Tovaglieri Gap Bed Lathe Machine

Get a Price/Quote

MOQ : 1 Piece

Tovaglieri Gap Bed Lathe Machine Specification

Product Type
Gap Bed Lathe Machine

Material
Cast Iron

Cutting Thickness
Depends on application, up to 25 mm

Cutting Speed
Variable, up to 1200 RPM

CNC Or Not
Not CNC (Conventional Lathe)

Automatic Grade
Semi-Automatic

Control System
Manual

Max. Swing Diameter
600 mm

Voltage
415 V, 3 Phase

Weight (kg)
Approx. 2000 kg

Dimension (L*W*H)
Approx. 2600 x 1200 x 1500 mm

Capacity
High-duty; suitable for heavy turning jobs

Feature
Heavy-duty construction, removable gap, precision ground bed

Color
Grey/Blue

Distance Between Centers
1000 mm to 2000 mm

Lead Screw Pitch
4 mm

Carriage Traverse
Automatic and manual via apron handwheel

Coolant System
Integrated (optional)

Surface Finish
Bed and main components precision ground

Bed Length
1500 mm to 2500 mm (varies with models)

Spindle Speed Range
35 - 1500 rpm, 12 steps

Power Required
4 kW

Spindle Bore Diameter
65 mm (approx.)

Cross Slide Travel
250 mm

Headstock
All-geared type

Tailstock Travel
150 mm

Application
Turning, Facing, Drilling, Thread Cutting

Chuck Size
250 mm 3-Jaw (standard supplied)

About Tovaglieri Gap Bed Lathe Machine

Tovaglieri Gap Bed Lathe Machine

Make - Tovaglieri (Italy)
Model - TMRN-2000
Center Height - 200 mm
Max. Length of Job - 2000 mm
Max. Swing Diameter over Bed - 400 mm
Max. Swing Diameter over Cross-Slide - 230 mm
Chuck Diameter - 230 mm
Bed Width - 315 mm
Spindle Speeds - 28 rpm to 1300 rpm
Gap Bed type Lathe Machine
Machine is in excellent working condition.

Heavy-Duty Versatility

The Tovaglieri Gap Bed Lathe is engineered for intensive industrial use, supporting a wide array of operations including turning, drilling, and thread cutting. Its sturdy cast iron construction and precision-ground components ensure stability and accuracy during demanding tasks, making it a preferred choice for workshops, manufacturing plants, and heavy engineering sectors requiring consistent high performance.

Flexible and Efficient Operation

With options for both automatic and manual carriage traverse, as well as variable cutting speeds up to 1200 RPM, this lathe provides operators with precise control over every job. The removable gap bed further increases the flexibility, allowing for the machining of larger diameter workpieces, adapting effortlessly to the evolving requirements of contemporary machining applications.

FAQs of Tovaglieri Gap Bed Lathe Machine:

Q: How can I change the spindle speeds on the Tovaglieri Gap Bed Lathe Machine?

A: The Tovaglieri lathe features an all-geared headstock with 12 selectable speed steps, ranging from 35 to 1500 rpm. To change speeds, you simply adjust the gear levers on the headstock manually to your desired setting, following the speed chart provided by the manufacturer.

Q: What materials can be machined with this lathe, and what is its maximum cutting thickness?

A: The machine is designed for high-duty operation on a variety of materials including steel, aluminum, and cast iron. The maximum cutting thickness depends on the application, but it can accommodate up to 25 mm, making it suitable for most industrial turning and facing tasks.

Q: When should I use the removable gap feature of the bed?

A: The removable gap in the bed is used when you need to machine workpieces with diameters larger than the standard swing over the bed, up to the machines maximum swing diameter of 600 mm. This is commonly needed for turning flanges or discs that exceed typical dimensions.

Q: Where is the lathe best utilized and for which jobs is it most suitable?

A: This Tovaglieri lathe is ideal for industrial workshops, manufacturing units, and tool rooms that require high-precision turning, facing, drilling, and thread cutting. Its heavy-duty construction and versatility make it particularly valuable for machining larger and longer shafts, pipes, and similar components.

Q: What benefits does the precision-ground bed and components offer?

A: Precision-ground bed and components ensure minimal wear, high accuracy, and excellent surface finish on machined parts. This contributes to greater longevity of the machine and consistent quality in production work.

Q: How do I maintain the coolant system, and is it included with the lathe?

A: The lathe comes with an integrated coolant system as an optional feature. To maintain the coolant system, regularly check coolant levels, clean the filters, and ensure the pump and hoses are free from blockage. Refer to the user manual for detailed maintenance guidelines specific to your installation.
