Freeport Taiwan Manual Surface Grinder

Price 225000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Freeport Taiwan Manual Surface Grinder Specification

Rotation
Clockwise

Model
Freeport Taiwan

Product Type
Manual Surface Grinder

General Use
Surface Grinding of Metal Components

Material
Cast Iron

Type
Surface Grinder

Capacity
Up to 450 mm Grinding Length

Weight (kg)
Approx. 900 kg

Computerized
No

Automatic
No

CNC Or Not
Not CNC (Manual)

Control System
Manual Control

Table Size
150 x 450 mm

Table Slide Way
Precision Ball Bearing

Magnetic Chuck Size
150 x 450 mm

Grinding Wheel Size
180 x 13 x 31.75 mm

Grinding Wheel Speed
2850 rpm

Grinding Length
450 mm

Floor Space
1600 x 1100 mm

Fuel Tank Capacity
25 L

Spindle Speed
2850 rpm

Power
2 HP

Voltage
415 V

Dimension (L*W*H)
1600 x 1100 x 1750 mm

Feature
Sturdy Construction, Precision Grinding, Low Maintenance

Color
White & Blue

Dust Collector
Optional

Coolant System
Yes, Included

Standard Accessories
Magnetic Chuck, Grinding Wheel, Wheel Flange, Tools

Vertical Feed Graduation
0.005 mm

Table Travel (Cross)
170 mm

Maximum Load on Table
120 kg

Lubrication System
Automatic Central Lubrication

Table Travel (Longitudinal)
475 mm

Hand Feed Graduation
0.02 mm

Maximum Distance from Table Surface to Spindle Center
370 mm

Humidifier
Not Included

Freeport Taiwan Manual Surface Grinder Trade Information

Minimum Order Quantity
1 Piece

Main Domestic Market
All India

About Freeport Taiwan Manual Surface Grinder

Make - Freeport (Taiwan)

Model - SGS-816

Capacity - 400 mm x 200 mm

Longitudinal Travel - 425 mm

Cross Travel - 200 mm

Current Magnet Size - 360 mm x 200 mm

Grinding Wheel Size - Diameter 230 mm x 25 mm Width

Max. Height between Magnet Top to Wheel Center - 410 mm

Least Count - 2 Micron (0.002 mm)

Grinding Wheel Speed - 2900 rpm

- Machine is in excellent working condition.

Video of The Machine -

https://youtu.be/1I6Uzw8CY9w

Sturdy Engineering for Precision Grinding

This manual surface grinder features quality cast iron construction and precision ball bearing slide ways, ensuring reliable, stable performance and consistent machining accuracy. The 2 HP motor delivers robust drive for demanding metalworking applications, while the generously sized table supports components weighing up to 120 kg, making it ideal for both small shops and larger facilities.

Comprehensive Accessory Package

Included standard accessories such as a magnetic chuck, grinding wheel, wheel flange, and essential tools support versatile grinding applications and streamline operation setup. Optional accessories, like a dust collector, are available to further enhance usability in different workshop environments.

Low Maintenance and User-Friendly Operation

Automatic central lubrication system minimizes upkeep, ensuring smooth and trouble-free grinding operations over extended periods. Manual control combined with precise hand and vertical feed graduations (0.02 mm and 0.005 mm, respectively) allows operators to achieve accurate results without complex settings.

FAQs of Freeport Taiwan Manual Surface Grinder:

Q: How do I operate the Freeport Taiwan Manual Surface Grinder for optimal results?

A: To achieve the best grinding outcomes, mount the workpiece securely on the magnetic chuck, adjust feed rates using the hand and vertical feed graduations, and activate the coolant system to prevent overheating. Always follow manufacturer guidelines and utilize included standard accessories for setup.

Q: What types of metal components can be processed with this surface grinder?

A: This grinder is suitable for flat and shaped metal components, such as steel, cast iron, and alloys. With a grinding length capacity of up to 450 mm and maximum table load of 120 kg, it accommodates a range of sizes for precision finishing and surface improvement.

Q: Where is the Freeport Taiwan Manual Surface Grinder ideal for use?

A: It is best utilized in metalworking workshops, tool rooms, manufacturing plants, and repair facilities where manual surface grinding of metal parts is required. Its sturdy design and manual control system allow for flexible integration into various environments.

Q: What is the maintenance process for this machine?

A: Regular maintenance includes cleaning the machine, checking for wear on the grinding wheel, and refilling the fuel tank as required. The automatic central lubrication system simplifies upkeep, reducing the need for frequent manual lubrication of moving parts.

Q: When should the grinding wheel be replaced?

A: Replace the grinding wheel when noticeable wear, reduced cutting efficiency, or surface imperfections on the workpiece occur. Always install a wheel matching the specified size (180 x 13 x 31.75 mm) for optimal performance.

Q: What benefits does the included coolant system provide?

A: The coolant system reduces heat buildup during grinding, lowers the risk of workpiece distortion, and prolongs grinding wheel life. This results in superior surface finishes and increased operational efficiency.

Q: Can I use a dust collector with this machine, and why might it be needed?

A: Yes, a dust collector is available as an optional accessory. Using a dust collector is recommended in environments where airborne particles must be controlled for operator safety, machine longevity, and cleanliness.
