Capacity
Heavy Duty

Weight (kg)
2850 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC

Control System
Manual

Table Size
1500 x 360 mm

Table Slide Way
Hardened and Ground

Magnetic Chuck Size
400 x 150 mm

Grinding Wheel Size
250 x 25 x 76 mm

Grinding Wheel Speed
1450 rpm

Grinding Length
1250 mm

Floor Space
2750 x 2100 mm

Fuel Tank Capacity
60 L

Spindle Speed
40-1600 rpm (variable)

Power
7.5 HP / 5.5 kW

Voltage
415 V, 3 Phase

Dimension (L*W*H)
2750 x 2100 x 1950 mm

Feature
Precision, High Rigidity, Durable

Color
White & Blue

Number of T-Slots
3

Max Table Load
700 kg

T-Slot Size
18 mm

Rapid Feed Rate
2000 mm/min

Coolant System
Yes

Spindle Taper
ISO 50

Working Speed
Variable

Table Swivel
±45°

Feed Range
Longitudinal/Transversal: 22 - 545 mm/min

Overarm Travel
300 mm

Vertical Travel (Z-Axis)
450 mm

Lubrication System
Automatic

Main Motor Power
5.5 kW

Cross Travel (Y-Axis)
300 mm

Longitudinal Travel (X-Axis)
1200 mm

Spindle Motor Power
3.7 kW

Deber Heavy Duty Universal Milling Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Deber Heavy Duty Universal Milling Machine

Make - Deber (Italy)

Model - Maxim-P

Table Size - 1800 mm x 400 mm

XYZ Travel - 1325 mm x 375 mm x 550 mm

Spindle Taper - ISO 50

Spindle Speed - 18 rpm to 1000 rpm

- Double Swivel type Vertical Milling Head.

- Rotating Type Table.

- Complete with Bracket for Horizontal Milling.

- It is a Heavy Duty type Universal Milling Machine.

- Machine is in excellent working condition.

Video Link -

https://youtu.be/wMy72y6LXZY

Precision and Versatility

Designed for heavy-duty milling, this universal machine is perfect for a wide array of metalworking applications. Its variable working speed, large table with 45 swivel, and overarm travel support a variety of setups and machining angles, providing both adaptability and accuracy for demanding projects.

Durable and Reliable Construction

Built from high-quality cast iron and featuring hardened and ground table slide ways, the Deber Heavy Duty Universal Milling Machine ensures longevity and stability under heavy loads. Its automatic lubrication system and advanced coolant function further enhance operational efficiency and reduce maintenance requirements.

Optimized for Operator Control

Equipped with manual controls, this milling machine grants the user full management of feeds, speeds, and machining operations. Clockwise and counterclockwise spindle rotation, along with precise feed adjustments, enable consistent and accurate results on each workpiece, giving professionals confidence in their workflow.

FAQs of Deber Heavy Duty Universal Milling Machine:

Q: How does the Deber Heavy Duty Universal Milling Machine enhance precision during operation?

A: The machine is engineered with hardened and ground table slide ways, robust cast iron construction, and a manual control system. These features ensure stable, vibration-dampened operations and allow the operator to finely tune machining parameters for optimal precision.

Q: What materials and applications is this milling machine best suited for?

A: This model is specifically designed for heavy-duty metal milling, accommodating both roughing and finishing tasks. Its rigidity, high table load capacity, and ISO 50 spindle taper make it ideal for industrial environments, including manufacturing, tooling, and repair workshops.

Q: When should I use the coolant and automatic lubrication systems?

A: The coolant system should be utilized during high-speed or extended machining to maintain temperature and prevent thermal deformation. The automatic lubrication system operates continuously during use to ensure smooth movement and protection of key components, reducing wear and prolonging machine life.

Q: Where is the Deber Heavy Duty Universal Milling Machine typically installed?

A: Due to its size (2750 x 2100 x 1950 mm) and weight (2850 kg), this machine is best situated in industrial workshops, manufacturing plants, or dedicated metalworking facilities with sufficient floor space and power supply (415 V, 3-phase).

Q: What is the process for changing spindle speeds on this machine?

A: Spindle speeds can be adjusted manually within a variable range of 40 to 1600 rpm, allowing operators to select the ideal speed for specific materials or cutting operations. Adjustments are performed using the machines spindle control interface, ensuring flexibility and adaptability.

Q: How does the manual control system benefit operators?

A: Manual control offers direct and immediate adjustment over feed rates, spindle speeds, and table movements, providing experienced machinists the ability to react swiftly to changes in material behavior or cutting requirements, ultimately improving finished part quality.
