Ernault Somua Cholet 550 Lathe Machine

Name: Ernault Somua Cholet 550 Lathe Machine
Brand: Liberty Metal & Machines Private Limited
Price: 100000 INR
Availability: InStock

Price 100000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Ernault Somua Cholet 550 Lathe Machine Specification

Product Type
Manual Lathe Machine

Material
Cast Iron Body

Cutting Thickness
Depends on tool and material

Cutting Speed
Variable (Up to 1500 RPM)

CNC Or Not
No

Automatic Grade
Manual

Control System
Manual Controls

Max. Swing Diameter
560 mm

Voltage
415 V, 3 Phase

Weight (kg)
Approx. 3800 kg

Dimension (L*W*H)
Approx. 3500 x 1200 x 1500 mm

Capacity
Heavy Duty Suitable for large workpieces

Feature
High Rigidity, Precision Ground Bed, Hardened Gears

Color
Grey & Light Green

Spindle Bore
72 mm

Leadscrew Pitch
6 mm

Carriage Travel
1850 mm

Feed Range
0.04 to 2.24 mm/rev

Metric Thread Cutting Range
0.5-72 mm

Distance Between Centers
2000 mm

Number of Spindle Speeds
18

Chuck Size
325 mm

Bed Width
400 mm

Spindle Nose
Camlock D1-6

Tailstock Quill Travel
250 mm

Inch Thread Cutting Range
72-0.5 TPI

Ernault Somua Cholet 550 Lathe Machine Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Ernault Somua Cholet 550 Lathe Machine

Make - H. Ernault Somua (France)

Model - Cholet 550

Center Height - 250 mm

Max. Length of Job - 1100 mm

Max. Job Diameter over Bed - 500 mm

Max. Job Diameter over Cross-Slide - 310 mm

Max. Job Diameter in Gap - 700 mm

Max. Job Length in Gap - 175 mm

Bed Width - 385 mm

Spindle Bore - 52 mm

Chuck Diameter - 355 mm

Spindle Speeds - 16 rpm to 1600 rpm

- With Motorised Rapid Travels of Carriage & Cross-Slide.

- Micro-Feed Travels on the Cross-Slide Movement.

- Complete with Job Steady, & many other accessories.

- Equipped with a 2-Axis DRO.

- Bigger Diameter Job can be machined without removing the gap-piece.

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/nszDizxhwxE

Precision Engineering for Demanding Applications

Designed for manufacturers, exporters, and suppliers, the Ernault Somua Cholet 550 delivers unmatched stability and precision. The rigid cast iron frame and accurately ground bed minimize vibration, enabling high-quality machining of extensive workpieces. Its variable speed and manual controls give machinists flexibility and control to achieve desired finishes on diverse materials. This lathe excels in both production and custom machining environments.

Versatile Features for Enhanced Productivity

Whether threading metric or inch standards, or creating complex shapes, the Cholet 550 offers significant versatility with a comprehensive thread-cutting range, 18 spindle speeds, and manual grade operation. Its 325 mm chuck and long carriage travel enable processing of lengthy components, while the robust bed width and heavy build support intensive use. The hardened gears ensure longevity, making it a reliable investment for heavy-duty machining tasks.

FAQ's of Ernault Somua Cholet 550 Lathe Machine:

Q: How is the Ernault Somua Cholet 550 lathe machine typically used?

A: This lathe is primarily used for turning, facing, threading, and boring large, heavy workpieces. Its high rigidity and robust construction make it ideal for demanding industrial machining operations, such as producing shafts, rollers, and specialized components.

Q: What benefits does the Cholet 550's manual operation offer?

A: Manual controls provide machinists with precise, direct interaction over all cutting and feed parameters. This flexibility is especially valuable for custom jobs or prototype work where frequent adjustments and hands-on control are needed.

Q: When should I choose a lathe with a 72 mm spindle bore and 560 mm swing?

A: Opt for this machine when working with large diameter or long workpieces that require significant spindle clearance and swing. The 72 mm spindle bore is suitable for bar work and components requiring substantial through-hole capacity.

Q: Where is the Ernault Somua Cholet 550 most commonly installed?

A: It's commonly found in industrial machine shops, metalworking factories, training institutes, and engineering workshops specializing in medium to heavy machining tasks. Its robustness and precision make it suitable for export and import businesses as well.

Q: What is the threading capability of this lathe machine?

A: The Cholet 550 accurately cuts both metric and imperial threads, offering a metric thread range from 0.5 to 72 mm and an inch thread range from 72 to 0.5 TPI, supporting a wide variety of threading needs.

Q: How does the bed width and construction influence machining performance?

A: A 400 mm bed width, together with a precision-ground, cast iron construction, provides stability and resists deflection during heavy cuts. This ensures consistent accuracy and surface finish on large or tough materials.
